7-INCH AUDIO/VIDEO RECEIVER
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news
about Alpine.
Merci d'avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection
de votre achat en enregistrant votre produit dès maintenant à l'adresse suivante :
www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des
promotions spéciales et de l'actualité d'Alpine.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto,
registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales y novedades
sobre Alpine.
ALPINE ELECTRONICS OF AMERICA, INC.
1500 Atlantic Blvd,
Auburn Hills, Michigan 48326, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
iLX-W650
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
EN
FR
ES
Designed by ALPINE Japan
Advertisement
Table of Contents
Related Manuals for Alpine iLX-W650
Summary of Contents for Alpine iLX-W650
- Page 1 • MODE D’EMPLOI Veuillez lire avant d’utiliser cet appareil. Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration. You will be informed of product and software updates (if applicable), special promotions, news about Alpine.
-
Page 2: Table Of Contents
Contents About the Crossover ........... 16 About Time Correction ........17 Operating Instructions Volume Setup Phone Volume Setup .......... 18 Adjusting the Ring Tone Level ...... 18 PRECAUTIONS Adjusting the Caller Level ......18 Adjusting the Microphone Level ....18 IMPORTANT INFORMATION ...... - Page 3 Search Function ........... 32 Information Selecting the Channel Directly ......32 Apple CarPlay (Optional) Parental Lock Function ........32 Access to Apple CarPlay ........25 Bluetooth Operation Android Auto (Optional) Setup Before Using ..........33 About Bluetooth ..........33 What is Android Auto ........25 About the Hands-free Phone ......
- Page 4 Installation and Connections WARNING ............ 46 CAUTION ............. 46 Precautions ..........46 Accessory List ............47 Installation ............47 Caution concerning the installation location ............47 Mounting the Microphone ......47 Installation example using the Original Mounting Bracket ........47 Connections ............
-
Page 5: Operating Instructions
They contain instructions on how to use this product NOISES WHILE DRIVING. in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this Excessive volume levels that obscure sounds such as emergency manual. -
Page 6: Caution
Failure to do so may cause personal injury or damage to the Doing so may cause heat to build up inside and may result in fire. product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing. -
Page 7: Notice
NOTICE CAUTION Alpine accepts no responsibility for lost data, etc., even if data, etc., is Product Cleaning lost while using this product. Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything On Handling USB Flash drive else has the chance of dissolving the paint or damaging the plastic. - Page 8 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license. • MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. Supply of this product only...
-
Page 9: Getting Started
Getting Started Turning Power On or Off Some of this unit’s functions cannot be performed while the vehicle is in motion. Be sure to stop your vehicle in a safe location and apply the Location of Controls parking brake, before attempting these operations. Turn the ignition key to the ACC or ON position. -
Page 10: Touch Screen Operation
Touch Screen Operation About the HOME Screen You can operate the system by using the touch panel on the screen. In the HOME screen, you can select the audio source and perform various setups or operations on the unit. • Be sure to touch the onscreen button lightly with the pad of your finger to avoid scratching the display. -
Page 11: About The Indicator Display
About the Indicator Display How to Input Characters and Numbers (Keypad) The Indicator Bar at the top of the screen displays various types of The displayed screens and procedures may vary slightly depending on information, like the current time. the function used, but the basic input method is the same. Indicates the current time. -
Page 12: Setup
Touch the required setting icon, then touch the setting Setup item. Setting items: Sound: See “Sound Setup” (page 13). Volume: See “Volume Setup” (page 18). Setup Operation System: See “System Setup” (page 19). Connectivity: See “Connectivity Setup” (page 20). SiriusXM: See “SiriusXM Setup” (page 21). Bluetooth: See “Bluetooth Setup”... -
Page 13: Sound Setup
Adjusting the Bass/Middle/Treble Sound Setup [Sound] is selected on the Setup menu screen. You can set up items related to the sound quality. Touch [Advanced] or [Simple] to change the setting screen. <Setting item> Simple Fad./Bal. (page 13) Bass/Treble (page 13) EQ (page 13) Sub.W (page 14) Touch [ ] or [ ] for each item to be adjusted. -
Page 14: Setting The Subwoofer
Setting the Subwoofer Adjusting the Crossover Settings (X-Over) Before performing the following procedures, see “About the Crossover” (page 16). Setting item: X-Over Touch [Channel] to select the channel. Each time you touch, the channel switches. Turning Subwoofer ON/OFF If an optional subwoofer is connected to the unit, make the following setting. -
Page 15: Adjusting The Parametric Equalizer Curve (P-Eq)
• While adjusting the P-EQ, you should consider the frequency response Adjusting the Parametric Equalizer Curve of the connected speakers. (P-EQ) • To reflect the P-EQ setting, set “EQ” to [Custom] (page 13). • Touch [Flat] to initialize all values. Parametric Equalizer (P-EQ) can adjust the center frequency/Q Factor (bandwidth)/level for the front and rear speakers independently. -
Page 16: Setting The Media Xpander (Mx)
Adjusting to a frequency range outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused by... -
Page 17: About Time Correction
Example 2. Listening Position: All Seats About Time Correction Adjust the time correction level of each speaker to almost the same level. The distance between the listener and the speakers in a car vary widely due to the complex speaker placement. This difference in the distances Sit in the listening position (driver’s seat, etc.) and from the speakers to the listener creates a shift in the sounds image and measure the distance (in meters) between your head and... -
Page 18: Volume Setup
Volume Setup Volume Setup except for Phones (Other) [Volume] is selected on the Setup menu screen. [Other] is selected on the Volume Setup menu screen. Phone Volume Setup [Phone] is selected on the Volume Setup menu screen. Volume Setting You can change the volume of the sound heard when a button is touched. -
Page 19: System Setup
Setting the Brightness of the Backlighting System Setup (Dimmer) [System] is selected on the Setup menu screen. Backlighting is provided by LEDs light built into the liquid crystal panel. The illumination control adjusts the brightness of the backlighting based Setting item: System on the car ambient lighting for easier viewing. -
Page 20: Reset
Connectivity Setup Reset [Reset] is selected on the System Setup Menu screen. You can initialize [Connectivity] is selected on the Setup menu screen. all data, to restore the factory settings. Remove the USB flash drive, etc. from the system before operation. Setting item: Reset Touch [Reset]. -
Page 21: Siriusxm Setup
Use the keypad to enter the new 4-digit passcode, and SiriusXM Setup then touch [OK]. Use the keypad to enter the new 4-digit passcode a [SiriusXM] is selected on the Setup menu screen. second time to verify it, and then touch [OK]. •... -
Page 22: Bluetooth Setup
• If all 4 devices have been registered, you cannot register a 5th device. To register another device, you need to delete one of the other 4 devices Select this unit (iLX-W650) to set the Bluetooth first. connection on the Bluetooth device. -
Page 23: Camera Setup
Adjusting Color of Display Camera Setup Setting item: Colors [Camera] is selected on the Setup Menu screen. Setting contents: You can set up items related to the Camera. -5 to 5 (Initial setting: 0) Touch [Page 1], [Page 2] or [Page 3] to change the screen. •... -
Page 24: Adjusting The Rear Camera Guide
Adjusting the Rear Camera Guide Information You can adjust the camera guide position. [Information] is selected on the Setup menu screen. Setting item: Information about this system is shown. Rear Camera Guide (Page 3) Further setting item: Adjustment Touch [Adjustment] on “Page3”. The camera guide adjustment screen is displayed. -
Page 25: Apple Carplay (Optional)
Apple CarPlay Android Auto (Optional) (Optional) Apple CarPlay is a smarter, safer way to use your iPhone in the car. Apple CarPlay takes the things you want to do with your iPhone while What is Android Auto driving and puts them right on the unit. You can get directions, make calls, send and receive messages, and listen to music, all in a way that Android Auto is designed to make it easier to use apps from your phone allows you to stay focused on the road. -
Page 26: Radio
Radio Presetting Stations Manually Tune in a desired radio station you wish to store in the Radio main screen example preset memory by manual or automatic seek tuning. Touch and hold the Preset number you want to store for at least 1 second. The selected station is stored. -
Page 27: Usb Flash Drive (Optional)
USB Photo mode screen USB Flash drive (Optional) You can play back music files (MP3/WMA/AAC/FLAC/WAV), video files (MP4/AVI/WMV/MOV) and photo files (JPG/PNG/BMP) stored in a USB flash drive on the internal player of this system. WARNING It is dangerous for the driver to watch video while driving the vehicle. -
Page 28: Playback
Playback Shuffle Play (USB Audio or USB Video) Touch the (HOME) button and select USB mode. Touch and hold [ The display shows the USB mode screen. • The [ ] button displays the currently selected mode. Select your desired Shuffle mode. Touch [ Mode]. -
Page 29: Ipod Mode On Iphone (Optional)
iPod mode on Playback iPhone (Optional) Touch the (HOME) button and select iPod mode. The display shows the iPod mode screen. Touch [ ] or [ ] or to select the desired track (file). A separately sold Lightning to USB cable (KCU-471i), etc., is required. •... -
Page 30: Searching For A Music File
Searching for a Music File Shuffle Play An iPhone can contain thousands of songs. For this reason, this unit Touch [ can make various searches using the search function as shown below. • The [ ] button displays the currently selected mode. Using the Playlist/Artist/Album/Podcast/Audiobook/Genre/ Composer/Song/iTunes Radio search mode’s individual hierarchy, you Select your desired Shuffle mode. -
Page 31: Siriusxm Satellite Radio Operation (Optional)
SiriusXM Satellite Receiving Channels with the SiriusXM Tuner About SiriusXM Satellite Radio Radio Operation Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the (Optional) best sports, news, talk, comedy and entertainment. -
Page 32: Changing The Display
No./Song Title Channel No./Content Info Channel No./Channel Changing the Display Name Searching by Channel Text information, such as the channel name, artist name/feature, and song/program title, is available with SiriusXM. The unit can display this Touch [All Channels]. text information as explained below. All Channels will be displayed in a list. -
Page 33: Bluetooth Operation
About Bluetooth then connect that Bluetooth compatible device to this unit. The device name of this unit is “iLX-W650” and the initial number of the passcode Bluetooth is a wireless technology allowing communication between a is “0000. ” Also refer to the Owner’s Manual of the connected device(s). -
Page 34: Answering A Call
Answering a Call Calling An incoming call triggers the ringtone and an incoming Making a phone call using the Phone Menu call display. Entering a Phone Number to Make a Call Touch [Keypad]. The number input screen (Keypad) appears. Touch [Answer]. The call starts. -
Page 35: Using Voice Recognition Function
Touch the phone number. Using Voice Recognition function The Phone Operation screen is displayed. You can use Siri function of your iPhone or make a telephone call by using voice operation of your smartphone. • When using Apple CarPlay or Android Auto, the operation screen may differ from the screen design in the Owner’s Manual. -
Page 36: Voice Dial Function
Voice Dial Function Phone Operation Screen You can make a telephone call by using voice operation. • Connect your smartphone to the unit via Bluetooth, then set to “Hands- free” or “Both” (page 22). Touch [ ] button. Adjusting the Speech Volume You can adjust Caller Level and Mic. -
Page 37: Phone Book Function
Bluetooth Audio Phone Book Function If a Bluetooth compatible mobile phone, portable player, etc. is Phone Book screen example connected by wireless, you can play back a song (operation is controllable from the unit). • Operation may vary, depending on the Bluetooth compatible device. Bluetooth Audio main screen example Use to search by directly inputting a name or phone number with the Keypad. -
Page 38: Playback
Playback Touch the (HOME) button and select Bluetooth Audio mode. The display shows the Bluetooth Audio mode screen. Touch [ ] or [ ] to select the desired track (file). Returning to the beginning of the current file: Touch [ Fast backward the current file: Touch and hold [ Advance to the beginning of the next file:... -
Page 39: Camera Operation (Optional)
If you shift the gear lever to a position other than reverse Camera Operation (R), the monitor returns to the previous screen. • Touch the screen when the camera image is displayed, and touch the (Optional) secondary camera button to switch to the secondary camera view image. - Page 40 Distance guidance mark <Situation of the car> Actual distances The distance guides represent the ground level distance from the rear bumper. It is difficult to accurately estimate the distance to objects above ground level. In the following example, the distance to A is 0.5 m and the distance to B is 1 m.
-
Page 41: Information
About the software license of the product Supported playback sampling rates and bit rates The software installed in the product contains open-source software. See the following Alpine website for details on the open source software. MP3 (USB Flash drive) Sampling rates: 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz,... - Page 42 • Both Audio and Video files are counted if their formats are Terminology playable on this unit. Bit rate Media supported This is the “sound” compression rate specified for encoding. The higher The media that this device can play back a USB flash drive. the bit rate, the higher the sound quality, but also the larger the files.
-
Page 43: In Case Of Difficulty
• If the area you are in is a primary signal area, the antenna may properly connected, or then consult your authorized not be grounded and connected properly. Alpine dealer. - Check your antenna connections; make sure the antenna is properly grounded at its mounting location. -
Page 44: If This Message Appears
Bluetooth If this Message Appears No Bluetooth device connected • The Bluetooth audio device was not connected correctly. Various messages are displayed on the screen during operation. In - Check the settings for the unit and the Bluetooth audio device addition to the messages telling you the current status or providing and reconnect. -
Page 45: Specifications
Bluetooth SECTION Specifications Bluetooth Specification Bluetooth V4.2 Output Power +4 dBm Ave. (Power class 2) MONITOR SECTION Profile HFP (Hands-Free Profile) PBAP (Phone Book Access Profile) Screen Size 7” A2DP (Advanced Audio LCD Type Transparent type TN LCD Distribution Profile) Operation System TFT active matrix AVRCP (Audio/Video Remote... -
Page 46: Installation And Connections
When in doubt, consult your Alpine dealer. electrical wiring. Failure to take such precautions may result in fire. -
Page 47: Accessory List
Accessory List Main unit......................1 Microphone Power cable......................1 USB extension cable ..................1 PRE OUT cable....................1 Cable clamp (sold separately) Microphone ....................... 1 Owner’s Manual ..................1set Installation Installation example using the Original Caution Mounting Bracket • Do not block the unit’s fan, thus preventing air circulation. -
Page 48: Connections
Connections Vehicle Antenna Microphone (included) USB extension cable (included) To USB flash drive, iPhone or Android smartphone. REMO To amplifier or equalizer (Blue/White) REVERSE To plus side of the back lamp signal (Orange/White) lead of the car P. ANT To power antenna (Blue) PARKING BRAKE To the parking brake signal lead... - Page 49 Connect this lead to the remote turn-on lead of your amplifier or Steering Remote Control Interface Connector signal processor. To steering remote control interface. For details about connections, consult your nearest Alpine dealer. Reverse Lead (Orange/White) USB Connector Power Antenna Lead (Blue) To USB flash drive, iPhone or Android smartphone.
-
Page 50: If An Acc Power Supply Is Not Available
• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information. -
Page 51: System Example
System Example Connection of an iPhone When connecting to an iPhone with a Lightning connector USB connector iPhone with a Lightning connector (sold separately) USB extension cable (included) Lightning to USB Cable KCU-471i (sold separately) • Do not leave an iPhone in a vehicle for a long time. Heat and humidity may damage the iPhone, and you may not be able to play it again. Connection of a USB Flash Drive USB connector USB extension cable (included) - Page 52 Connection of an External Amplifier REMOTE ON Power Supply Connector CAMERA/ (Blue/White) PRE OUT REMO REMOTE ON Connector (Blue/White) (Blue/White) Power cable SUBW PRE OUT cable Amplifier for subwoofer Subwoofer (sold separately) To subwoofer input terminal To front input terminal (Red) Front speaker FRONT OUT...
- Page 53 Connection of a Rearview camera CAMERA/PRE OUT Power Supply Connector Connector Power cable Reverse Connect to the plus side of the car’s reverse lamp. (Orange/White) PRE OUT cable To Video Output terminal Camera with RCA video output (sold separately) REAR VIEW CAMERA To Video Output terminal Camera with RCA video output (sold separately)
-
Page 54: Limited Warranty
ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the telephone numbers listed below. - Page 55 N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration. Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente...
