INSTALLATION AND OPERATION MANUAL
CAUTION:
Read and follow all safety rules and
operating instructions before first
use of this product.
◄READ AND SAVE THESE INSTRUCTIONS►
Please read these instructions carefully before attempting to install, operate or service
the product described. Failure to comply with instructions could result in personal injury
and/or property damage. Please retain this booklet for future reference.
By KOBE Range Hoods
For Residential Use Only
Model No. UB4130W
1
Safety Precautions
Installation
Operation
Maintenance
Troubleshooting
Parts List
Advertisement
Table of Contents
Related Manuals for KOBE Brillia UB4130W
Summary of Contents for KOBE Brillia UB4130W
- Page 1 By KOBE Range Hoods INSTALLATION AND OPERATION MANUAL For Residential Use Only Model No. UB4130W CAUTION: Safety Precautions Read and follow all safety rules and Installation operating instructions before first Operation use of this product. Maintenance Troubleshooting Parts List ◄READ AND SAVE THESE INSTRUCTIONS►...
-
Page 2: Table Of Contents
Table of Contents General Safety Information Installation Measurement Diagram Operation Maintenance Specification Circuit Diagram Troubleshooting Parts List Disclaimer Warranty INSTALLATION INSTRUCTIONS CAUTION: Before starting, turn off the circuit breaker or remove the appropriate fuse to disconnect power source before installing fixture. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PROFESSIONAL WHO IS FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS... - Page 3 CAUTION: For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. CAUTION: To reduce risk of fire and to properly vent air, be sure to duct air outside – do not vent exhaust air into spaces within walls ceilings, attics, crawl spaces, or garages.
- Page 4 CAUTION For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. To avoid motor bearing damage and noisy and/or unbalanced fans, keep drywall spray, construction dust, etc. off power unit. For best capture of cooking impurities, your range hood should be mounted so that the bottom of the hood is 27”-30”...
-
Page 5: Installation
INSTALLATION SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING, OR SERVICING. Please read entire instruction before proceeding. Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. -
Page 6: Venting Methods
Venting Methods The ductwork system needed for installation is not included. Determine whether the hood will discharge horizontally or vertically. The hood is shipped to discharge vertically but is easily converted to horizontal discharge by swapping the discharge adapter on top of the hood with the discharge cover on the back of the hood. Use duct tape to attach the discharge adapter and discharge cover to the hood (Fig.2). - Page 7 CAUTION: • If required to move the cooking range to install the hood, turn off the power on an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE. • It is recommended that the vent system be installed before hood is installed. •...
-
Page 8: Measurement Diagram
Measure and create access opening for electrical access and ductwork. If the cabinet bottom is recessed above a support frame, wood filler strips (not included) need to be installed on the right and left sides of the cutout. Measurement Diagram Top View Back View Front View... -
Page 9: Maintenance
Lights: Press butt to turns lights on and press again to turn lights off. Each press of Light Control will cycle the light intensity through high, low, and off. Change Filter Indicator Light High / Middle / Low speed Power Maintenance SAFETY WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK, DISCONNECT FROM POWER SUPPLY... -
Page 10: Specification
SPECIFICATIONS MODEL NUMBER UB4130W COLOR White Color (powder coating) VOLTAGE 120V 60Hz, 1.5 A FAN CONTROLS 3-speed LIGHT 40W x 2 HOOD DIMENSION (W x D x H)(in.) 29-3/4” x 18-1/2” x 5-7/8” Medium High AIR CAPACITY (CFM) SONE (dB) 1.0 (40) 2.8 (55) 4.0 (60) -
Page 11: Parts List
PARTS LIST DESCRIPTION PART NO. Hood Casing SY-30SS-3-001 Light Bulb SY-30SS-5-026 Switch ( Mechanical Switch) SY-30SS-5-060 Control Board SY-30SS-5-061 Capacitor SY-30SS-5-022 Electrical Box SY-15 Bottom Casing SY-30SS-3-004 Light Cover SY-30SS-3-011 Filter SY-30SS-3-012 Safety Screen SY-30SS-5-005 Locknut SY-30SS-5-032 Squirrel Cage SY-30SS-3-013 Motor SY-30SS-5-031 6”... -
Page 12: Disclaimer
DISCLAIMER 1. CAREFULLY INSPECT ALL ITEMS FOR DAMAGES BEFORE ACCEPTING DELIVERY. NOTE ANY DAMAGES ON THE FREIGHT BILL OR EXPRESS RECEIPT. REQUEST NAME AND SIGNATURE OF THE CARRIER’S AGENT AND KEEP COPY TO SUPPORT YOUR CLAIM. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. -
Page 13: Warranty
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the... - Page 14 KOBE Range Hoods Agent as applicable, for any traveling expenses and any costs of transporting the range hood or parts...
-
Page 15: Product Registration
Any covered failure occurring within two years of original purchase arising from defective workmanship or material in manufacture will be repaired or at our option the unit will be replaced free of charge by an authorized KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection. - Page 16 KOBE Range Hoods 11775 Clark Street Arcadia, CA 91006, U.S.A. This Brillia hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a Brillia hood overseas is at your own risk and will void your warranty.
