  • Page 1: Media Converter

    MCS-2160 Media Converter User’s Manual USM Ver 1.9.1...

  • Page 2: Foreword

    Copyright Copyright © 2012 Xtramus Technologies, all rights reserved. The information contained in this document is the property of Xtramus Technologies. No part of this publication shall be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, without the prior written permission of Xtramus Technologies.

  • Page 3: Revision History

    41-43) 4. Added new subject: “Port A/B SDFR Setting” and “Port A/B Capture View”. (Page 49 and 50) 1. Updating MCS-2160 interface figure. (Page 36) 2. Updating System Information interface’s figure by adding Syslog Info. (Page 37) 3. Updating System Information interface’s figure by adding Syslog Info and descriptions.
  • Page 4 7. Adding description about Web Management or Telnet will auto log out when accessing MCS-2160 via Hyper Terminal. (Page 62) 8. Adding description and figure showing the progress bar during the upgrading of MCS-2160 or XC module via console and Tftpd32 software. (Page 67) E-mail: sales@xtramus.com ®...
  • Page 5 Telnet. (Page 64, 68, 74) 2012/09/24 1.9.1 2. Updating Media Converter Management figure and description.(Page 50-51) 3. Adding description about showing detail information of MCS-FANT on Hyper Terminal and Telnet. (Page 68, 74) E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 6: Table Of Contents

    Foreword ............................2 Revision History ..........................3 1. MCS-2160 Overview ........................8 1.1. General Descriptions of MCS-2160...................8 1.2. Features, Key Advantages, and Main Applications of MCS-2160 ........9 1.3. MCS-2160 Functions Overview ..................10 1.3.1. MCS-2160 Outer Case ....................10 1.3.2. MCS-2160 Front Part ....................11 1.3.3.
  • Page 7 3.1.6. MCS-2160 Management Webpage – Language............65 3.2.1. HyperTerminal Settings for MCS-2160...............67 3.2.2. MCS-2160 HyperTerminal Commands ...............67 A. MCS-2160 HyperTerminal Command – system ............68 B. MCS-2160 HyperTerminal Command – ip ..............72 C. MCS-2160 HyperTerminal Command – cls ..............72 D. MCS-2160 HyperTerminal Command – logout ............72 3.3 Managing MCS-2160 with Telnet ..................73...

  • Page 8: Mcs-2160 Overview

    MCS-2160 media converter chassis provides an easy-to-access Management Webpage, allowing users to view system status, counters, upgrading firmware/FPGA and network statistics. Moreover, XC-CASC module card allows you to cascade multiple MCS-2160 chassis for managing these chassis at the same time.

  • Page 9: Features, Key Advantages, And Main Applications Of Mcs-2160

    Multiple MCS-2160 chassis can be cascaded for system management Replaceable power modules for AC & DC power Supports Link Loss Forwarding Optional Fan Tray (MCS-FANT-05) which can be placed under MCS-2160 chassis for ventilation Key Advantages Fast connection with multi-function...

  • Page 10: Mcs-2160 Functions Overview

    1.3. MCS-2160 Functions Overview 1.3.1. MCS-2160 Outer Case MCS-2160’s outer case consists two parts: Front Part and Back Part. The figure above shows the outer case of MCS-2160. Outer cases of other MCS-2160 are quite the same and can be related.

  • Page 11: Mcs-2160 Front Part

    1.3.2. MCS-2160 Front Part As mentioned in “1.3.1. MCS-2160 Outer Case”, MCS-2160 has 16 slots for installation of media converter module cards and 3 slots comprising a Fan, CASC and Management module card installed. Please see the sections down below for more detailed information/specification for MCS-2160 and the module cards.

  • Page 12: Module Cards

    XC-8S23 Converter Cards can be installed in MCS-2160 Module Cards XC-8S82 Slot 2~17 and support hot-swap. XC-8S33 XC-8S83 Please see the sections down below for more detail information regarding to MCS-2160 Module Cards. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 13: System Module Cards

    1.3.3.1. System Module Cards A. System Module Card – XC-SFAN The XC-SFAN comes with your MCS-2160 chassis, and shall be installed on the Fan slot located on the far left side of MCS-2160 chassis. This module card provides ventilation for the MCS-2160 chassis.

  • Page 14: System Module Card - Xm-M667

    To configure MCS-2160 on your PC (Telnet or Hyper Terminal), please connect a 2.5mm Phone Jack to RS232 between your PC and Console Port of MCS-2160, where the 2.5mm Phone Jack end must be plug in the Console Port of MCS-2160 and the RS232 end must be connect to your PC. Interface Ports One 2.5mm Phone Jack Port for managing MCS-2160 via HyperTerminal...

  • Page 15: System Module Card - Xc-Casc

    C. System Module Card – XC-CASC The XC-CASC comes with your MCS-2160 chassis, and shall be installed on the Casc slot located on the right side of MCS-2160 chassis (next to XC-M667 module card). This module card allows you to cascade multiple MCS-2160 chassis.

  • Page 16: Media Converter Module Cards

    Error occurred when booting XC-7S81. Green ON Port A/B is connected. Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 17: Media Converter Module Card - Xc-8S22

    Error occurred when booting XC-8S22. Yellow ON Green ON Port A/B is connected. Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 18: Media Converter Module Card - Xc-8S23

    Error occurred when booting XC-8S23. Port A/B is connected. Green ON Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 19: Media Converter Module Card - Xc-8S33

    Error occurred when booting XC-8S33. Green ON Port A/B is connected. Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 20: Media Converter Module Card - Xc-8S82

    Error occurred when booting XC-8S82. Port A/B is connected. Green ON Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 21: Media Converter Module Card - Xc-8S83

    Error occurred when booting XC-8S33. Green ON Port A/B is connected. Green Blinking Port A/B is transmitting/receiving data. User-defined LED ▇ User-defined LED ▲ Note: All LEDS will be off when upgrading FPGA/Firmware E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 22: Mcs-2160 Rear End

    1.3.4. MCS-2160 Rear End As mentioned in “1.3.1. MCS-2160 Outer Case”, MCS-2160’s rear end includes 3 different slots for installation of a DC module, AC module and a Fan module. Please see the sections down below for more detailed information/specification for MCS-2160 and modules.

  • Page 23: Xc-Rfan Fan Module

    The XC-RFAN consists of two fans as shown in the figure below. After installing XC-RFAN, the Management Web Page will show the operation of XC-RFAN, please see the 3.1.4. MCS-2160 Management Webpage – Management for more information about showing the operation of XC-RFAN.

  • Page 24: Xcp-Ac-300 & Xcp-Ac-100

    The Power Jack of XCP-AC-300 & XCP-AC-100 is Male IEC 320 Receptable. To activate XCP-AC-300 & XCP-AC-100, just turn on/off the O/I button after connecting a power source cable in Male IEC 320 Receptable. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 25: Optional Fan Tray - Mcs-Fant-05

    1.3.5. Optional Fan Tray – MCS-FANT-05 Set MCS-FANT-05 on the base of MCS-2160, with dimension of 441 mm x 310 mm x 29 mm. XC-SFAN’s Port A and Port B are designed to provide power source and gather information for MCS-FANT fan tray.
  • Page 26 MCS-FANT contains LEDs that represent its ten fans. The figure down below shows how these fans are numbered. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 27: Mcs-2160 Installation

    MCS-2160 is a chassis with 16 slots for installation of media converter modules. Installing MCS-2160 is very easy and simple: all you have to do is to plug the proper fiber/UTP cables into MCS-2160 ports like a general Ethernet switch without any extra configurations. However, selecting the proper physical media and applications in your network environment is crucial when installing MCS-2160.

  • Page 28: 10Gbase-R (Optical Fiber)

    2.1.2. 10GBASE-R (Optical Fiber) 10GBASE-R is 10Gbps Ethernet connection that based on IEEE802.3ae. It uses fiber as transmission media with different specification of fiber, connector and transceiver. MCS-2160 uses two standards, 10GBASE-LR and 10GBASE-SR. 10GBASE-SR 10GBASE-SR ("Short Range") uses 64B/66B encoding and 850 nm wavelength lasers. It is designed to support short distances over deployed multi-mode fiber cabling, it has a range of between 26 meters (85 ft) and 82 meters (270 ft) depending on cable type.
  • Page 29 XC media converter module and are capable of converting signals between optical data flow and electronic data flow. For different transmission purpose, the component inside SFP+ form factor can be 10BASE-LR or 10BAST-SR mode. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 30: Hardware Installation

    2.2. Hardware Installation Please follow the steps shown below for a better understanding on how to install hardware in MCS-2160. 2.2.1. Bracket installation Steps for installing a Bracket in MCS-2160 First of all, you must have an Empty Slot for the Installation of a Bracket.
  • Page 31 Steps for installing a Bracket in MCS-2160 After attaching the Bracket’s Latch on the internal face of Chassis’ Latch, let this point be a fix central rotation point and push the bottom part of Bracket into MCS-2160. Lock the Captive Screw into the MCS-2160 to fix the Bracket into MCS-2160.

  • Page 32: Module Cards Installation

    2.2.2. Module Cards Installation Steps for installing a Media Converter Module Card in MCS-2160 Aim the border side of a Media converter Module Card with the MCS-2160 internal slide road, and push this Module Card into MCS-2160. Please, make sure if the Media...

  • Page 33: Power Module

    Steps for installing a Media Converter Module Card in MCS-2160 Lock the Captive Screw into the MCS-2160 to fix the Module Card into MCS-2160. 2.2.3. Power Module 2.2.3.1. XCP-DC-300 & XCP-DC-100 Steps for installing a XCP-DC-300 & XCP-DC-100 Installing a XCP-DC-300 &...

  • Page 34: Xcp-Ac-300 & Xcp-Ac-100

    Steps for installing the XC-SFAN The XC-SFAN comes with your MCS-2160 chassis, and shall be installed on the Fan slot located on the far left side of MCS-2160 chassis. This module card provides ventilation for the MCS-2160 chassis. Also, XC-SFAN’s CTRL + PWR and...

  • Page 35: Xc-Rfan

    CTRL + PWR and PWR ports will seriously damage the MCS-2160. *Note: In a rack mount installation of MCS-2160, the distance between two MCS-2160 must unless be 2U (9 cm) for a better efficiency of the MCS-FANT-05. E-mail: sales@xtramus.com ®...

  • Page 36: Mcs-2160 Management

    3. MCS-2160 Management You can configure MCS-2160’s settings and view statistics generated while performing media converting with MCS-2160 by connecting MCS-2160 and PC to the same network via an RJ45 cable, and accessing MCS-2160’s settings/statistics with PC’s web browser. Please see the sections down below for more information regarding to MCS-2160 management.

  • Page 37: Accessing Mcs-2160 Management Webpage

    To access MCS-2160’s management webpage, please open your web browser, and type in MCS-2160’s default IP address (192.168.1.8) in web browser’s URL field as shown in the figure on the right side. If you’ve changed MCS-2160’s IP address, please input the IP address you’ve changed to instead.

  • Page 38: Mcs-2160 Management Webpage Overview

    MCS-2160’s IP address, SNMP, or user accounts. Setting Options • Maintenance: This option allows you to save system settings, reboot MCS-2160, and reset all MCS-2160’ settings to default value. • Language: You can set the Management Webpage language as English, Chinese Simplified, Chinese Traditional, Japanese or Korean.

  • Page 39: Mcs-2160 Management Webpage - System

    Normal: for users that purchased the License of MCS-2160. • Evaluation: for users that are only testing the MCS-2160. Update Valid Date The time limit for using the MCS-2160. Syslog Information Syslog Server IP This field displays the IP address for connection with 3CDaemon.

  • Page 40: Fan Tray Information

    Update Fan Tray Firmware Click the Browse… button to choose the Firmware update files, and click the Send button to start updating your Fan Tray firmware. *Note: The Fan Speed will auto-refresh during the operation of the MCS-2160. E-mail: sales@xtramus.com ®...

  • Page 41: Mcs-2160 Management Webpage - Management

    3.1.4. MCS-2160 Management Webpage – Management There are 11 options available for Management, which includes: • IP Settings: Allows you to set how MCS-2160 will acquire its IP, subnet mask, and gateway addresses. Also, you could input these addresses manually here. •...

  • Page 42: Syslog Settings

    Syslog Receiver IP is 192.168.1.17 . Apply Apply the changes you’ve made here. Before accessing Syslog Configuration for MCS-2160, please download and install the 3CDaemon software. Please refer to the interface of 3CDaemon shown below: 3CDaemon Please choose the Syslog Server option from the left side option of the 3CDaemon interface.
  • Page 43 Configuration window. In this 3CDaemon Configuration window, you may modify settings of: Directory for syslog, Who can log to this and Log messages to. Click the button of Stop/Start to enable or unable 3CDaemon to receive signals from your MCS-2160. E-mail: sales@xtramus.com ®...
  • Page 44 Click the Clear list option to delete all the records of Time/IP Address/Msg Type/Message of each module shown in the right field. Choose the View Log files to open the saved log file from your PC. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES...

  • Page 45: User Settings

    C. User Settings For issues regarding to system security, MCS-2160 has 2 different user security levels, which are: • Administrator: User with Administrator privilege can change MCS-2160 system settings and view system information/statistics. • Guest: User with Guest privilege can only view system information/statistics.

  • Page 46: Snmp Settings

    Apply the changes you’ve made here. By clicking the Download button, you can save your SNMP Download MIB File Settings on your PC or search on Internet for a program to run the SNMP Settings. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 47: Time Settings

    Save the settings made from Set Device Time. Set Device Time Set your MCS-2160 date and time manually. Set your MCS-2160 date and time as your current connected Get Computer Time computer time. *Note: for Time and Date settings please install battery on your XC-M667 module card.

  • Page 48: Mail Settings

    F. Mail Settings Mail Configuration Enable You can able or disable your MCS-2160 mail warning function. POP3 Server Address Sets your POP3 server address. E-mail Box Account Sets the e-mail account for your MCS-2160. E-mail Box Password Sets the e-mail password for your MCS-2160.

  • Page 49: Safety Settings

    Enable You can able or disable the Safety Configuration function. Your MCS-2160 will shutdown when it reach the temperature (60, 65, Temperature 70, 75, 80) that you set here to avoid any damage to your MCS-2160 threshold system. Apply Apply the changes you’ve made here.

  • Page 50: Media Converter Management

    Above shows the Media Converter Management option interface. You can set the Media Converter of the same LAN of your MCS-2160 to be displayed by choosing Create new user button, and than choose the Go button to apply your settings. For more details, please see the table below:...
  • Page 51 Media Converter Counter Scroll down this field to select others Media Converter that is connected to the same LAN as your MCS-2160 to show theirs respective Counter. Click the Clear button to clean the Network Port Statistics of the Media Converter’s Counter.

  • Page 52: Chassis Management

    10-17. Shows the status of XCP-DC-300 & XCP-DC-100 and XCP-AC-300 & XCP-AC-100, if the left one turns green, than indicates that the MCS-2160 is power on by XCP-AC-300 or XCP-AC-100; if the right one turns green, than indicates that the MCS-2160 is power on by XCP-DC-300 or XCP-DC-100.
  • Page 53 After few seconds of the installation of the module card, the Sys / Pwr LED will turn green, and the port of the module card will turn in black, this indicates respectively that the module card is ready for use and the port is available for connecting a cable. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES...
  • Page 54 Allows you to turn on / off and setting the Port A/B USC Port A/B USC Allows you to see/ refresh/ clean the Port A/B USC table Note: The XC-8SXX series don’t support Port Configuration function. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 55: Information

    You can view the wave length of your transceiver inserted in the Port A/B Wavelength media converter module cards. *Note: The Temperature may auto-refresh during the operation of the MCS-2160. The Port A/B Factory and Wavelength will auto-refresh if you change the optical transceiver of your Port A/B. License Information This field displays the device type of your MCS-2160: •...

  • Page 56: Port A/B Ddmi

    Warning Maximum Tx Power supported. Shows the Current Rx Power in mW, and the Maximum, Minimum Rx Power (dBm) and Warning Maximum Rx Power supported. *Note: The DDMI’s parameter will auto-refresh during the operation of MCS-2160. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES...

  • Page 57: Counter

    Counter Click the Counter to pop up the Port Counter Statistics window as shown above. The Port Counter Statistics can display statistics reports of MCS-2160’s Port A/B. Port Counter Statistics Refresh Refresh the configuration webpage and update the latest statistics.

  • Page 58: Upgrade

    Update F/W (Firmware) Click the Browse… button to choose the firmware file you would like to Browse… upgrade. MCS-2160’s firmware files are in the format of “*.bin”. Send Click this button to start upgrading MCS-2160’s firmware. Update FPGA Click the Browse…...

  • Page 59: Power Control

    Turns on/off the USC function. USC Type The types of USC includes: DA, SA, VID, MPLS, DIP, SIP, DPort, Sport. USC Value Allows you to input USC number. Apply Apply the changes you’ve made here. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 60: Port A/B Universal Stream Counter

    Clear all statistics displayed in the table. Clear *Note: The results of each parameters will auto-refresh during the operation of MCS-2160. h. Link Loss Forwarding (LLF) Clicking the Link Loss Forwarding option will pop up the interface shown below, if you select Enable, you will enable the Link Loss Forwarding function of your MCS-2160.

  • Page 61: Module Card Options_Xc-7S81

    Module Card Options_XC-7S81 For XC-7S81 module card management function, it includes Port Configuration function. The XC-7S81 module card management doesn’t include the Port A /B USC Setting and Port A/B USC function. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...
  • Page 62 Flow Turn On the Flow Control function. Control Setting Turn Off the Flow Control function. Clicking on Apply of Media Type Setting and Flow Control Setting to respectively Apply save each configuration. E-mail: sales@xtramus.com ® XTRAMUS TECHNOLOGIES Website: www.Xtramus.com...

  • Page 63: Chassis Overview

    K. Chassis Overview The Chassis Overview will display the parameters of all the MCS-2160’ slots, please refer to the figure above. If you click the refresh button, you can refresh all the parameters. All the cascaded MCS-2160’ slots will be displayed on the same interface, in which each MCS-2160 will be named in order of Chassis 0, Chassis 1, …, Chassis 9.

  • Page 64: Mcs-2160 Management Webpage - Maintenance

    MCS-2160’s firmware files are in the format of “*.bin”. Send Click this button to start upgrading MCS-2160’s firmware. *Note: For updating your MCS-2160, please update first all the MGM_RTC_v1.1b002 version, and than update to the MGM_RTC_v1.1b003 or newest. E-mail: sales@xtramus.com ®...

  • Page 65: System Reboot

    C. System Reboot System Reboot You can reboot MCS-2160 by clicking the “Reboot” button. Please note that all Reboot unsaved settings will be lost after system reboot. D. Factory Defaults Factory Defaults You can set all MCS-2160’s settings to the default value by clicking the Restore “Restore”...
  • Page 66 Port with PC’s RS-232 Port via a 2.5mm Phone Jack to RS-232 cable as shown in the figure above. Please Note: If you log in the Hyper Terminal to access the MCS-2160 system, the previous accessed Web Management or Telnet will automatically log out from the MCS-2160 system.

  • Page 67: Hyperterminal Settings For Mcs-2160

    Establishing Connection with MCS-2160 1. Input a name for this connection, such as MCS-2160, and also select an icon for this connection. Click “OK” to continue. 2. Select the COM port of PC for this connection. Click “OK” to continue.

  • Page 68: Mcs-2160 Hyperterminal Command - System

    *Note1: Please access the “Counter” by entering “sys show chassis”. Entering “0” to access the MCS-2160, than enter the number of the slot of the module card that you want to analysis, and please confirm the commands for specific analysis.
  • Page 69 A. MCS-2160 HyperTerminal Command – system (Continue) Command Descriptions – system show Shows the status of snmp v1/v2/v3. Type command sys snmp readcommunity private or public to readcommunity set this option as private or public. Type command sys snmp writecommunity private or public to writecommunity set this option as private or public.
  • Page 70 A1. MCS-2160 HyperTerminal Command – system chassis Please type sys show chassis command to display the status of your MCS-2160 and XC module cards, when you cascade numerous MCS-2160, the number of total chassis cascaded will be shown as the figure above on Total chassis number.
  • Page 71 While the system is updating your MCS-2160 or XC module cards’ firmware, the Tftpd32 software will pop up a progress bar as shown below: When the Tftpd32’s progress bar is finished, the Hyper Terminal window will start to upgrade your...

  • Page 72: Mcs-2160 Hyperterminal Command - Ip

    The ip show command allows you to view information of MCS-2160’s IP configuration. status The ip status command allows you to view information of MCS-2160’s IP status. The ip mode dhcp command allows you to set MCS-2160’s IP acquiring mode dhcp to DHCP, allowing MCS-2160 to acquire IP automatically from DHCP server.

  • Page 73: Managing Mcs-2160 With Telnet

    *Note: If you change MCS-2160’s user name and password with MCS-2160’s configuration webpage, please log in with the new user name and password here. Please Note: If you log in the Telnet to access the MCS-2160 system, the previous accessed Web Management will automatically log out from the MCS-2160 system.

  • Page 74: Mcs-2160 Telnet Command - System

    *Note1: Please access the “Counter” by entering “sys show chassis”. Entering “0” to access the MCS-2160, than enter the number of the slot of the module card that you want to analysis, and please confirm the commands for specific analysis.
  • Page 75 A. MCS-2160 HyperTerminal Command – system (Continue) Command Descriptions – system show Shows the status of snmp v1/v2/v3. Type command sys snmp readcommunity private or public to readcommunity set this option as private or public. Type command sys snmp writecommunity private or public to writecommunity set this option as private or public.
  • Page 76 When you cascade numerous MCS-2160, the number of total chassis cascaded will be shown as the figure above on Total chassis number. In this example of the figure above, we cascaded 2 MCS-2160 together which is Chassis ID 00 and 01, the number than is shown as Total chassis number 02.

  • Page 77: Mcs-2160 Telnet Command - Ip

    The ip show command allows you to view information of MCS-2160’s IP configuration. status The ip status command allows you to view information of MCS-2160’s IP status. The ip mode dhcp command allows you to set MCS-2160’s IP acquiring mode dhcp to DHCP, allowing MCS-2160 to acquire IP automatically from DHCP server.

  • Page 78: Mcs-2160 General Specifications

    4. MCS-2160 General Specifications Model MCS-2160 Slot 16 Slots for Installing XC Series Module Cards Dimension 441 mm x 310 mm x 88 mm Temperature Operating: 0 C ~ 40 C (32 F ~ 104 Storage: 0 C ~ 50...
  • Page 79 Note: Information and specifications contained in this document are subject to change without notice. All products and company names are trademarks of their respective corporations. Copyright © 2012 Xtramus Technologies, all rights reserved. Do not reproduce, redistribute or repost without written permission from Xtramus. Doc # USM_MCS-2160 _V1.9.1_ENG_20120926 E-mail: sales@xtramus.com ®...
