Summary of Contents for Xtramus XG2
-
Page 1: User Manual
User Manual USM: V1.0... - Page 2 The information contained in this document is subject to change without notice and does not represent a commitment on the part of Xtramus Technologies. The information in this document is believed to be accurate and reliable, however, Xtramus Technologies assumes no responsibility or liability for any errors or inaccuracies that may appear in the document.
-
Page 3: Revision History
REVISION HISTORY Date FPGA History Version Version Version Feb, 2009 First version ® E-mail: sales@xtramus.com XTRAMUS TECHNOLOGIES Website: www.Xtramus.com... -
Page 4: Table Of Contents
Application for University ..................14 3.3.2 Application for Online Game Company..............15 3.3.3 Application for Home User ..................16 4. Additional Function ..................18 Loopback......................18 4.1.1 Operation via Console Port..................18 5. Maintenance ....................21 ® E-mail: sales@xtramus.com XTRAMUS TECHNOLOGIES Website: www.Xtramus.com... -
Page 5: General Description
DSLAM. Data stream can be transmitted with copper wire cable easily and cost effectively afterward. XG2 is a two ways converter with RJ-45 and SFP+ connector. Data stream can be converted bi-directionally from 10GBASE-R to 10GBASE-T and vice versa. With full duplex Wirespeed forwarding capability between these two media, XG2 bring you the best and simple solution for the 10Gbps Ethernet conversion between media of copper wire and fiber. -
Page 6: Features
Ethernet traffic. • Subsidiary device for test on 10Gbps Ethernet switch with 10GBAST-T and/or 10GBASE-R ports. • High-speed 10Gbps fiber/copper wire converter without packet loss. • Enable loopback function via console port. ® E-mail: sales@xtramus.com XTRAMUS TECHNOLOGIES Website: www.Xtramus.com... -
Page 7: Appearance
2.1 Front and Rear Side There are holes with fan for ventilation Ventilation Hole 2.2 Top side As the graph above, the name plate of XG2 2.3 Right side Right side has ports that connect with physical transmission media. 10G Base-T Port... - Page 8 Note: For network flow conversion, the media speed of two ends has to be symmetrical; otherwise, packet loss happens during conversion. Hence, the connection speed of copper UTP port A must be 10Gbps connection, for the conversion of 10Gbps SFP+ connection. 10M/100M/1000Mbps UTP connection is not applicable to XG2. LED Status Type...
-
Page 9: Left Side
Power Socket 12V DC Plug power from DC 12V adapter. Note: XG2 media converter has to convert and transmit data flow for both copper and fiber connection that has larger power consumption. Please do use the power adapter that comes with XG2 to prevent damage. -
Page 10: Procedure Of Installation
3. Procedure of Installation This chapter tells you how to install XG2 in your network environment. XG2 is an equipment that administrator only has to plug fiber/cable and then it works, as easy as general Ethernet switch without extra configuration. -
Page 11: 10Gbase-R (Optical Fiber)
600 MHz. It has better performance than Cat 6a. 3.1.2 10GBASE-R (Optical Fiber) 10GBASE-R is 10Gbps Ethernet connection that based on IEEE802.3ae. It uses fiber as transmission media with different specification of fiber, connector and transceiver. XG2 uses two standards, 10GBASE-LR and 10GBASE-SR. 10GBASE-SR 10GBASE-SR ("short range") uses 64B/66B encoding and 850 nm wavelength lasers. -
Page 12: Connection Of Utp Cable And Optical Fiber
RJ-45 Connector Plug into 3.2.2 10GBASE-R (Optical Fiber) The connection of optical fiber can be departed to 4 sections LR or SR Mode Transceiver Optical Fiber Fiber Connector SFP+ Transceiver Connect Connect Plug into ® E-mail: sales@xtramus.com XTRAMUS TECHNOLOGIES Website: www.Xtramus.com... - Page 13 For different transmission purpose, the component inside SFP+ form factor can be 10BASE-LR or 10BAST-SR mode. When SFP+ transceiver is plugged into the XG2, the LED of SFP+ is Amber. If the inserted SFP+ transceiver is attached by a fiber with LC connector with going on signaling, the LED becomes Green.
- Page 14 The size and specification of transceiver are independent from the Ethernet protocol transmitted and received inside fiber. Hence, there is no problem for the fiber connection between XG2's SFP+ transceiver (connector) and XFP transceiver (connector) that is plugged at other device.
-
Page 15: Application For Your Network
C: XG2 is located at the computer center of university. D: After the conversion of XG2, expensive equipment for transmitting/receiving network data via optical fiber is not required afterward. E: Full 10Gbps Ethernet Switch may beyond your budget or it is not available. Some 1Gbps Switch reserves a swappable slot for the upgrade of future technology. -
Page 16: Application For Online Game Company
3.3.2 Application for Online Game Company For ISP or online game company, XG2 may also save lots of money for cabling their control room. ISP runs lots of customer's service such as e-mail server, web server or any co-located network services in the control room. -
Page 17: Application For Home User
(Technologies such as VDSL provide high speed, short-range link are used often in FTTx service) E: Different rooms of home or different compartments in the same building. F: XG2 can be located at any place that near or away from building, depending on the service to home users. ®... - Page 18 Gigabit switch or media converter to copper wired destination. Depends on the bandwidth required for client, ISP can configure a XG2 media converter between the connection of light blue and dark blue line in the graph. With 10G Ethernet conversion between fiber and copper wire, ISP can provide heavyweight bandwidth service that is closer to the client without spending too much cost.
-
Page 19: Additional Function
XG2 4.1.1 Operation via Console Port After connecting the COM port of PC to Console port of XG2 via Console cable, power on the PC and configure the PC parameters as following path of Windows (by using Windows Hyper Terminal software): ®... - Page 20 Accessories Communications Hyper Terminal • Input a name for this connection, such as XG2, and also select an icon for this connection. • Select the COM port of PC for this connection. Generally, it is COM1. • Configure the parameter of COM port as below, 38400, 8, None, 1, None ®...
- Page 21 • Press "Enter" key to build connection and system enter into the main windows of XG2 Console Program Input the number as command from keyboard and the console program shows the result. • Input 1 to enable Line Loopback. For the function of Loopback, please refer to 4.1 Loopback •...
-
Page 22: Maintenance
5. Maintenance XG2 is a media converter that configuration of its function is not required in most of case. Please locate it at good ventilation place with suitable temperature and humility is required. • Temperature: Operating: 0℃ ~ 40 ℃ (32℉ ~ 104℉) Storage: 0℃...
