  • Page 1 User Guide Onyx EZ Radio & Vehicle Kit...

  • Page 2: Table Of Contents

    Onyx EZ Functions . . . . . . . . . . . . . . . . . . .7...

  • Page 3: Introduction

    Introduction Features Congratulations on your purchase of the Onyx EZ with Vehicle Kit! The Onyx EZ has these exciting features to enhance your overall experience: • Hear SiriusXM through your existing vehicle radio with easy, do-it- yourself installation . • View artist name, song title, and channel information on the large display .

  • Page 4: Safety And Care Information

    Introduction Safety and Care Information IMPORTANT! Always read and understand all the instructions to avoid injury to yourself and/or damage to your device . SiriusXM Canada Inc . disclaims all responsibility for damage from data loss due to breakdown, repair, or other causes .
  • Page 5 Introduction Warning! • Opening the case may result in electric shock . • If the liquid crystal fluid comes in contact with your skin, wipe the skin area with a cloth and then wash the skin thoroughly with soap and running water .

  • Page 6: What's In The Box

    Introduction What’s in the Box? menu jump Dash Mount direct PowerConnect Vehicle Dock Onyx EZ Radio Aux In Cable Vent Mount and Extended Vent Clamps Antenna Cable Routing Adapter Screws (4) Antenna & Dash Mount Magnetic Mount PowerConnect Alcohol Preparation Pads...

  • Page 7: Onyx Ez Functions

    Introduction Onyx EZ Functions Up and Down Arrows Left and Right Arrows Scroll through lists and Search for channels by preview channels; also category . Power Button highlight menu options . Turn radio on and off . Select Button Press to confirm selection for channel and menu items .

  • Page 8: Powerconnect Vehicle Dock

    Introduction PowerConnect Vehicle Dock Colour-Coded Connections The colour-coded PowerConnect Vehicle Dock makes it simple to connect . Just match the colours on the cable ends to the colours on the dock to see what goes where . Rear View AUDIO ANT (Silver) PWR (Red) FM (Blue)
  • Page 9 Introduction Wire Guide The PowerConnect Vehicle Dock has a wire guide at the top rear that can help you to organize the cables and wires connected to the dock . If you need to bring a cable or wire from one side of the dock to the other, utilize the wire guide by looping the cable though the wire guide as shown .

  • Page 10: Vehicle Installation

    . Several examples of the Onyx EZ mounted in a vehicle are shown: A is the on dash method using the Dash Mount, and B is the vent clip method using the Vent Mount .
  • Page 11 Vehicle Installation Option 3 Option 4 Option 5...

  • Page 12: Radio

    Follow the instructions on the next several pages for the mounting method you have selected . NOTE! The PowerConnect Vehicle Dock included with Onyx EZ is compatible with the T-slot style Dash and Vent Mounts . If you have an existing Dash Mount or Vent Mount in your vehicle, you can continue to use it with this dock, and skip this step .
  • Page 13 Vehicle Installation vehicle . When the orientation is correct, tighten the knob . Knob Adhesive Foot Dock Mounting Plate 4 . Attach the Dash Mount to the PowerConnect Vehicle Dock using the 4 provided screws . 5 . Before you attach the Dash Mount to the dash, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock .
  • Page 14 1 . Locate a vent with horizontal louvers Extended Vent Clamps sturdy enough to hold your PowerConnect Vehicle Dock and Onyx EZ Radio . 2 . If the vent louvers in your vehicle are recessed, you may need to use the longer...
  • Page 15 Vehicle Installation 3 . Attach the Vent Mount to the PowerConnect Vehicle Dock using the 4 provided screws . 4 . Before you attach the Vent Mount to the vent, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock .

  • Page 16: Antenna

    Vehicle Installation Step 3: Mount the Magnetic Mount Antenna The Magnetic Mount Antenna contains a strong magnet which will stick to any metal part of your vehicle, but will not damage the vehicle . To install the Magnetic Mount Antenna: 1 .
  • Page 17 Vehicle Installation SUV: We recommend mounting the antenna at the rear of the roof as shown . Convertible: We recommend mounting the antenna at the leading edge of the trunk as shown . Pickup Truck: We recommend mounting the antenna just above the front windshield as shown .
  • Page 18 Vehicle Installation 3 . If you are installing the antenna at the roof edge, or hood edge, install the Cable Routing Adapter to direct the antenna cable downward . With Cable Without Cable Routing Adapter Routing Adapter Installed Installed Cable Routing Adapter orientation Place the antenna wire Slide the Cable Routing...
  • Page 19 Vehicle Installation 4 . Place the antenna in the location you selected . Follow the Tips and Cautions shown on the next several pages . TIP! Mount the antenna on the roof (for most vehicles) or trunk (for convertibles) where it has a clear view of the sky in all directions .
  • Page 20 Vehicle Installation CAUTION! Don’t mount the antenna inside the vehicle, for example, on the dashboard . CAUTION! Don’t mount the antenna on any of the vehicle’s front, back or side pillars . CAUTION! Don’t mount the antenna close to a roof rack . Adjust the rack so it’s further away from the antenna or move the antenna closer to the center of the roof .
  • Page 21 Vehicle Installation CAUTION! Don’t mount the antenna close to another antenna . Mount it at least 7 .5 cm (3 inches) away .

  • Page 22: Step 4: Route The Magnetic Mount

    Vehicle Installation Step 4: Route the Magnetic Mount Antenna Cable Before you begin routing the antenna cable, read these general instructions for how to route and hide the antenna cable . Then route your antenna cable according to the instructions which follow for your specific type of vehicle . Use a blunt plastic putty knife, a credit card, a plastic knife, or a similar blunt tool to lift the rubber window moulding...
  • Page 23 Vehicle Installation Route cable out from under rear windshield moulding and tuck into weatherstripping around trunk opening Avoid sharp bends by running cable through Pull weatherstripping weatherstripping for several inches from trunk opening Tuck cable into weatherstripping. Route cable through weatherstripping several inches to avoid sharp bends Pull cable out of weatherstripping and route through trunk to cabin...
  • Page 24 Vehicle Installation Bring cable out of weatherstripping and into trunk Route cable along trunk wall and into cabin through gap or conduit, along existing wiring harness Route cable along trunk wall and into cabin...
  • Page 25 Vehicle Installation Use a blunt plastic putty knife or similar blunt tool to lift edge of interior trim and tuck cable Route cable under under trim. Continue trim or upholstery towards front of vehicle Continue routing cable under trim or carpet towards front of vehicle Route cable from trunk under interior trim, into...
  • Page 26 Vehicle Installation Continue routing cable under carpet or console to radio location Coil excess cable under Pull carpet carpet or mat or mat back Bring cable out from trim Bring cable out from trim and route under carpet to dashboard or console TIP! Always be careful to include enough slack in your cable to accommodate open doors or trunk lids .
  • Page 27 Vehicle Installation • Sedan/Coupe With Antenna Placed at the Rear of the Roof: 1 . Feed the antenna cable from the antenna underneath the rubber molding around the rear window . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the rear window and tuck the antenna cable underneath the molding .

  • Page 28: Step 5: Connect The Magnetic Mount

    Vehicle Installation careful not to crimp or cut the cable . 5 . Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console . Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls .

  • Page 29: Antenna And Powerconnect Power

    Vehicle Installation • Sedan/Coupe With Antenna Placed at the Front of the Roof: 1 . Feed the antenna cable from the antenna underneath the rubber molding around the windshield . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath the molding .

  • Page 30: Step 5: Connect The Magnetic Mount

    Vehicle Installation • SUV: 1 . Feed the antenna cable underneath the rubber weather stripping of the rear tailgate window/door and route the cable along the rear hatch . Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping . Pull the cable out from weather stripping and route it into the cabin under the interior trim .
  • Page 31 Vehicle Installation • Convertible: 1 . Bring the antenna cable from the antenna into the trunk at the front edge of the trunk lid . Keep any bends in the cable loose . Tape or tie the cable along the inside of the trunk lid to the trunk lid hinge strut .

  • Page 32: Step 5: Connect The Magnetic Mount

    Vehicle Installation connector of the dock . 6 . Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter” on page 34 . • Pickup Truck: 1 . Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath it .

  • Page 33: Step 5: Connect The Magnetic Mount

    Vehicle Installation 5 . Bring the end of the cable out at the PowerConnect Vehicle Dock location . Leave yourself enough cable so you can easily connect it to the antenna connector of the dock . 6 . Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter”...

  • Page 34: Adapter

    Vehicle Installation Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter 1 . Plug the Magnetic Mount Antenna into the silver ANT connector on the AUDIO FM OUT PowerConnect Vehicle Dock . 2 . Insert the PowerConnect Power Adapter into your vehicle’s cigarette lighter or power adapter socket .

  • Page 35: Step 6: Connect The Audio

    . Cassette Adapters are sold separately and can be purchased from an electronics retailer, or go to siriusxm .ca . • Option 3: Good: Use the PowerConnect feature in the Onyx EZ . PowerConnect plays the audio through your vehicle’s FM radio .
  • Page 36 . 4 . Insert your Onyx EZ into the dock . 5 . Power on your Onyx EZ by pressing the Power button . 6 . Be sure the vehicle is outside and the antenna has a clear view of the sky . Verify that you are menu receiving the signal .
  • Page 37 . 7 . Ensure Onyx EZ is tuned to channel 1 . Upon power up, Onyx EZ should tune to channel 1 by default, when it’s not yet activated . If it’s not on channel 1, refer to “Listening to Satellite Radio”...
  • Page 38 . 3 . Insert the dock into the mount . 4 . Insert your Onyx EZ into the dock . 5 . Power on your Onyx EZ by pressing the Power button .
  • Page 39 Dash or Vent Mount . Then the installation is complete . 11 . The audio level output of the Onyx EZ can be increased or decreased as necessary to match the audio levels of other sources in your vehicle .
  • Page 40 Option 3: PowerConnect Installation Instructions 1 . Insert the dock into the mount . 2 . Insert your Onyx EZ into the dock . 3 . Power on your Onyx EZ by pressing the Power button . 4 . Be sure the vehicle is outside and the antenna has a clear view of the sky .
  • Page 41 107 . 9 . 6 Ensure Onyx EZ is tuned to channel 1 . Upon power up, Onyx EZ should tune to channel 1 by default, when it’s not yet activated . If it’s not on channel 1, refer to “Listening to Satellite Radio”...
  • Page 42 Dock From the Universal Xpress Car Kit” on page 77, and complete the additional instructions before continuing with the next step . 8 . Set your Onyx EZ to transmit on the same FM channel that you have selected in step 7: 90.1...
  • Page 43 If the signal reception is good, but there is no XM audio when tuned to channel 1, verify that both the Onyx EZ and your vehicle’s FM radio are tuned to the same FM channel (steps 7 & 8) . Also ensure the chosen FM channel is a suitable one to use in your area (step 5) .
  • Page 44 Vehicle Installation Option 4: FM Direct Adapter (FMDA) Installation The FMDA needs to be installed by a professional installer . Professional installation can help improve your radio’s reception and significantly reduce the visibility of wires . To learn more, check with the retailer where you bought your radio, or go to siriusxm .ca .

  • Page 45: Activation

    . General activation and subscription process: 1 . Make sure your Onyx EZ is properly installed and receiving the XM signal so that you can hear the audio on channel 1 . 2 . Make a note of your XM Radio ID . You can find it on channel 0, on a label on the bottom of the gift box, and on the label on the back of your Onyx EZ .

  • Page 46: Display Settings

    Activation Activation guide: For your convenience, Onyx EZ has an on-board activation guide . You can activate your radio and subscribe to the XM service by using this guide, where you will be guided step-by-step through the subscription process . To access and use the guide, simply follow these steps: 1 .

  • Page 47: Using Your Onyx Ez

    Using Your Onyx EZ The Main Display When listening to a channel, information about the channel is displayed . The Spectrum Channel Number Channel Name Tom Petty Artist Name or Talk Show Host I Should Have Known It or Sports Teams/Score...

  • Page 48: Navigation Basics

    Using Your Onyx EZ Navigation Basics Power Button Pressing the Power button turns the Onyx EZ On or Off . Navigation Buttons Use the Left, Right, Up, and Down buttons to navigate through various features and functions of Onyx EZ .
  • Page 49 Using Your Onyx EZ Menu Button menu Pressing menu displays various options to make setup and feature changes . Pressing menu when in menu options returns to the previous menu option screen until menu options is exited . Pressing and holding menu returns to the main display screen in most instances .

  • Page 50: Listening To Satellite Radio

    Using Your Onyx EZ Listening to Satellite Radio Tune a channel: 1 . Press and release to immediately tune to the next or previous channel . 2 . Press and hold to quickly scroll through the channels . Release to tune to the channel that is displayed .

  • Page 51: Direct Tune

    Using Your Onyx EZ Direct Tune A channel can be tuned directly by entering the channel number using the number buttons . 1 . To directly tune a channel press direct . Direct Tune Enter channel # 6 2 _ 2 .
  • Page 52 Using Your Onyx EZ Jump Pressing the jump button tunes the channel to which you were previously listening . Return to Main Display Screen Pressing and holding menu in most instances will return you to the main display screen . In some cases, you may need to follow the instructions on the display...
  • Page 53 Using Your Onyx EZ Favourite Channels You can set up to 10 of your favourite channels so you can easily access them . Each favourite channel can be assigned to a number button . To assign a favourite channel to a number...
  • Page 54 Using Your Onyx EZ Scanning Channels in a Category You can scan a category and listen to each channel for 10 seconds before the next channel is automatically tuned . If you want to stay tuned to the channel being played and stop the scan, just press the Select button .

  • Page 55: Fm Presets

    FM presets make it easy to quickly access stored FM channels and choose a new FM channel from them . Use FM presets when you use PowerConnect to listen to your Onyx EZ through your vehicle’s FM radio . (Refer to “Option 3: PowerConnect Installation Instructions”...
  • Page 56 Using Your Onyx EZ TIP! To configure the list of preset FM channels, you need to find available FM channels in your area . Refer to “Find Available FM Channels in Your Area” on page 63 . Next, refer to “Set and Select an FM Channel” on page 65 .

  • Page 57: Special Features

    . All locked channels become unlocked and will remain unlocked until you turn the Onyx EZ Off, and back On . In the category list, the previously locked channels will show an unlocked icon To turn Parental Controls On (or Off): 1 .
  • Page 58 Special Features For each digit, press one of the 0-9 keys and then press advance to the next digit . (Press if you need to go back and edit a previous digit .) ii . When you have selected all 4 Enter Parental Code digits of your code press the Select button .
  • Page 59 Special Features To lock (or unlock) channels or categories: 1 . Press menu . 2 . Press to scroll to and highlight Parental Controls . Press the Select button . 3 . You will be prompted to enter the 4-digit code . For each digit, press one of the 0-9 keys and then press to advance to the next digit .
  • Page 60 Special Features channel or category and press the Select button . The lock icon will disappear indicating the channel or category is unlocked .) 8 . You can continue to lock and unlock as many channels or categories as you wish . When you are finished press and hold menu to return to the main display screen .
  • Page 61 . If your code is correct the channel will be tuned . All locked channels become unlocked and will remain unlocked until you turn the Onyx EZ Off, and back On . In the category list, the previously locked channels will show an unlocked icon...

  • Page 62: Configuring Your Onyx Ez

    Configuring Your Onyx EZ Radio ID Your Onyx EZ has an alphanumeric ID which uniquely identifies the radio . This ID is used during the activation process . To display the Radio ID: 1 . Press menu . Radio ID 2 .

  • Page 63: Area

    Find Available FM Channels in Your Area Before attempting any of the procedures below, you should park your vehicle in a safe location . Do not attempt to set up your FM channels or any Onyx EZ function while driving .
  • Page 64 . If this is the case, we recommend saving the best FM channels as presets on your FM radio and Onyx EZ . Then you simply select and match the best channel for the area you are in .

  • Page 65: Set And Select An Fm Channel

    FM preset in any one of the 5 storage locations . IMPORTANT! Onyx EZ and the vehicle’s FM radio need to be tuned to the same FM channel in order to hear the audio .
  • Page 66 Configuring Your Onyx EZ If the chosen storage location is empty (denoted by “---“), or if the storage location contains the FM preset currently being used (denoted by “current”), then the FM channel tuning screen is displayed . ii . If the chosen storage location has an FM preset that is not currently being used, and you want to edit it, Edit Channel is highlighted .
  • Page 67 Configuring Your Onyx EZ 7 . The chosen FM channel will be confirmed on the display screen 99.3 FM and the Onyx EZ will tune to that channel . Set your vehicle radio to the above 8 . Set your vehicle’s FM radio to same FM channel .
  • Page 68 Configuring Your Onyx EZ To quickly select an FM channel from the preset list: 1 . Press FM to display the current FM preset . 99.3 FM 2 . To display and select the next FM Set your vehicle preset, press FM . The radio will radio to the above tune to the displayed FM channel .

  • Page 69: Set Brightness Or Contrast

    Configuring Your Onyx EZ Set Brightness or Contrast To change the display’s brightness or contrast: 1 . Press menu . Set Brightness 2 . Press to scroll to and highlight Display Settings and press the Select button . 3 . Press the Select button to change...

  • Page 70: Set Audio Level

    . Audio level is used to adjust the Onyx EZ’s volume level to match the volume of other audio sources you may use, such as a CD player, other FM stations, or an MP3 player .

  • Page 71: Signal Indicator

    Configuring Your Onyx EZ Signal Indicator For best reception, your Magnetic Mount Antenna should have an unobstructed view of the XM satellites . In large cities, there are terrestrial transmitters (ground repeaters) to help increase the signal coverage . Your...

  • Page 72: Factory Settings

    Factory Settings The factory settings menu has two choices, AUX Detect and Restore Defaults . AUX Detect Factory Settings AUX Detect allows the Onyx EZ Radio to automatically detect a connection made to the AUX Detect enabled AUDIO connector of the Vehicle Dock by an Aux In Cable or Cassette Adapter .
  • Page 73 Configuring Your Onyx EZ 3 . AUX Detect should be highlighted and show as enabled . Press the Select button to toggle the setting . Press Select to 4 . A warning screen will be displayed . disable only if using...
  • Page 74 You can clear all of your personal settings, such as favourite channels, FM presets etc . and return the radio to its original out-of-the-box settings To reset Onyx EZ to factory defaults: NOTE! Restoring defaults permanently removes all personal settings .

  • Page 75: Demo Mode

    . If desired, you can also manually put the Onyx EZ in demo mode . The ability for Onyx EZ to enter demo mode is enabled by default . If you don’t want Onyx EZ to ever enter the demo mode, you can disable the demo feature .

  • Page 76: Auto Shut Off

    Auto Shut Off forget to turn your Onyx EZ off . Started auto shut off When Onyx EZ is about to shut off, the due to inactivity message Auto Shut Off, Started auto shut off due to inactivity is displayed, followed by Press any button Press any button to cancel .

  • Page 77: Using The Vehicle Dock From The Universal Xpress Car Kit

    1 . Disable the AUX Detect feature . Refer to “AUX Detect” on page 72, and disable AUX Detect . 2 . Turn the FM Transmitter in the Onyx EZ On . Refer to “Turn FM Transmitter On/Off” on page 78, and turn the FM Transmitter On .

  • Page 78: Turn Fm Transmitter On/Off

    4 . The FM Channels menu item will now be accessible, allowing you to tune the Onyx EZ and the FM radio in your vehicle to the same FM channel . TIP! Onyx EZ is programmed with FM channel 97 . 9 as the default setting .
  • Page 79 Aux In Cable or a Cassette Adapter as the audio connection option, you’ll have to turn the FM Transmitter under the FM Settings menu in the Onyx EZ Radio Off, if it was previously turned On . 1 . Press menu .

  • Page 80: Troubleshooting

    Troubleshooting Onyx EZ has been designed and built to be trouble-free but if you experience a problem, try this: • Check that all connections are firm and secure . • Make sure the vehicle power socket is clean and free of corrosion .
  • Page 81 PowerConnect Vehicle Dock . Make sure the cable is not bent or broken . • Turn Onyx EZ Off, then On, to reset this message . • If the message persists, most likely the Magnetic Mount Antenna cable has been damaged . Replace the antenna .
  • Page 82 Universal Xpress Car Kit, ensure that the FM Transmitter in the Onyx EZ is turned Off, and increase the audio level of the Onyx EZ . Refer to “Set Audio Level” on page 70 . Audio sounds too soft • Raise the volume of your stereo system or increase...
  • Page 83 • If you are using the Vehicle Dock that came with the Universal Xpress Car Kit, ensure that the FM Transmitter in the Onyx EZ is turned On . Refer to “Turn FM Transmitter On/Off” on page 78 . No song title or artist name is • The information may not be available or updates...

  • Page 84: Product Specifications

    -4°F to +140°F (-20°C to +60°C) Audio Output: 1 .0 V rms (max) Onyx EZ Radio Dimensions: 4 .5 in (W) x 2 .4 in (H) x 0 . 7 in (D) 115 mm (W) x 61 mm (H) x 17 mm (D) Weight: 3 .4 oz (95 g)

  • Page 85: Information

    Patent and Environmental Information Patent Information It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer, hack, manipulate, or otherwise access and/or make available any technology incorporated in this product . Furthermore, the AMBE voice ª...

  • Page 86: Fcc And Ic Statement

    FCC and IC Statement The user is cautioned that changes or modifications not expressly approved by XM Radio Inc . can void the user’s authority to operate this device . This device complies with Part 15 of the FCC Rules and is certified to Industry Canada’s RSS- 210 specifications .

  • Page 87: Copyrights And Trademarks

    © 2013 Sirius XM Canada Inc . “SiriusXM”, the SiriusXM logo, channel names and logos are trademarks of Sirius XM Radio Inc . and are used under license . “NFL” and the NFL Shield design are trademarks of the National Football League . NASCAR® is a registered trademark of the National Association for Stock Car Auto Racing, Inc .
  • Page 88 .ca Sirius XM Canada Inc . 135 Liberty St . - 4th floor Toronto, Ontario, M6K 1A7 1-877-438-9677 © 2013 Sirius XM Canada Inc . Onyx EZ User Guide 130613a...
