Microcom 424M Options
• Ethernet
• Guillotine Full and Partial
Cutters
• Rotary Cutter
• 300 DPI
• Remote Stock Sensors
• Remote User Interface Kit
• Low Cost Presenter
• Desktop Power Supplies
(740) 548-6262
8220 Green Meadows Drive North
Lewis Center, Ohio 43035
Microcom can be found on the Internet at
www.microcomcorp.com
References in this publication to Microcom
Corporation products or services do not
imply that we intend to make them
available in all countries.
This product is RoHS compliant.
Microcom 424M Thermal Kiosk Printer
For Expanded specifications visit www.microcomcorp.com/424m.htm
Performance Summary
—Direct thermal
—203 dpi standard with optional 300 dpi
—4.1" maximum print width
—Up to 6" per second print speed
—Unlimited print length
—Adjustable sensor detects die-cut, black line, blow hole on continuous and preprinted labels or tag stock
—Serial and USB interface
—Microsoft Windows® OS compatible
—Software-controlled print contrast adjustments
—Lift up print head for easy cleaning and replacement
—Rated for 100% duty cycle usage
—Rigid steel construction

Bar Codes

◊◊◊
—Code 39 —Modified Plessy
—UPC-A —UPC-E
—Postnet —Codabar
2D Symbologies —PDF-417
Fonts
◊◊◊
—7 Resident fonts including OCR-A and OCR-B
—Downloadable font support
—All fonts expandable in height and width up to 255X and 255Y
—0, 90, 180 and 270 degrees font and bar code printing
Memory
◊◊◊
—Up to 8MB Flash for non-volatile font, graphic and label data storage
—Up to 512K SRAM for volatile font, graphic and label data storage

Communication Interfaces

—Serial RS-232D with baud rates up to 115,200 BPS
—USB
—Ethernet (Optional)

Physical Dimensions

Height
4.0" (102 mm) 8.2" (208 mm)

Environmental Conditions

—Relative humidity: 10-85% non-condensing
—Operation Temperature: 40° to 104° F (5° to 40° C)
—Power supply: External Supply with Auto-Sensing; 90-264 VAC, 3.5/1.5 Amps, 47-63 Hz
Compliance
◊◊◊
—RoHS
—Designed to meet CUL, CE and FCC Class A
Warranty
◊◊◊
—One year limited warranty
© Copyright 2010 Microcom Corporation. All rights reserved.
Microcom Corporation reserves the right to make improvements to their products at any time without prior notice.
The information contained herein is subject to change without notice. Microcom Corporation shall not be liable for
technical or editorial omissions contained herein. Reproduction, adaptation or translation without prior written permission
is prohibited, except as allowed under the copyright laws. All company and product names are trademarks or registered
trademarks of their respective owner.
◊◊◊
—Code 128 —Code 93
—EAN-8 —EAN-13
—Maxicode —RSS-14
◊◊◊
◊◊◊
Width Depth
3.7" (94 mm)
◊◊◊
—Interleaved 2 of 5
—EAN-UCC 128
Weight
3.2 lbs. (1.5 Kg)
