Microcom 426P Features
• Ethernet and Serial

Communication Ports

• Fixed Tray Tag Guide
• Field Replaceable Printhead
• Toolless Media Path Access
• Compatible with most
USPS Sortation Equipment
• Supports Code 128 Indicia
(740) 548-6262
8220 Green Meadows Drive North
Lewis Center, Ohio 43035
Microcom can be found on the Internet at
www.microcomcorp.com
References in this publication to Microcom
Corporation products or services do not
imply that we intend to make them
available in all countries.
This product is RoHS compliant.
Microcom 426P Desktop Thermal Printer
For Expanded specifications visit www.microcomcorp.com/426p.htm
Performance Summary
—Direct thermal
—203 dpi resolution
—Up to 6" per second print speed
—Adjustable sensor detects die-cut, blow hole, black line on continuous and preprinted labels or tag stock
—Label taken sensor
—Software-controlled print contrast adjustments
—Fixed media guides designed specifically for 3.3" Tray Tag Media (Adjustable Guides Optional)
—High lift print head for easy cleaning
—Rated for 100% duty cycle usage
—Rigid steel construction
—User selected Baud rate

Bar Codes

◊◊◊
—Code 39 —Modified Plessy
—UPC-A —UPC-E
—Postnet —Codabar
2D Symbologies —PDF-417
Fonts
◊◊◊
—19 Resident fonts including OCR-A and OCR-B
—Downloadable font support
—All fonts expandable in height and width up to 255X and 255Y
—0, 90, 180 and 270 degrees font and bar code printing
Memory
◊◊◊
—4MB Flash for code and resident font storage (non-volatile)
—16MB SDRAM for label data storage, downloadable font and graphics storage (volatile)

Communication Interfaces

—Serial RS-232D with baud rates up to 230,400 BPS
—Ethernet (TCP/IP)
—USB (Optional)

Physical Dimensions

Height
8.4" (213mm) 8.6" (218mm)

Environmental Conditions

—Relative humidity:
—Operation Temperature:
—Power supply:
Compliance
◊◊◊
—CUL
—RoHS
Warranty
◊◊◊
—One year limited warranty
© Copyright 2010 Microcom Corporation. All rights reserved.
Microcom Corporation reserves the right to make improvements to their products at any time without prior notice.
The information contained herein is subject to change without notice. Microcom Corporation shall not be liable for
technical or editorial omissions contained herein. Reproduction, adaptation or translation without prior written permission
is prohibited, except as allowed under the copyright laws. All company and product names are trademarks or registered
trademarks of their respective owner.
◊◊◊
—Code 128 —Code 93
—EAN-8 —EAN-13
—Datamatrix
◊◊◊
◊◊◊
Width Depth
5.5" (140mm)
◊◊◊
10-85% non-condensing
40° to 104° F (5° to 40° C)
Universal input
Auto-sensing 90-264 VAC 4 Amps 47-63 Hz
—CE
—FCC Class A
—Interleaved 2 of 5
—EAN-UCC 128
Weight
8.7 lbs. (4Kg)
830005-0000
