Nixeus NX-VUE30 User Manual

30" ips 2560x1600 monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Nixeus Technology, Inc
Nixeus Vue 30" IPS 2560x1600 Monitor
(NX-VUE30)
Important Note:
Please make sure your computer hardware graphics card supports the Nixeus Vue 30" IPS Monitor. Some devices and
connections may not be able to support the full 2560x1600 resolution. If you are not sure, please contact your computer
hardware's manufacturer. Please read this manual before using the Nixeus Vue 30" NX-VUE30 with your computer. It
contains important information regarding use and care of IPS Monitors.
Safety and Maintenance:
1) Do not expose the monitor to direct sunlight. Keep the monitor away from a stove or any other heat source.
2) Remove or secure any objects that may fall into the monitor's vents. Do not obstruct or block the cooling vents of the
monitor.
3) Don't jam the vents on the enclosure.
4) When setting up the monitor for use, please ensure the power plug and socket are easy to insert and extract.
6) Please use only approved power line and power adapters provided by Nixeus. If any power connections are missing,
please contact Nixeus for a replacement. Using un-authorized power connectors may damage your monitor and void your
warranty.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX-VUE30 and is the answer not in the manual?

Questions and answers

Related Manuals for Nixeus NX-VUE30

Summary of Contents for Nixeus NX-VUE30

  • Page 1 4) When setting up the monitor for use, please ensure the power plug and socket are easy to insert and extract. 6) Please use only approved power line and power adapters provided by Nixeus. If any power connections are missing, please contact Nixeus for a replacement.

  • Page 2: Box Contents

    If foreign objects or liquids get into the monitor, please disconnect power adapter immediately. For service please contact Nixeus Technical support for service and repair at techsupport@nixeus.com 11) To ensure long life and best performance of the monitor, please use the monitor in these safe and optimum...

  • Page 3: Input And Connection Ports

    Installing Base Stand: (Tools needed – Philips Screw Driver) Carefully lay the monitor on its' back on a static free, clean, flat surface. Connect base to stand and line up connection holes. With the four connection screws provided, secure base to stand. Input and Connection Ports DisplayPort (DP), VGA, Dual Link DVI, and HDMI Note: HDMI 1.4 and VGA do not support full 2560x1600 @ 60Hz...

  • Page 4: Off Position

    NX-VUE30 Power Cable and Power Supply Switch: Only use the power cable included with the NX-VUE30. Using any other un-authorized power adapters may damage your monitor and void your warranty. Connect the power cable to internal power supply on the back of the monitor (make sure power switch is off before connecting the cable).
  • Page 5 Monitor Swivel Left/Right: Make sure the NX-VUE30 is on a stable level surface. Holding the left and right bezel with your hand, carefully adjust monitor left or right to desired orientation. Monitor Tilting Foward/Back: Use both hands, hold the top and bottom or right and left to tilt the monitor as shown in the pictures.

  • Page 6: On-Screen Display (Osd)

    ON SCREEN DISPLAY (OSD) For the On Screen Display to be visible on the monitor, a video signal must be transmited to the monitor from your PC/MAC. The six buttons you will use to navigate the On Screen Display (OSD) are "AUTO," "MENU," "VOL+," "VOL-," "UP," and "DOWN."...

  • Page 7: Osd Setting Sub-Menu

    OSD SETTING Sub-Menu: One of the first things you should do is to adjust the On Screen Display settings to your preference. 1) To bring up the OSD menu, first press the MENU button then press the DOWN button to navigate down to OSD SETTING.
  • Page 8 If you want to adjust the horizontal placement of the OSD MENU on your monitor; 1) Press the DOWN or the UP button to navigate and highlight OSD H. POS then press MENU to highlight the progress bar. 2) Use the VOL+ and VOL- buttons to adjust the value for your desired settings. Once you have customized your selection, press the MENU or AUTO button.
  • Page 9 You also can adjust the transparency of the OSD menu. 1) To do this, go to the OSD SETTING sub-menu and navigate down to TRANSPARENCY. 2) Press MENU to highlight the progress bar and use VOL+ and VOL- buttons to adjust your preferred settings. Once you finish you may press the AUTO button twice to exit out of the OSD MENU.

  • Page 10: Brightness Sub-Menu

    BRIGHTNESS Sub-Menu: To adjust the settings in the BRIGHTNESS Sub-Menu, first press the MENU button bring up the OSD, then press MENU again to access the BRIGHTNESS Sub-Menu. 1) To adjust the monitor's brightness, use the UP and DOWN buttons to navigate to BRIGHTNESS then press the MENU button to highlight the progress bar.
  • Page 11 The ECO settings have 4 preset brightness/contrast settings - STANDARD, GAME, MOVIE, and TEXT. 1) In the BRIGHTNESS Sub-Menu, use the UP/DOWN buttons to navigate to ECO and press the MENU button. 2) Then use the VOL+/VOL- buttons to cycle through and select either STANDARD, GAME, TEXT, and MOVIE mode. Please note when you select GAME, TEXT, or MOVIE as the setting - you will not be able to manually customize the BRIGHTNESS and CONTRAST settings (These settings are grayed out).
  • Page 12 Dynamic Contrast Ratio (DCR) can also be adjusted in the BRIGHTNESS Sub-MENU. 1) Use the UP/DOWN buttons to navigate to DCR and press the MENU button. 2) Using the VOL+/VOL- buttons you can turn DCR to ON or OFF. Pressing the AUTO button will exit DCR. Please note if DCR is turned ON, you cannot adjust the BRIGHTNESS and CONTRAST settings.

  • Page 13: Image Sub-Menu

    IMAGE Sub-Menu: In the IMAGE Sub-MENU, you are only able to adjust the ASPECT Ratio of the monitor to either WIDE or 4:3. The recommended settings is to set the ASPECT ratio to WIDE. 1) First press the MENU button to bring up the OSD, then use the UP/DOWN buttons to browse to the IMAGE sub-menu and press MENU again.
  • Page 14 COLOR TEMP Sub-Menu: 1) Press the MENU button to bring up the OSD. 2) Use the Up/Down buttons to navigate to COLOR TEMP, then press the MENU button. 3) Use the VOL+/VOL- to browse or select one of 3 preset color temperatures; Normal, Warm, or Cool. Once selected, you may press the "AUTO Button twice to exit and apply the settings.
  • Page 15 Color Temperature Calibration in COLOR TEMP Sub-Menu: NOTE: For accurate color calibration, we recommend using a hardware colorimeter 1) In the COLOR TEMP Sub-Menu, use the VOL+/VOL- button to select the "USER" preference and press the MENU button. 2) Use the UP/DOWN button to select which color temperature to customize and press the MENU button to highlight the progress bar.

  • Page 16: Misc Sub-Menu

    MISC Sub-Menu: 1) Press the MENU button to bring up the OSD 2) Using the UP/DOWN buttons, browse to the MISC sub-menu and press the MENU button. 3) Using the UP/DOWN buttons navigate to either HOTKEY TYPE, SIGNAL SOURCE, AUDIO SELECT or VOLUME that you wish to adjust or change then press the MENU button.
  • Page 17 SIGNAL SOURCE: This setting allows you to change the video signal source to either VGA, DVI, HDMI, or DP. This function can also be accessed without the On Screen Display by simply just pressing the AUTO button.
  • Page 18 AUDIO SELECT: This setting allows you to choose which audio source to transmit sound to the monitors speakers. Select DIGITAL only if you are using a HDMI or DP video signal source. Choose ANALOG is you are using DVI or VGA connection cables with the 3.5mm audio cable.

  • Page 19: Reset Sub-Menu

    2) Using the UP/DOWN buttons, browse to the RESET sub-menu and press the MENU button. 3) Pressing the MENU button again while the RESET is highlighted in red will reset ALL OSD settings to the factory default settings. If you need additional assistant, please contact Nixeus Technology toll free at 888-983-4128 or e-mail techsupport@nixeus.com...
  • Page 20 • After an RMA number is assigned, the defective/malfunctioning product must be packaged securely in the original or other suitable shipping package to ensure that it will not be damaged in transit to Nixeus Technology, Inc. The RMA number must be visibly and clearly marked on the outside of the package. Do not include any manuals or accessories in the shipping package, Nixeus will only replace/repair the defective/malfunctioning product and will not ship back any accessories.
