Page 1: Table Of Contents
FM788HB INSTRUC TION MANUAL FM788HC VACUUM CLEANER FM788HG Contents IMPORTANT SAFETY INSTRUCTIONS NAME OF EACH PART PREPARATION BEFORE USE USING THE VACUUM CLEANER USING THE ATTACHMENTS EMPTYING THE DUST COMPARTMENT CLEANING THE FILTERS CLEARING BLOCKAGES IN THE SUCTION HOSE AND CLEANING THE... -
Page 2: Important Safety Instructions
FANTOM at 94 Main Mill Street, Door 16, Plattsburgh, NY 12901. 6. Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the cord around sharp edges or corners. -
Page 3: Save These Instructions
25. If the supply cord of this appliance is damaged, it must only be replaced by FANTOM, because special purpose tools are required. 26. Connect to a properly grounded outlet only. See Grounding Instructions. SAVE THESE INSTRUCTIONS This vacuum is intended for household or commercial use. -
Page 4: Name Of Each Part
NAMES OF EACH PART FRONT REAR Handle Power Cord Suction Hose A Plug Release Button C Plug shown in figure Release may differ from actual Power Cord Button A plug attached to unit Release Carrying Handle for your area. Button B Duster Knob Cord Storage ON/OFF Switch... -
Page 5: Preparation Before Use
PREPARATIONS BEFORE USE Caution: Do not connect the power cord plug to the wall outlet until assembly is completed. Attaching the handle Set the vacuum cleaner lnsert the handle to the upright position. as shown in the illustration. Handle Attaching the suction hose A & attachments Wand Crevice Tool Suction Hose A... -
Page 6: Winding The Power Cord
PREPARATIONS BEFORE USE WINDING THE POWER CORD Wind the power cord around the cord storage hooks. Secure the power cord plug on the power cord. Cord Storage Hooks RELEASING THE POWER CORD Return the hook to the Rotate the upper cord upright position before storage hook downward. -
Page 7: Using The Vacuum Cleaner
USING THE VACUUM CLEANER ON/OFF SWITCH Start or stop vacuum cleaner by pushing ON/OFF Switch on the switch. ADJUSTING THE HANDLE The handle of this vacuum cleaner can be set to one of three positions -Upright, Normal, Parallel. Place your foot on handle release lever as shown and pull back on the handle until it releases from its upright position. -
Page 8: Edge Cleaning
USING THE VACUUM CLEANER HEIGHT ADJUSTMENT LEVER Caution: Before using the height adj- ustment lever,please make sure the nozzle head is tilted Height Adjustment Lever backward from the floor. The nozzle head can be Nozzle Head adjusted to four different height settings. -
Page 9: Using The Attachments
USING THE ATTACHMENTS Caution: When using one of the attachments during cleaning,set the vacuum cleaner to the upright position. Wand Remove the attachments from the Crevice Tool vacuum cleaner. Press the release button C to Duster disconnect the handle from the Release vacuum cleaner. - Page 10 USING THE ATTACHMENTS Hose Attachment Handle Suction Hose A Line up notches Suction Inlet push hose in till it Hose Cuff clicks.
-
Page 11: Emptying The Dust Compartment
EMPTYING THE DUST COMPARTMENT Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before cleaning. Empty the dust compartment when Press the release button A meanwhile press the release button B to remove contents reach the MAX mark. -
Page 12: Cleaning The Filters
CLEANING THE FILTERS Remove the dust compartment.(refer to page 10) Set the dust compartment to the parallel position.Open the trapdoor,then push the release button E and pull out the main filter. Release Button E The main filter and prefilter will be removed at the same time. -
Page 13: Suction Hose And Cleaning The
CLEARING BLOCKAGES AND CLEANING THE AGITATOR ASSEMBLY Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before clearing any blockages in the suction hose and cleaning the agitator assembly. Cleaning blockages Cleaning blockages in the suction hose A, B Suction Hose A... -
Page 14: Replacement Instructions
REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE HEADLIGHT LAMP Set the vacuum cleaner to the parallel position. Loosen the screws to remove the lens. -
Page 15: Replacing The Flat Belt
REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE FLAT BELT Remove the bottom plate. (refer to page 15) Lift out the agitator assembly, and then remove the flat belt from the motor shaft and the agitator pulley. -
Page 16: Reattaching The Bottom Plate
REPLACEMENT INSTRUCTIONS REMOVING THE BOTTOM PLATE Set the vacuum cleaner to the parallel position and turn it over. Loosen Screws Use a Philips screwdriver to loosen the screw on the bottom plate and slide the latch in the direction of the arrow. Loosen Loosen Screw... -
Page 17: Replacing The Filter
(3) months, however, vacuuming large amounts of extremely fine dust, powder or similar material over a long period of time may decrease airflow performance through the filter. If this occurs, it may become necessary to replace the HEPA Filter more often. Only use genuine FANTOM replacement filters. Filter Cover... -
Page 18: Troubleshooting
If the problem still persists after the checks have been made, do not use the vacuum cleaner to prevent the possibility of an accident occurring. Turn the ON/OFF switch to the "OFF" position, disconnect the power cord from the wall outlet, and contact FANTOM Customer Service at 1-800-275-9251. Problem Cause... -
Page 19: Limited Warranty
FANTOM, 94 Main Mill Street, Door 16, Plattsburgh, N.Y. 12901 If the appliance is found by FANTOM to be defective in material or workmanship, FANTOM will repair or replace it free of charge. Proof of purchase date and $21.95 to cover the cost of return shipping and handling must be included. * Non-durable parts including, without limitation, dust cup filters, filters, belts, brushes and electrical parts which normally require replacement are specifically excluded from warranty.
