Page 1: Table Of Contents
INSTRUCTION MANUAL VACUUM CLEANER HOUSEHOLD AND COMMERCIAL USE FM744H Contents IMPORTANT SAFETY INSTRUCTIONS NAME OF EACH PART PREPARATION BEFORE USE USING THE VACUUM CLEANER USING THE ATTACHMENTS AIR DRIVEN TURBO BRUSH EMPTYING THE DUST COMPARTMENT CLEANING THE FILTERS CLEARING BLOCKAGES IN THE... -
Page 3: Important Safety Instructions
4. Use only as described in this manual. Use only the manufacturer's recommended attachments. 5. Do not use with a damaged cord or plug. If the vacuum cleaner is not working as it should, or if it has been dropped, damaged, left outdoors or dropped into water, return to FANTOM at 94 Main Mill Street, Door 16, Plattsburgh, NY 12901. -
Page 4: Save These Instructions
19. Do not pick up items such as pieces of waste paper or cloth which looks as though they may cause the hose to become blocked. 20. Do not clean or store the vacuum cleaner in places where there are high temperatures. -
Page 5: Name Of Each Part
Height Adjustment Lever Headlight Set the ON/OFF switch to " ON " to light the headlight. WARNING: Operate vacuum cleaner only at the voltage specified on name plate. Suction Power Cord Hose A Plug Plug shown in figure Release may differ from actual... -
Page 6: Preparation Before Use
PREPARATIONS BEFORE USE Caution: Do not connect the power cord plug to the wall outlet until assembly is completed. Attaching the handle Set the vacuum cleaner to the upright position. Attaching the suction hose A & attachments Suction Hose A Upholstery Tool &... - Page 7 To protect your vacuum cleaner motor from overheating, a thermal safety device has been built in. If your vacuum cleaner hose or air intake clogs up with dust or dirt, or if your dust bag becomes full and you continue to run the machine, the vacuum will shut off automatically to prevent the motor from overheating.
-
Page 8: Using The Vacuum Cleaner
Start or stop vacuum cleaner by pushing on the switch. ADJUSTING THE HANDLE The handle of this vacuum cleaner can be set to one of three positions -Upright, Normal, Parallel. Place your foot on handle release lever as shown and pull back on the handle until it releases from its upright position. -
Page 9: Edge Cleaning
Caution: Do not change the setting of the RUG/FLOOR(TOOLS)selector while the vacuum cleaner is turned off. EDGE CLEANING This vacuum cleaner is equipped with an "edge cleaning" function for cleaning carpet edges near baseboards and stationary furniture. Caution: Before using the height adj-... -
Page 10: Using The Attachments
USING THE ATTACHMENTS Caution: When using one of the attachments during cleaning,set the vacuum cleaner to the upright position. Remove the attachments from the vacuum cleaner. Press the release button C to disconnect the handle from the vacuum cleaner. Caution:... - Page 11 Suction Hose A Suction Hose B Press the release button C to disconnect the handle from the vacuum cleaner. To attach the Pet Hair Attachment, twist the cuff on end of attachment onto the adapter until it locks, then slide adapter into wand or into Suction Hose B.
-
Page 12: Air Driven Turbo Brush
AIR DRIVEN TURBO BRUSH Using the Unit With Air Driven Turbo Brush The efficiency of your Air Driven turbo brush depends on the bristle brush rotating at high speed. Strong air suction is needed to accomplish this. In order to ensure that maximum air suction is maintained, please read the following instructions: 1. -
Page 13: Emptying The Dust Compartment
EMPTYING THE DUST COMPARTMENT Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before cleaning. Empty the dust compartment when contents reach the MAX mark. MAX mark Press the release lever to open the trapdoor. -
Page 14: Cleaning The Filters
CLEANING THE FILTERS Remove the dust compartment.(refer to page 11) Set the dust compartment to the parallel position.Open the trapdoor,then push the release button E and pull out the main filter. The main filter and prefilter will be removed at the same time. Caution: Do not push the release button E at the upright position. -
Page 15: Suction Hose And Cleaning The
Remove the bottom plate(refer to page 16) Remove any blockages from the nozzle head. Reattach the bottom plate to the nozzle head, and then operate the vacuum cleaner to check that the blockage has been properly cleared. If the nozzle head is still blocked, the suction force will be weak. -
Page 16: Replacement Instructions
Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE HEADLIGHT LAMP Set the vacuum cleaner to the parallel position. Loosen the screws to remove the lens. When removing the headlight lamp, be careful not to pull on the headlight lamp wiring. -
Page 17: Replacing The Flat Belt
REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE FLAT BELT Remove the bottom plate. (refer to page 16) Lift out the agitator assembly, and then remove the flat belt from the motor shaft and the agitator pulley. -
Page 18: Reattaching The Bottom Plate
REPLACEMENT INSTRUCTIONS REMOVING THE BOTTOM PLATE Set the vacuum cleaner to the parallel position and turn it over. Using a Philips screwdriver, loosen the screw on the bottom plate. Lift the bottom plate off. REATTACHING THE BOTTOM PLATE Insert the projection on the bottom plate into the groove on the nozzle housing and set the bottom plate in place. -
Page 19: Replacing The Filter
Do not attempt to wash the HEPA filter. Always replace the old filter with a new one. Insert a new HEPAfilter with the seal to the inside of the vacuum cleaner. Reattach the filter cover. Caution: Be sure that seal on the HEPAfilter is inserted towards the inside of the vacuum cleaner. -
Page 20: Troubleshooting
TROUBLESHOOTING If there is a problem with the vacuum cleaner, carry out the following checks to find the cause. If the problem still persists after the checks have been made, do not use the vacuum cleaner to prevent the possibility of an accident occurring. -
Page 21: Limited Warranty
By returning this card you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions. RETURN TO FANTOM , 94 Main Mill Street, Door 16 , Plattsburgh , N.Y . 12901 Model FM744H Appliance model Date purchased...
