INSTRUCTION MANUAL VACUUM CLEANER FM760 Contents IMPORTANT SAFETY INSTRUCTIONS NAME OF EACH PART PREPARATION BEFORE USE USING THE VACUUM CLEANER USING THE ATTACHMENTS EMPTYING THE DUST COMPARTMENT CLEANING THE FILTERS CLEARING BLOCKAGES IN THE SUCTION HOSE AND CLEANING THE AGITATOR ASSEMBLY... -
Page 3: Important Safety Instructions
4. Use only as described in this manual. Use only the manufacturer's recommended attachments. 5. Do not use with a damaged cord or plug. If the vacuum cleaner is not working as it should, or if it has been dropped, damaged, left outdoors or dropped into water, return to FANTOM at 94 Main Mill street, Door 16, Plattsburgh, NY 12901. -
Page 4: Save These Instructions
19. Do not pick up items such as pieces of waste paper or cloth which look as though they may cause the hose to become blocked. 20. Do not clean or store the vacuum cleaner in places where there are high temperatures. -
Page 5: Name Of Each Part
Height Adjustment Headlight Lever Set the ON/OFF switch to " ON " to light the headlight. Cleaning Utensil Operate vacuum cleaner only at the voltage specified on name plate. Suction Hose Release Button A Cord Storage Hooks Release Button B... -
Page 6: Preparation Before Use
PREPARATION BEFORE USE Caution: Do not connect the power cord plug to the wall outlet until assembly is completed. Attaching the handle Set the vacuum cleaner to the upright position. Attaching the suction hose & attachments Suction Hose Upholstery Tool... -
Page 7: Winding The Power Cord
PREPARATION BEFORE USE WINDING THE POWER CORD Hook the power cord over the clip which is located on the upper cord storage hook as shown. Plug side Clip RELEASING THE POWER CORD Rotate the upper cord storage hook downward. Upper Cord Storage Hook INSERTING T HE POWER CORD PLUG WARNING: To reduce the risk of electric shock, this... -
Page 8: Using The Vacuum Cleaner
Start or stop vacuum cleaner by pushing on the switch. ADJUSTING THE HANDLE The handle of this vacuum cleaner can be set to one of three positions -Upright, Normal or Parallel. Place your foot on handle release lever as shown and pull back on the handle until it releases from its upright position. - Page 9 Caution: Do not change the setting of the RUG/FLOOR(TOOLS)selector while the vacuum cleaner is turned off. EDGE CLE AN ING This vacuum cleaner is equipped with an "edge cleaning" function for cleaning carpet edges near baseboards and stationary furniture. Cautio n:...
-
Page 10: Using The Attachments
USING THE ATTACHMENTS Caution: When using one of the attachments during cleaning,set the vacuum cleaner to the upright position. Remove the attachments from the vacuum cleaner. Press the release button C to disconnect the handle from the vacuum cleaner. Caution:... -
Page 11: Emptying The Dust Compartment
EMPTYING THE DUST COMPARTMENT Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before cleaning. Empty the dust compartment when contents reach the MAX mark. MAX mark Press the release lever to open the trapdoor. -
Page 12: Cleaning The Filters
CLEANING THE FILTERS Remove the dust compartment.(refer to page 9) Set the dust compartment to the parallel position.Open the trapdoor,then push the release button E and pull out the main filter. The main filter and prefilter will be removed at the same time. Caution: Do not push the release button E at the upright position. -
Page 13: Clearing Blockages In The Suction Hose And Cleaning The
Reattach the hose cuff to the suction inlet,and the dust inspection cover to the bypass tube assembly. Now switch on the vacuum cleaner to check that the blockage has been properly cleared. If the hose is still blocked, the suction force will be weak. -
Page 14: Replacement Instructions
Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE HEADLIGHT LAMP Set the vacuum cleaner to the parallel position. Loosen the screws to remove the lens. When removing the headlight lamp, be careful not to pull on the headlight lamp wiring. -
Page 15: Replacing The Flat Belt
REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the"OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE FLAT BELT Remove the bottom plate. (refer to page 14) Lift out the agitator assembly,and then remove the flat belt from the motor shaft and the agitator pulley. -
Page 16: Reattaching The Bottom Plate
REPLACEMENT INSTRUCTIONS REMOVING THE BOTTOM PLATE Set the vacuum cleaner to the parallel position and turn it over. Slide the latch in the direction of the arrow. Remove the bottom plate by pulling the tabs as illustrated. REATTACHING THE BOTTOM PLATE... -
Page 17: Replacing The Hepa Filter
Do not attempt to wash the HEPA filter. Always replace the old filter with a new one. Insert a new HEPA filter with the seal to the inside of the vacuum cleaner. Reattach the filter cover. Caution: Be sure that seal on the HEPA filter is inserted towards the inside of the vacuum cleaner. -
Page 18: Troubleshooting
TROUBLESHOOTING If there is a problem with the vacuum cleaner, carry out the following checks to find the cause. If the problem still persists after the checks have been made, do not use the vacuum cleaner to prevent the possibility of an accident occurring. -
Page 19: Limited Warranty
By returning this card you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions. RETURN TO FANTOM, 94 Main Mill Street, Door 16, Plattsburgh, N.Y. 12901 Model FM760 ____________________________________________________________________________________________ Appliance model...
