Configure System - CMD11 (3Bh)

Notes:
4. This command is only available
in System 4xi units with the
following firmware revision levels, or
higher:
System 4LDxi – revision 3.0
System 4LQxi – revision 4.0
6. Only available on System 4LDxi
and 4LQxi
Extron • System 4 xi Switcher Series • User's Manual
4
Configure the System 4xi
Format:
ESC, CMD11, LD Sync, RGB Delay, Aud Mute, reserved, LDxi Misc, reserved,
EOT
Where: ESC, CMD11 = 1Bh, 3Bh
LD Sync 80h = no change
81h = Composite Sync with no serrations
82h = Sync negative (horizontal & vertical)
83h = Composite Sync with serrations
84h = 6 Sync positive (horizontal & vertical)
6
85h = Sync positive horizontal, negative vertical
86h = 6 Sync negative horizontal, positive vertical
RGB Delay FFh = no change
80h - 8Ah = RGB Delay in 0.5 second steps
(values range from 0 to 5 seconds)
Audio Mute 80h = Turn Audio Mute Off
81h = Turn Audio Mute On
FFh = No change
LDxi Misc 6 80h - AAh (see table)
Bit #s
Function:
No changes
Demo, no change
Demo mode On
Demo mode Off
Freeze no change
Freeze On
Freeze Off
VGA no change
Not VGA resolution
Force VGA resolution
reserved 80h = reserved
EOT 04h = End Of transmission
Example:
Configure a System 4xi for the following:
Sync = No change, RGB Delay = No change, Audio Mute = On, Demo Mode =
No change, Freeze = No change and Force VGA Resolution = No change.
That is: 1Bh, 3Bh, 80h, FFh, 81h, 80h, 80h, 80h, 04h
Normal response:
ESC, CMD11, ERC, EOT
1Bh, 3Bh, 80h, 04h
