Bogen EASY INSTALL Quick Manual

EASY INSTALL
Surface-Mount Ceiling Speakers
SM1EZ, SM4T
Easy Install Speakers drastically cut system installation time because each
speaker can be completely installed — mounted in the ceiling, secured,
and connected — in less than a minute! This versatile speaker carries voice
messages with clarity anywhere dependable communication is required.
It can be installed in any suspended ceiling with ceiling tiles... quick, easy,
and trouble-free. Compatible with both 70V and 25V systems.
P r o d u c t F e a t u r e s :
• Installs in Seconds. Each speaker assembly is
specially designed for immediate installation
as soon as you take it out of the box... complete
installation takes less than a minute.
• No-Tool Installation. No tools needed; everything
you need is right in the box.
• Contemporary, Low-Profile Design.
in any environment.
• No Clean-Up. Installation means piercing ceiling
tiles, NOT cutting them. So, there's virtually no
mess and no ceiling tile pieces to clean up.
Complies with NFPA National code 160b
that allows speakers to be installed
in plenums and other air handling spaces.
Complies with UL-2043.
For System Design for SM1EZ,
for SM4T, see pages 64-67.
/EASY DESIGN
®
M o d e l Va r i a t i o n s :
• SM1EZ
speaker.
• SM4T
speaker with settings of 4, 2, 1,
1/2, and 1/4 watts. Settings are
rotary switch selectable (there are
no transformer wires to deal with).
Looks good
Te c h n i c a l S p e c i f i c a t i o n s :
Dimensions:
Depth:
Frequency
Response:
Sensitivity:
Product
Weight:
see pages 17-21; Shipping
Weight:
SPEAKERS
TM
is a one-watt, single tap
is a four-watt, multi-tap
9-1/2" diameter
3" (from tile surface)
125 Hz – 15 kHz
90 dBspl (1 watt @ 1 meter)
2 lb. each
15 lb./carton (5/carton)
INSTALLS
IN SECONDS!
:03
A
The speaker's two specially de-
signed mounting studs easily
pierce through the ceiling tile.
:24
B
Wide-based wing nuts secure the
speaker assembly to the ceiling tile.
:45
C
Two standard wire nuts connect
the speaker wires to the mount-
ing studs, making the electrical
connection. That's all it takes!
Accessories
SMTB
Tile Bridge
15
