Extron electronics HDSDI-ACR 100 User Manual page 5

Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Sync
Output type .................................. RGBHV, RGBS, RGsB
Standards (SDI-AVR 100 only) .. NTSC 3.58, PAL 4.43, Betacam
Output impedance ....................... 75 ohms
Max. rise/fall time ....................... 200 nS
Polarity .......................................... SDI-AVR 100 ............ negative
HDSDI-ACR 100 ...... bi-level or tri-level sync
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, internal, auto-
switchable
SDI AVR 100 ..................... 6 watts
HDSDI AVR 100 .............. 10 watts
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to
90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to
90%, non-condensing
Rack mount ................................... Yes, with optional rack shelf, part #60-190-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 8.75" W x 8.0" D
(1 rack unit high, half-rack unit wide)
4.5 cm H x 22.2 cm W x 20.3 cm D
(Depth excludes connectors.)
Shipping weight .......................... 4 lbs (1.8 kg)
Product weight
SDI-AVR 100 .................... 1.8 lbs (0.8 kg)
HDSDI-ACR 100 .............. 1.9 lbs (0.9 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com
Fax 714.491.1517 Fax +31.33.453.4050
© 2002 Extron Electronics. All rights reserved.
(switch selectable) on luma
(Y) leg
