Contents
Introduction ..................................................
About this Manual............................................ 1
Terms Used in this Manual ........................... 1
Features .......................................................... 1
Installation ....................................................
Application Examples ...................................... 3
Mounting the XTRA Series Amplifiers ............... 4
Tabletop Use ............................................... 4
UL Guidelines for Rack Mounting ................. 4
Rack Mounting ............................................ 5
Flexible Conduit Adapter Kit Installation ....... 6
Operation .......................................................
1
Front Panel Features and Operation ................ 9
Rear Panel Features and Operation ............... 11
Remote Volume Control ............................. 17
Controlling Multiple Amplifiers with One
Volume Controller ..................................... 18
3
Bridged Mono Output ................................ 19
Troubleshooting
Amplifier Fails to Exit
Standby Mode Promptly ............................... 20
Amplifier Enters Standby Mode
Too Early ...................................................... 21
Limiter/Protect LED Warning Indicators ......... 21
Over Temp Indicator LED ............................... 21
XTRA Series Half-Rack Audio Power Amplifiers • Contents
.........................................
