11. Touch the "Enter Button" to deselect the selected
parameter removing it from the list of parameters being
displayed on the 1-up display.
12. Use the "Arrow Button" to scroll and highlight the desired
parameter that has not been selected for display.
13. Touch the "Enter Button" to select the highlighted
parameter for inclusion in the Single Engine Parameter
Display.
14. Continue to scroll and select additional parameters for
the custom 1-up Display. Touch the "Menu Button" at
any time to return to the "Custom Setup" menu.
15. Automatic Scan- Selecting the scan function will cause
the 1-Up Display to scroll through the selected set of
parameters one at a time. Use the "Arrow Buttons" to
scroll to the "Automatic Scan" function.
DCA-220SSJ/SSJU — OPERATION AND PARTS MANUAL — REV. #0 (02/04/14) — PAGE 31
DCA-220SSJ/SSJU — DIAGNOSTIC DISPLAY
ENGINE SPEED
1
PERCENT LOAD AT CURRENT RPM 3
ENGINE OIL PRESSURE 2
ENGINE COOLANT TEMPERATURE
ENGINE SPEED
PERCENT LOAD AT CURRENT RPM
2
ENGINE OIL PRESSURE 1
ENGINE COOLANT TEMPERATURE
Note that the numbers
now indicate the new order
of display for the parameters.
ENGINE SPEED
PERCENT LOAD AT CURRENT RPM 2
ENGINE OIL PRESSURE 1
ENGINE COOLANT TEMPERATURE 3
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN OFF
16. Touching the "Enter Button" toggles the "Automatic
Scan" function on.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN ON
17. Touching the "Enter Button" again toggles the "Automatic
Scan" function off.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN OFF
18. Once the "Use Defaults", "Custom Setup" and "Automatic
Scan" functions have been set touch the "Menu Button"
to return to the main menu.
USE DEFAULTS
CUSTOM SETUP
AUTOMATIC SCAN ON
19. Touch the "Menu Button" to exit the Main menu and
return to the engine parameter display.
GO TO 1-UP DISPLAY
STORED CODES
ENGINE CONF G
SETUP 1-UP DISPLAY
SETUP-4-UP DISPLAY
SELECT UNITS
ADJUST BACKLIGHT
0 1500 3000
1800 RPM
ENG RPM COOL TEMP
1
