PRE-INSTALLATION NOTES:

The system is shipped with this feature activated. Any time the ignition key is turned to the off position, the doors will
automatically unlock. Any time the ignition key is turned to the on position, the doors will automatically lock.
To disable the auto lock / unlock feature, move dip switch number 1 to the "off" position.

PASSIVE / ACTIVE DOOR LOCK SELECTION: DIP SWITCH # 2

This feature will only affect the operation of the system if the passive arming feature is selected.
When active door lock is selected, the doors will only lock when the transmitter button is pressed. When the alarm is
allowed to arm passively, at the end of the 30 second arming cycle, the doors will not automatically lock. The system
is shipped in the active door lock mode, therefore, no modifications are required for this feature.
When passive door lock is selected, when the alarm is allowed to arm passively, at the end of the 30 second arming cycle,
the doors will automatically lock. To program this feature, move dip switch number 2 to the on position.

PASSIVE / ACTIVE ARMING SELECTION: DIP SWITCH # 3

This alarm can be programmed to operate as either a "PASSIVE" or "ACTIVE" arming security system.
As a "Passive" alarm, the system will automatically arm itself approximately 30 seconds after the ignition key is turned
off, one door is opened, then all vehicle doors are closed, (arming is suspended until the last door is closed). This feature
protects the vehicle in the event you forget to arm the system using the keychain transmitter. When the optional door lock
interface is installed, the doors will operate according to the position of dip switch number 2.
This system is shipped in the passive mode, therefore no modifications are required to make the system operate as a
"Passive" alarm.
As an "Active" alarm, the system can only be armed using the keychain transmitter. There will be no backup
automatic arming. To make the system operate as an "Active" alarm, move dip switch number 3 to the off position.

VOLTAGE SENSE / HARDWIRE SELECTION: DIP SWITCH # 4

This alarm can be wired to operate as a Voltage Sensing or a Hardwire system.
As a voltage sensing system, the alarm will trigger any time an entry point that illuminates a courtesy light is opened.
The system is shipped in the voltage sensing mode, therefore, no modifications are required to make this system a voltage
sensing alarm.
As a hardwire system, the alarm will trigger any time a door, hood, trunk, etc. is opened, by wiring directly to the switches.
This means that if the courtesy light is burned out, or the courtesy light fuse is blown, the alarm will continue to protect
all points of entry. To make this system operate as a hardwire alarm, move dip switch number 4 to the off position.
NOTE: When "Passive Arming" and "Voltage Sensing" are selected, you must hardwire the driver's door pin switch,
or passive arming will never be initiated.
REMOTE ENTRY ILLUMINATION: (OPTIONAL RELAY REQUIRED)
This system provides a ground output (300 mA Max) to drive an external relay that can be used to illuminate the dome
light for 30 seconds whenever the system is disarmed.
This circuit will also flash the interior dome light when the alarm is triggered.
Since a relay is required, (not included), this feature can be used with both positive and negative switched dome light
circuits.
Installation Manual

AUTO LOCK / UNLOCK: DIP SWITCH # 1

Model PRO 9243
128-4301

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO 9243 and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiovox PRO 9243

  • Page 1 Model PRO 9243 Installation Manual PRE-INSTALLATION NOTES: AUTO LOCK / UNLOCK: DIP SWITCH # 1 The system is shipped with this feature activated. Any time the ignition key is turned to the off position, the doors will automatically unlock. Any time the ignition key is turned to the on position, the doors will automatically lock.
  • Page 2 DOOR LOCK / UNLOCK OUTPUTS: This system provides both (+) & (-) pulsed door lock outputs, for direct connection to most OEM factory installed door lock control relays. These outputs have a maximum current capability of 300 mA , therefore, external relays must be used on switching circuits requiring more than 300 mA or with 4 or 5 wire polarity reversal door lock control circuits.
  • Page 3 WIRING OF THE SYSTEM: RED w/ WHITE TRACE FUSED WIRE - (VOLTAGE SENSING): + 12 VDC CONSTANT BATTERY SOURCE This wire controls the sensitivity of the voltage sensing circuit, which detects the turning on of an interior light when a door is opened.
  • Page 4 IMPORTANT: Audiovox does not recommend using this relay to interrupt the ignition wire. Only connect this relay to the low current starter solenoid feed wire, as indicated on the wiring diagram.
  • Page 5 DOOR LOCK CONTROL CIRCUITS In these applications, the AS 9159 Door Lock Interface (or equivalent 30 A automotive relays) must be used. Refer to the AUDIOVOX Door Lock Wiring Supplement, for proper connection to these types of circuits. COMPLETING THE INSTALLATION:...
  • Page 6 VEHICLE MAKE: MODEL: YEAR: WIRING VEHICLE WIRE ALARM WIRE LOCATION COLOR COLOR BLACK YELLOW BROWN PURPLE WHITE OPTIONAL DOOR LOCK WIRING TYPE OF DOOR LOCK CIRCUIT: LOCK UNLOCK CONTROL MODULE LOCATION: L.E.D. LOCATION: VALET SWITCH LOCATION: SIREN LOCATION: 128-4301...
  • Page 7 ADDITIONAL NOTES AND SKETCHES: NOTES: Printed in Taiwan Audiovox Corp., 150 Marcus Blvd. Hauppauge , N.Y. 11788 Form No. 128-4301 128-4301...
