Page 1
GV-FD5300 5MP H.264 WDR IR Fixed IP Dome • 1/2.5" progressive scan CMOS • Dual streams from H.264 and MJPEG • Up to 20 fps at 2560 x 1920 • 3‐axis mechanism (pan / tilt / roll) • Varifocal megapixel lens • Intelligent IR • 2‐way audio • One sensor input and alarm output • TV‐out support • Built‐in Micro SD (SDHC / SDXC ) card slot for local storage • DC 12V / AC 24V / PoE • Wide Dynamic Range (WDR) ...
Dimensions Hard‐Ceiling Mount In‐Ceiling Mount Specifications Camera Image Sensor 1/2.5” progressive scan low lux CMOS Picture Elements 2560 (H) x 1920 (V) Color 0.15 Lux at F/1.6 Minimum B/W Illumination 0 Lux IR ON Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec.) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic S/N Ratio 45 dB BLC Yes Lens Megapixel Yes Day/Night Yes (with removable IR‐cut filter) Lens Type Varifocal ...
Operation Audio Compression G.711 Two‐way Audio Yes Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Video Resolution 4:3 2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960 Main Stream 16:9 1920 x 1080, 1280 x 720 5:4 1280 x 1024 4:3 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252 5:4 640 x 512, 320 x 256 Network Interface 10/100 Ethernet HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS Ethernet Protocol (DSCP), ONVIF (Profile S) Mechanical Pan 0° ~ 350° Camera Angle Tilt ...
Page 4
Note: 1. Do not use clothes or any ordinary material to clean the camera cover since they may result in scratches. 2. Specifications are subject to change without notice. Accessories Model No. Name Details Dimensions: 200 x 170 x 257.5 mm GV‐Mount100 Straight Tube and Junction Box Kit (7.9’’ x 6.7’’ x 10.1”) Weight: 3.17 Kg (6.99 lb) Dimensions: 219 x 125 x 332 mm GV‐Mount101 Straight Tube Kit (8.6’’ x 4.9’’ x 13.1”) Weight: 1.8 Kg (3.97 lb) Dimensions: 225 x 140 x 250 mm GV‐Mount200 Wall Pendant Tube (8.9’’ x 5.5’’ x 9.8”) Weight: 900 g (1.98 lb) Dimensions: 315 x 195.5 x 225 mm Wall Pendant Tube and Junction Box GV‐Mount203 (12.4’’ x 7.7’’ x 8.9”) Kit Weight: 2.95 Kg (6.5 lb) Dimensions: 238.6 x 409.5 mm GV‐Mount300 Convex Corner Adapter Kit ...
Page 5
Model No. Name Details Bracket: 241 x 161 mm (9.5’’ x 6.3’’) Pole Mount Bracket Kit GV‐Mount410 Weight: 1.70 Kg (3.75 lb) (Ø 6" ~ 7.5") Steel Strap Diameter: Ø 6" ~ 7.5" Four options are available. Dimensions: Ø 5.4 x 10 or 20 or 30 or 50 cm (Ø 2.1’’ x 3.9’’ or 7.9’’ or 11.8’’ or GV‐Mount702 Extension Tube 19.7”) Weight: 180 g or 390 g or 550 g or 800 g (0.4 lb or 0.86 lb or 1.21lb or 1.76 lb) Dimensions: 154 x 108 x 50 mm GV‐Mount900 Wall Mount Bracket (6.1’’ x 4.3’’ x 2”) Dimensions: Ø 186 x 97.5 mm GV‐Mount902 GV‐FD Series Dome Housing (Ø 7.3’’ x 3.8”) Weight: 600 g (1.32 lb) Dimensions: ø 103.7 x 55 mm (4.08’’ x 2.16”) 41‐81053‐HK2 ...
