Configuring The Server; Configuring The Onboard Sata Controller - Fujitsu PRIMERGY TX120 S2 Operating Manual

Starting up and operation
– IPMI
The server is switched on by an IPMI console via serial port COM1 (item 1
in figure 6 on page
on page 42).
5.4

Configuring the server

This section contains information about configuring the server and installing the
operating system.
5.4.1

Configuring the onboard SATA controller

A 6-port SATA controller is integrated on the system board. You can configure
the onboard SATA controller either before or during installation with the
ServerView Installation Manager. Using the ServerView Installation Manager is
recommended.
I
The controller has its own configuration utility. For further information,
refer to the "Embedded MegaRAID Software User's Guide" (on the
PRIMERGY ServerView Suite DVD 2 under Industry Standard Servers -
Expansion Cards - Storage Adapters - LSI RAID / SCSI Controllers).
I
Descriptions of operating systems not covered in the controller manual
are provided in the corresponding readme files on the driver CDs.
TX120 S2
42) or via the service LAN connection (item 4 in
Operating manual
Configuring the server
figure 6
55
