Specifications
PCI revision 2.2
Bus Interface
(3.3/5V slot connector)
Form Factor
Full Profile
Chipset ID
Oxford OXuPCI952
Connectors
2 x DB9 male
Supported Protocols
RS232/422/485
Maximum Data Transfer Rate
921.6Kbps
Operating Temperature
0°C ~ 55°C (32°F ~ 131°F)
Storage Temperature
-20°C ~ 85°C (-4°F ~ 185°F)
Humidity
5 ~ 95% RH
Dimensions (LxWxH)
121.0mm x 74.0mm x 18.0mm
Weight
100g
Windows XP/Server 2003/Vista/
Compatible Operating
Server 2008 R2/7 (32/64-bit),
Systems
CE 4.x/5.0, Linux
6
