7
BATTERY CHARGING

I Optional battery chargers

D Rapid charging with the BC-119N+AD-103
The optional BC-119N provides rapid charging of battery
packs. The following are additionally required.
• AD-103
• An AC adapter (may be supplied with BC-119N depending
on version).
OPC-515L or
CP-17L
AC adapter
(BC-145E)
19
IC-M21
BP-224
AD-103 charger
adapter is installed
in BC-119N.
D Rapid charging with the BC-121N+AD-103
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-103.
• An AC adapter (BC-124) or the DC power cable (OPC-656).
BP-224
AC adapter
(purchased
separately)
DC power cable
(Connect with the DC power supply;
13.8 V/at least 7 A)
IC-M21
AD-103 charger
adapters are installed
in each slot.
