Marshall Electronics V-R261P-AFHD Operating Instructions Manual

Sd/hd widescreen lcd monito
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version

Maintenance

■ Screen Cleaning
Periodically clean the screen surface using ammonia-free cleaning wipes (Marshall Part No. V-HWP-K). A clean micro-
fiber cloth can also be used using only non-abrasive and ammonia-free cleaning agents. Do not use paper towels.
Paper towel fibers are coarse and may scratch the surface of the polycarbonate faceplate or leave streaks on the
surface. Antistatic and fingerprint resistant cleaning agents are recommended. Do not apply excessive pressure to the
screen to avoid damaging the LCD.
■ Faceplate Dusting
Dust the unit with a soft, damp cloth or chamois. Dry or abrasive cloths may cause electrostatic charge on the surface,
attracting dust particles. Neutralize static electricity effects by using the recommended cleaning and polishing practice.

Warranty

Marshall Electronics warranties to the first consumer that this V-R261P-AFHD LCD monitor will, under normal use, be free
from defects in workmanship and materials, when received in its original container, for a period of one year from the
purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the
warranty. If there is no proof of purchase provided with a warranty claim, Marshall Electronics reserves the right not to
honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer. This warranty does not
apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations or modifications in design or
construction void this warranty. It is considered normal for a minimal amount of pixels, not to exceed three, to fail on the
periphery of the display active viewing area. Marshall Electronics reserves the option to refuse service for display pixel
failure if deemed unobtrusive to effective use of the monitor by our technicians. No sales personnel of the seller or any
other person is authorized to make any warranties other than those described above, or to extend the duration of any
warranties on behalf of Marshall Electronics, beyond the time period described above. Due to constant effort to improve
products and product features, specifications may change without notice.
Marshall Electronics, Inc.
Tel: (800) 800-6608 / (310) 333-0606 • Fax: 310-333-0688
www.LCDRacks.com
Specifications (continued)
1910 East Maple Ave.
El Segundo, CA 90245
•
sales@lcdracks.com
Marshall Electronics
Operating Instructions
16
V-R261P-AFHD
SD/HD Widescreen LCD Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-R261P-AFHD and is the answer not in the manual?

Questions and answers

Related Manuals for Marshall Electronics V-R261P-AFHD

Summary of Contents for Marshall Electronics V-R261P-AFHD

  • Page 1 This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, Marshall Electronics reserves the right not to honor the warranty set forth above.

  • Page 2: Table Of Contents

    Contents Specifications ■ PANEL ■ TALLY Product Overview..............................3 Screen Size 26.005” Diagonal 3 LEDs (Green, Red, Yellow). Activation requires contact Display Area (h x v) 575.700 x 323.831 mm closure of pin to ground on the HD-15 connector: Features ..................................3 Aspect Ratio 16:9 Native (4:3/16:9 Modes) Pixels...

  • Page 3: Product Overview

    Use the FUNCTION 1 and FUNCTION 2 menu items to define each function button on the front panel of the monitor. The following options are available for each button: ■ Multi-Format Compatibility With a variety of analog and digital inputs, the V-R261P-AFHD accommodates virtually all video formats. Input types • DELAY Enable and rotate amongst delay modes.

  • Page 4: Unpacking

    Use this mode to clearly view the edges of the active video Connect the required cables for video signal input and output. (Power must be applied to the V-R261P-AFHD for the area.

  • Page 5: Power Button

    On-Screen Menu (continued) Front Panel Features VIDEO CONFIGURATION SUBMENU (continued) ■ Monochrome Mode Use this setting to enable monochrome mode. Only the luminance of the image will be displayed as a grayscale picture. Top Front Panel ■ Blue-Only Mode Use this setting to enable Blue-Only mode. This mode displays only the blue color component of the image, switching off the red and green components.

  • Page 6: Rear Panel Features

    On-Screen Menu (continued) Rear Panel Features VIDEO CONFIGURATION SUBMENU Video Configuration Submenu ■ Color Temperature Presets Use this setting to choose one of three color temperature presets: • D55 (5500K) • D65 (6500K) • D93 (9300K) • USER (Adjustable Color Bias and Gain) ■...

  • Page 7: On-Screen Menu

    On-Screen Menu (continued) Compatible Input Formats MARKER SETUP SUBMENU (continued) Format Composite S-Video YPbPr DVI-D ■ 4:3 Markers ● ● NTSC Use this setting to superimpose one of 5 markers on the screen when in 4:3 mode. This setting is disabled when the ●...

  • Page 8: Main Menu And Navigation

    On-Screen Menu (continued) On-Screen Menu MARKER SETUP SUBMENU STRUCTURE OVERVIEW OFF, 13:9, 14:9, 4:3, 2.35:1, MARKER 16:9 1.85:1, 95%, 93%, 90%, 88%, 80% MARKER SETUP OFF, 95%, 93%, 90%, 88%, MARKER 4:3 MARKER BACKGROUND OFF, HALF, BLACK CENTER MARKER OFF, ON COLOR TEMP D55, D65, D93, USER Marker Setup Submenu...
