FIGURE 4A — Correct and Incorrect Eyebolt
Orientation
FORCE
CORRECT
FIGURE 5A — Vertical Suspension of a
System 200
M 200 Installation Kit
b
WARNING:
Suspending any object is potentially dan-
gerous and should be attempted only by
individuals who have a thorough knowl-
edge of the techniques and regulations of
rigging objects overhead. Electro-Voice
sanctions suspending the System 200
speakers only when all current national,
federal, state and local regulations are
taken into account. When the System
200 TM speaker is suspended, Electro-Voice
strongly recommends that system be in-
spected at least once a year. If any sign of
weakness is detected, corrective action
should be taken immediately.
3
Mb200/Mb200W Installation Kit
FIGURE 4B — Horizontal Suspension of a
FORCE
5/16
SHOULDER
EYEBOLT
1.00 in. (25 mm)
MAXIMUM
LENGTH
INCORRECT
LOCK WASHER
FIGURE 5B — Vertical Suspension of Two
TM Speaker Using
TM
System 200 TM Speaker Using
M 200 Installation Kit (side view)
b
System 200 TM Speakers Using
M 200 Installation Kit
b
FIGURE 4C — Horizontal Suspension of a
System 200 TM Speaker Using
M 200 Installation Kit
b
(isometric view)
FIGURE 6A — Frame Structure for Horizontal
Array in Position for Assembly
(comprised of M 200 and M
b
brackets)
FIGURE 6B — System 200 TM Horizontal Array
(assembled)
300
b
M b 300
