DIRECTV Wireless Cinema Connection Kit
Troubleshooting
LEDs
Activity
This LED is green when the Whole-Home DVR service network is
established. Both the wireless connection and a wired connection
(either Ethernet or Coax) must be established. It flashes when data
is being transmitted through the CCK-W. The LED is off when no
Whole-Home DVR service coax network is established.
Coax Network
This LED indicates that the Whole-Home DVR service network
is operational. When the light is steady green, it means a good
MoCA coax network is established with full bandwidth. When the
light is steady yellow, it means the MoCA coax network is estab-
lished, but with degraded bandwidth. The coaxial distribution
should be checked to ensure all devices in line are DIRECTV-ap-
proved; splitters, coax cable, wall-ports, etc. This LED is off when no
MoCA coax network is established. LED off is expected when using
an Ethernet connection.
AP/STA
AP is for possible future implementation testing only.
LED Definitions
LED Possible
Label Status
Power is on,
Solid
Green
Flashing
POWER
Green
Off
24
Definition Troubleshooting Tips
device is Solid green is normal.
booted
Wait for 30 seconds. If LED is
not solid, unplug
Device is the power from the W-DCCK
booting up device, wait 10 seconds,
then plug in the power to the
W-DCCK device.
Check to ensure the power
Device is
adapter is plugged into
not pow-
the W-DCCK device and into
ered
an electrical outlet.
