- Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8704-07 AB_CSP APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001...
-
Page 2: Table Of Contents
Appendix A. Troubleshooting .....................13 Appendix A.1. Continuous Map Descriptors .................13 Appendix B. Command Support ..................14 Appendix C. Revision History .....................15 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 3: Allen Bradley Ab_Csp Description
Page 3 of 15 Allen Bradley AB_CSP Description The AB_CSP driver allows the FieldServer to transfer data to and from devices over AB_CSP Ethernet protocol. The FieldServer can emulate either a Server or Client. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer. -
Page 4: Hardware/Software
AB_CSP Client, e.g. Wonderware, Intellution FIX, GE Cimplicity, etc. If FieldServer used as Allen Bradley AB_CSP Client If FieldServer used as Allen Bradley AB_CSP Server. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 5: Hardware Connections
Make sure the device IP_address is configured to be on the same IP network as the FieldServer. Use a crossover cable if the FieldServer is connected directly to the PLC device. Use a straight cable if the FieldServer is connected to a hub. -
Page 6: Configuring The Fieldserver As A Ab-Csp Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer). -
Page 7: Client Side Connection Descriptors
PLC3, PLC5, SLC5 Communications type. Example Client Side Nodes Nodes Node_Name, Node_ID, Protocol, PLC_Type, IP_Address, Adapter PLC_01, AB_CSP, SLC5, 192.168.1.13, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 8: Client Side Map Descriptors Client Side Map Descriptors
-32767 to 32767, 0 Node Scaling max in Connected Node_High_Scale* -32767 to 32767, 100 Node Override the default Unprotected Command AB_Command command Typed FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 9: Map Descriptor Example
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, File_Type, File_Number, Address, Length, Scan_Interval CMD_DI_01, DA_DI_01, RDBC, PLC_01, 1.0s CMD_DO_01, DA_DO_01, RDBC, PLC_01, 1.0s FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 10: Configuring The Fieldserver As An Ab_Csp Server
Specify PLC PLC_Type PLC3, PLC5, SLC5 Communications type. Example Server Side Nodes Nodes Node_Name, Node_ID, Protocol, PLC_Type ABE_Srv_11, AB_CSP, SLC5 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 11: Server Side Map Descriptors
Scaling zero in Connected Node_Low_Scale* -32767 to 32767, 0 Node Scaling max in Connected Node_High_Scale* -32767 to 32767, 100 Node FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 12: Map Descriptor Example
ABE_Srv_11, 100, Map_Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, File_Type, File_Number, Address, Length SMD_DI_01, DA_DI_01, Server, ABE_Srv_11, SMD_DO_01, DA_DO_01, Server, ABE_Srv_11, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 13: Appendix A. Troubleshooting
This will crash RS view as the AB_CSP will attempt to map N21: 0-100 If set up as Server Map 1: N21: 0-100, no problems are experienced FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 14: Appendix B. Command Support
FS-8704-07_AB-CSP Manual Page 14 of 15 Appendix B. Command Support The following commands are supported by the FieldServer for the various PLC types: Typical PLC_Type File_type Read Write Command Range Read Range Write N7: 3, L5 PLC3 Range Read Range Write... -
Page 15: Appendix C. Revision History
Corrected example 12/27/04 Meg 1.00 table formatting. Removed some commas in example. Created Troubleshooting section. DUR0522. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com...
