Page 1 FORD TRANSIT Owner's Manual...
Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2013 All rights reserved. Part Number: CG3612en 12/2013 20131211085629...
Page 3: Table Of Contents
Keys and Remote Controls Cornering Lamps..........51 General Information on Radio Direction Indicators........51 Frequencies..........30 Stepwell Lamps..........51 Remote Control..........30 Interior Lamps..........52 Replacing a Lost Key or Remote Control............30 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 4 Head Restraints..........81 Manual Seats...........82 Transmission Power Seats.............84 Manual Transmission........107 Rear Seats............86 Heated Seats...........88 All-Wheel Drive Using All-Wheel Drive........108 Auxiliary Power Points Auxiliary Power Points.........89 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 5 Draining the Fuel Filter Water Trap..158 Towing Changing the 12V Battery......159 Towing a Trailer..........132 Checking the Wiper Blades.......161 Trailer Sway Control........133 Changing the Wiper Blades.......161 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 6 Audio unit............208 Audio unit - Vehicles With: AM/FM/ CD..............217 Audio unit - Vehicles With: SYNC/ Navigation System........221 Audio unit - Vehicles With: SYNC/AM/ FM/CD............227 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 7: Introduction
This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing Battery forward in the seat. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 8 Engine air filter release Jack Engine coolant Keep out of reach of children Engine coolant temperature Lighting control Engine oil Low tire pressure warning Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 9: Data Recording
If required, you will receive further information. After an error has been corrected, these data are deleted from the error storage module or they are constantly overwritten. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 10: Replacement Parts Recommendation
Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 11 Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 12: At A Glance
See Technical Specifications (page 190). See Refueling (page 104). See Selective Catalytic Reduction System (page 102). See Changing a Bulb (page 163). See Towing Points (page 133). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 13: Vehicle Interior Overview
See Fastening the Safety Belts (page 24). See Head Restraints (page 81). See Manual Seats (page 82). See Parking Brake (page 110). See Hill Start Assist (page 111). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 14: Instrument Panel Overview - Lhd
Information and entertainment display. See Audio System (page 207). See Locking and Unlocking (page 31). See Hazard Warning Flashers (page 138). See Climate Control (page 73). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 15: Instrument Panel Overview - Rhd
See Auto-Start-Stop (page 97). See Parking Aid (page 114). See Direction Indicators (page 51). See Lighting Control (page 47). See Information Displays (page 62). See Instrument Cluster (page 56). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 16: At A Glance
See Ignition Switch (page 94). Horn See Adjusting the Steering Wheel (page 41). See Cruise Control (page 118). See Lighting (page 47). See Exterior Mirrors (page 54). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 17: Child Safety
Death or serious injury to the child can occur. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 18: Booster Seats
Secure children that weigh between 29 lb (13 kg) and 40 lb (18 kg) in a child safety seat (Group 1) on the rear seat. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 19: Isofix Anchor Points
ISOFIX size class for the intended seating locations. See Child Seat Positioning (page 19). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 20: Child Safety
Follow the child seat manufacturer's instructions for installing a child seat with a support leg. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 21: Child Seat Positioning
See Seats (page 81). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 22 - bus Rear seats - second row - double cab in van Rear seats - second row - double chassis cab Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 23 X Not suitable for children in this mass group. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 24 Note: When you are purchasing an ISOFIX child seat, make sure that you know the correct mass group and ISOFIX size class for the intended seating locations. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 25: Child Safety Locks
Left-Hand Side Turn counterclockwise to lock and clockwise to unlock. Right-Hand Side Turn clockwise to lock and counterclockwise to unlock. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 26: Safety Belts
Position the safety belt correctly for your safety and that of your unborn child. Do not use only the lap strap or the shoulder strap. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 27: Safety Belt Height Adjustment
3. Pull down on the safety belt loop to make sure it is secure in position. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 28: Safety Belt Minder
Turning the Safety Belt Minder Off See an authorized dealer. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 29: Supplementary Restraints System
This is normal. Note: The front passenger airbag protects both positions of a double seat. Note: Only wipe airbag covers with a damp cloth. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 30: Switching The Passenger Airbag Off
Switching the Passenger Airbag WARNING You must switch the airbag on when you are not using a child seat on the front seat. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 31: Side Airbags
The airbag will deploy during significant lateral collisions. The airbag will not deploy in minor lateral and frontal collisions, rear collisions, or overturns. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 32: Keys And Remote Controls
REMOTE CONTROL You can program a maximum of eight remote controls to your vehicle. See an authorized dealer. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 33: Locks
Turn the key to the lock position twice within three seconds. Double Locking With the Remote Control Press the button twice within three seconds. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 34: Opening And Closing The Sliding Door
Pull the door handle to release the door check feature. 2. Slide the door to close. Pull the interior door handle to open the door. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 35: Automatic Locking
45 seconds of unlocking your vehicle with the remote control. The door locks and the alarm will return to their previous state. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 36: Automatic Unlocking
Turn the key in the driver door lock. • Press the unlock button on the remote control once. • Press the interior unlock button once. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 37: Configurable Unlocking
See an authorized dealer for further information. Rear Emergency Exit Pull the interior handle up to open the door in an emergency. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 38: Security
The sounder has its own battery and will sound an alarm siren even if someone disconnects your vehicle battery or the battery back-up sounder itself. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 39: Triggering The Alarm
You can select full or reduced guard using the information display. See General Information (page 62). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 40: Disarming The Alarm
12 seconds or unlocking the doors with the remote control. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 41: Power Running Boards
Note: The running boards may operate slower in cold temperatures. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 42: Manual Operation
Resetting the System You can reset the system by opening and closing the sliding door. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 43: Steering Wheel
2. Adjust the steering wheel to the desired position. Use the arrows on the steering wheel to navigate through the menus. Press OK to make a selection. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 44: Voice Control
• tune the radio to the next station up or down the frequency band • seek through a track. See Cruise Control (page 118). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 45: Information Display Control
Steering Wheel INFORMATION DISPLAY CONTROL See Information Displays (page 62). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 46: Wipers And Washers
Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 47: Windshield Washers
With high sensitivity, the wipers will operate when the sensor detects a small amount of moisture on the windshield. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 48: Rear Window Wiper And Washers
To use the washer, push the lever away from you. When you release the lever, wiping will continue for a short period of time. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 49: Lighting
B. If you see any unacceptable condensation, have your vehicle checked by an authorized dealer. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 50: Autolamps
10 seconds when you switch the windshield wipers on. The exterior lamps will turn off after a short period of time when you switch the windshield wipers off. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 51: Instrument Lighting Dimmer
Note: If you disconnect the battery or it loses charge the instrument lighting will return to its brightest setting. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 52: Front Fog Lamps
Press the control to switch the fog lamps on or off. 2. Rotate the control to the required setting. 3. Press to close the control. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 53: Cornering Lamps
If you unlock the doors with the remote control, they will come on. They will go off automatically after a short time. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 54: Interior Lamps
If you unlock the doors with the remote control, they will switch on. They will switch off automatically after a short period of time. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 55: Windows And Mirrors
Press the switch fully and release it. Press 6. Open the window and then try to close again or lift it to stop the window. using the one-touch feature. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 56: Exterior Mirrors
Note: Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum or ammonia-based cleaning products. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 57: Sliding Windows
SLIDING WINDOWS Press and hold the unlock button. 2. Slide the window. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 58: Instrument Cluster
Tripmeter Reset and Distance to Empty Press the button to change between the tripmeter and distance to empty information. Press and hold the button to reset the tripmeter. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 59: Warning Lamps And Indicators
Note: Some warning indicators appear in the information display and function the same as a warning lamp but do not illuminate when you start your vehicle. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 60: Engine Warning Lamps
Have your vehicle checked by an authorized dealer immediately. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 61: Front Airbag Warning Lamp
See Information Messages (page 68). It will illuminate when you switch the headlamp high beam on. It will flash when you use the headlamp flasher. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 62: Oil Pressure Warning Lamp
See It will illuminate when you are Tire Pressure Monitoring recommended to shift up or System (page 180). down from the selected gear. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 63: Audible Warnings And Indicators
Sounds when the driver door is open and the exterior lamps are on. Over Speed Warning Sounds when your vehicle exceeds a set speed. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 64: Information Displays
Note: Some options may appear slightly different or not at all if the items are optional. Trip computer Message Trip computer Dist to empty Instant fuel Average fuel Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 65: Information Displays
Lighting Rain light On or Off Hdlamp delay Manual or xx Seconds Display Language Choose your applicable setting Measure unit Choose your applicable setting Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 66 See Information different or not at all if the items are Messages (page 68). optional. SYNC-Media allows you to access the SYNC features. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 67 Text msg notify Emerg. Assist. Menu Message Action SYNC-Settings Bluetooth on Set defaults Master reset Install on SYNC System info Voice settings Browse USB SYNC-Apps Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 68 Personal data Clear last destinations Clear favourites Delete home address Clear all data Reset all settings Audio settings Adaptive volume Sound Nav audio mixing Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 69: Clock
Press and hold OK on the current screen to reset the respective trip, distance, time Indicates the average speed calculated and average fuel information. since the function was last reset. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 70: Personalized Settings
A system-specific symbol with a message indicator may supplement some messages. Airbag Message Description and Action Airbag fault Service now The system has detected a fault that requires service. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 71: Alarm Messages
Refill the diesel exhaust fluid tank. See Selective Catalytic Reduction System (page 102). AdBlue® sys malfunction The system has detected a fault that requires service. Service required Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 72 See Engine Coolant Check (page 157). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 73 Parking Aid Message Description and Action Parking aid malfunction The system has detected a fault that requires service. See Service required Parking Aid (page 114). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 74 Traction Control Message Description and Action Traction control off Indicates that you have switched the traction control system off. See Using Traction Control (page 112). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 75: Climate Control
This is normal. General Information on Controlling the Interior Climate Fully close all the windows. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 76: Manual Climate Control
Select to distribute air through Select to distribute air through the instrument panel air vents the windshield air vents and and footwell air vents. footwell air vents. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 77: Hints On Controlling The Interior Climate
• Adjust the temperature control to the highest setting. • Adjust the air distribution control to the footwell air vents position. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 78: Rear Passenger Climate Controls
Temperature and air distribution control: Controls the temperature of the air circulated in your vehicle. Adjust to select the desired temperature and distribution. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 79: Heated Windows And Mirrors
This may cause damage to the heated grid lines and will not be covered by your vehicle warranty. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 80: Climate Control
Heat now Switches the heater on immediately. Note: You must set the time and date on the clock correctly. See Clock (page 67). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 81 See Information Switching the Heat Now Function On Displays (page 62). Use the information display controls on the steering wheel. See Information Displays (page 62). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 82: Fuel Operated Heater
Displays (page 62). Action Message Settings Convenience Aux heater Press the OK button. An X appears in the box when the system is switched on. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 83: Seats
Sit in an upright position with the base of your spine as far back as possible. • Do not recline the seatback more than 30 degrees. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 84: Manual Seats
Do not adjust the driver seat when your vehicle is moving. Make sure the driver seat fully locks into place by rocking it backward and forward. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 85: Recline Adjustment
Adjusting the Armrest Seat Cushion Adjustment Swivel Seat WARNING Make sure the seat locks into place and is facing forward when your vehicle is moving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 86: Power Seats
See adjust the seat to allow sufficient Changing the 12V Battery (page 159). clearance for it to swivel in a single motion. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 87 Seats Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 88: Rear Seats
Note: Rear seat arrangements vary depending on the vehicle. Recline Adjustment With the seat occupied, pull the lever or strap to recline or raise the seatback. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 89: Installing The Seats
3. Align the seat frame rear catches. 4. Allow the seat to drop under its own weight for the last 6-8 in (15-20 cm). Pull the release handles up. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 90: Heated Seats
• Operate the heated seats unless the engine is running. This prevents the vehicle battery from running out of charge. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 91: Auxiliary Power Points
150 watt load limit and WARNING could result in fire or personal injury. You must close the instrument panel storage compartment lid before driving your vehicle. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 92: Cigar Lighter
The AC power point is not suitable for use with all electrical devices, for example: • Tube type televisions. • Vacuum cleaners. • Power tools. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 93: Storage Compartments
Do not place heavy objects on the Do not place glass objects in the parcel shelf. bottle holder. The maximum permitted evenly distributed loading is 44 pounds (20 kilograms). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 94: Under Seat Storage
3. Tilt the seat cushion forward. Note: If your vehicle has rear air conditioning, it may not have under seat storage below the outer seat. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 95: Front Door Storage Compartment
Storage Compartments Under Seat Storage Guard FRONT DOOR STORAGE COMPARTMENT Turn the retaining clips counterclockwise to open the storage compartment. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 96: Starting And Stopping The Engine
Remove the key from the ignition when you have difficulty starting the switch. engine. 2. Rotate the steering wheel slightly to engage the lock. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 97: Starting A Diesel Engine
2. Turn the key to position III until the • You frequently switch the ignition on engine has started. and off. • Your journeys contain a high level of acceleration and deceleration. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 98: Switching Off The Engine
This will lead to premature turbocharger bearing wear. Release the accelerator pedal. Wait until the engine has reached idle speed and then switch it off. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 99: Unique Driving Characteristics
Stop your vehicle. engine is warm and the outside temperature is within the system operating range. 2. Move the transmission selector lever to neutral. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 100: To Restart The Engine
70 mph (110 km/h). See Eco Mode (page 128). See Speed Limiter (page 124). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 101: Fuel And Refueling
Consult a physician immediately • Always turn off the vehicle before if you experience an adverse reaction. refueling. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 102: Fuel Quality
Do not prise or push open a capless fuel system. This may damage the fuel system or its seal and cause fuel to run onto the ground. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 103: Catalytic Converter
3. Insert the plastic funnel into the filler neck. 4. Add fuel to your vehicle from the fuel container. 5. Remove the plastic funnel from the filler neck. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 104: Selective Catalytic Reduction System
21 liters. contact a physician immediately Note: You must open the fuel filler door before you can open the diesel exhaust fluid filler door. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 105: Diesel Exhaust Fluid Guidelines
Replace the water or any other liquid. diesel exhaust fluid tank cap. • Do not re-use a diesel exhaust fluid container. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 106: Refueling
This can cause damage not covered by the vehicle warranty. Have your vehicle checked by an authorized dealer immediately. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 107: Fuel And Refueling
A may affect the flow of fuel and shut off the fuel pump nozzle before the fuel tank is full. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 108: Fuel Consumption
Switch the ignition off. • Allow no more than two automatic shut-offs when refueling. Results are most accurate when the refueling method is consistent. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 109: Transmission
Do not engage reverse gear when your vehicle is moving. This can cause damage to the transmission. Raise the collar when you select reverse gear. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 110: All-Wheel Drive
When you use all-wheel drive lock mode on normal road surfaces, you may experience some unusual driving characteristics. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 111: Brakes
Wet brakes result in reduced braking efficiency. Gently press the brake pedal a few times when driving from a car wash or standing water to dry the brakes. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 112: Parking Brake
Note: When applied, the parking brake lever will return to the completely down position and a warning lamp will illuminate. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 113: Hill Start Assist
Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 114: Traction Control
Press the button again to return the system to normal mode. Stability control will remain on even when you have switched the traction control off. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 115: Stability Control
This improves your ability to pull away on slippery roads or loose surfaces, and improves comfort by limiting wheel spin in hairpin bends. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 116: Parking Aids
Note: The system may emit false alerts if it detects a signal using the same frequency as the sensors or if your vehicle is fully loaded. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 117: Parking Aids
3 mph (5 km/h) or less. • Objects detected by the rear sensors produce a low-pitched tone from the rear speakers. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 118: Rear View Camera
The camera is on the rear cargo door or liftgate. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 119: Switching The Rear View Camera Off
Green - 24 in (0.6 m) to 71 in (1.8 m). Red - up to 12 inches (0.3 meter). Amber - 12 inches to 24 inches (0.3 meter to 0.6 meter). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 120: Cruise Control
SET+. Canceling the Set Speed Pull CAN toward you and release, or tap the brake pedal. The set speed will not be erased. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 121: Using Adaptive Cruise Control
Do not use the system on icy or slippery roads. Do not use the system when entering or leaving a freeway. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 122: Detection Beam Issues
(C). The detection beam will not follow sharp curves in the road. In these cases the system may brake late or unexpectedly. You should stay alert and intervene if necessary. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 123: Setting The Vehicle Gap
The Note: The system must be in standby system also maintains the set gap and mode. displays this in the information display. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 124: Standby Mode
The engine speed is too low. Note: The recommended gap setting is four • The radar sensor is covered. bars. • You apply the parking brake. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 125 Note: Brake support prepares the braking system for rapid braking by gently applying the brake. You may notice a slight jerk. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 126: Driving Aids
To turn it on, press the switch again. For item location: See Instrument Panel Overview (page 12). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 127: Driver Alert
40 mph (65 km/h). If the sensor becomes blocked the The system automatically monitors your system may not function. driving behavior. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 128: Using Driver Alert
• stopping your vehicle and then opening and closing the driver's door. The alertness level is shown by six steps as a colored bar. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 129: Lane Keeping System
Press the button once to turn the system off. Note: Keep the windshield free from obstructions such as bird droppings, insects and snow or ice. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 130: Eco Mode
A column of lane markings are displayed efficiently by constantly monitoring either side of the vehicle graphic. characteristics of gear changing, anticipation of traffic conditions and speeds while driving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 131: Driving Aids
Efficient speed Reduce your cruising speed on open roads to improve economy. Higher speeds use more fuel. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 132: Load Carrying
Take extra precautions, such as slower speeds and increased stopping distance, when driving a heavily loaded vehicle. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 133: Securing Cargo
Load Carrying Securing Cargo Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 134: Towing
The trailer nose weight (vertical weight suitable for towing trailers with LED lamps. on the tow ball), is essential for the driving stability of your vehicle and trailer. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 135: Trailer Sway Control
Make sure that it is fully tightened. Failure to do so could result in the recovery hook becoming loose. Front Towing Point Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 136: Towing The Vehicle On Four Wheels
Do not use a rigid tow bar on the front towing eye. When towing your vehicle you must select neutral. Drive off slowly and smoothly without jerking the vehicle you are towing. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 137: Driving Hints
See Gauges heavy braking or acceleration. (page 56). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 138: Cold Weather Precautions
This can cause loss of vehicle control. Always correctly install the floor mats to the retention posts so that they cannot slip out of position or obstruct pedal operation. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 139: Driving Hints
To install the floor mats, position the floor mat eyelet over the retention post and press down to lock in position. Remove in reverse order. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 140: Roadside Emergencies
Ask your dealer for advice on roof racks suitable for your vehicle. Break the glass with the hammer in an emergency. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 141: To Connect The Booster Cables
Position the vehicles so that they do three minutes before disconnecting the not touch one another. cables. 2. Switch the ignition off and any electrical equipment. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 142: Roadside Emergencies
Do not switch the headlamps on when disconnecting the cables. The peak voltage could blow the bulbs. Disconnect the cables in the reverse order. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 143: Fuses
Body Control Module Fuse Box For item location: See Under Hood Overview (page 154). Passenger Compartment Fuse Box This is located behind the removable trim panel. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 144: Fuse Specification Chart
FUSE SPECIFICATION CHART Engine Compartment Fuse Box Fuse Fuse rating Circuits protected Selective Catalytic Reduction. Selective Catalytic Reduction. Selective Catalytic Reduction. Selective Catalytic Reduction. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 145 Stability assist pump. Starter solenoid. Glow plugs. Ignition relay 3. Not used. Not used. Not used. 7.5A Fuel injection pump. Not used. Not used. Not used. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 146 Windshield wiper - low and high speed. Not used. Not used. Air conditioning clutch. Fuel vaporizer system glow plug. Fuel injection pump. All-wheel drive pump. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 147: Passenger Compartment Fuse Panel
Passenger Compartment Fuse panel Fuse Fuse rating Circuits protected Airbag module. Heated rear window. Heated exterior mirrors. Not used. Not used. Tachograph. Battery sensor. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 148 Interior lighting. Heated exterior mirrors. Heated front seats. Cornering lamps. Rear parking aid camera. Lane keeping system. Electro mirror. Adaptive cruise control. Not used. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 149 Cigar lighter socket. Rear auxiliary power points. Front auxiliary power points. Ignition relay 1. Ignition relay 2. Left-hand heated windshield element. Right-hand heated windshield element. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 150 Not used. Front blower motor. Rear blower motor. Heated rear window. Heated exterior mirrors. Left-hand heated windshield element. Right-hand heated windshield element. Pre-fuse Box Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 151 Passenger compartment fuse panel. Passenger compartment fuse panel supply. Passenger compartment fuse panel supply. Auxiliary power point 1. Auxiliary power point 2. Auxiliary power point 3. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 152 Circuits protected Central locking system 2. Central locking system 1. Ignition switch. Parking assist control module. Rain sensor module. Windshield washer pump. 7.5A Exterior mirrors. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 153: Changing A Fuse
Switch the ignition and all electrical equipment off before attempting to change a fuse. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 154 A break in the fuse wire will indicate a blown fuse. Check the appropriate fuses before replacing any electrical components. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 155: Maintenance
2. Slightly lift the hood. (page 156). 3. Turn the key clockwise to release the • Brake fluid level. See Brake and hood. Clutch Fluid Check (page 157). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 156: Under Hood Overview - Fwd
8-12 in (20-30 cm). Note: Make sure that the hood is correctly closed. UNDER HOOD OVERVIEW - FWD Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 157: Under Hood Overview - Awd/Rwd
Windshield washer reservoir . See Washer Fluid Check (page 158). Brake and clutch fluid reservoir (right-hand drive). See Brake and Clutch Fluid Check (page 157). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 158: Engine Oil Dipstick
If the oil level is at the minimum mark, add oil immediately. See Technical Specifications (page 170). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 159: Engine Coolant Check
Note: Coolant expands when it is hot. The and consult a physician. level may therefore extend beyond the MAX mark. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 160: Power Steering Fluid Check
If the power steering fluid level is between the MAX and MIN marks add power steering fluid that meets the correct specification. See Technical Specifications (page 170). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 161: Changing The 12V Battery
Remove the cover trim by pulling up the tabs with your fingers. With the engine running the water in fuel indicator lamp will go out after approximately two seconds. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 162 4. Remove the seat runner bolts on both sides. Slide the seat fully forward, making sure the arm rest is folded up. See Seats (page 81). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 163: Checking The Wiper Blades
3. Install in the reverse order. Make sure WARNING that the wiper blade locks into place. Make sure that you securely fasten the seat runner bolts before installing the covers. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 164: Removing A Headlamp
Switch all of the lamps and the ignition off. Failure to do so could result in serious personal injury. Open the hood. See Opening and Closing the Hood (page 153). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 165: Changing A Bulb
4. Disconnect the electrical connector. Headlamp low beam Note: When you install the headlamp make Side lamp sure that you attach the electrical connector correctly. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 166 Note: Do not touch the glass of the bulb. Note: You cannot separate the bulb from the bulb holder. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 167: Side Repeater
2. Remove the small mirror glass. Tilt the mirror glass fully down, pull the mirror glass toward you from the top. 3. Remove the screws. 4. Remove the lamp lens. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 168: Rear Lamps
Remove the screws. 2. Remove the lamp and unclip the bulb holder. 3. Press the bulb in and turn the bulb counterclockwise to remove it. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 169: License Plate Lamp
2. Remove the bulb. Entrance Lamps Reading Lamps Vehicles with Interior Sensors Carefully remove the lamp. 2. Turn the bulb holder counterclockwise and remove it. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 170: Bulb Specification Chart
Brake and tail lamp P21/5W 21/5 Central high mounted brake lamp W16W Chassis cab rear marker lamp Cornering lamp Front direction indicator lamp PY21W Front fog lamp Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 171 Side door entrance lamp 211 Festoon Note: If your vehicle is fitted with LED lamps these are not serviceable items, see an authorized dealer if they fail. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 172: Technical Specifications - Fwd
Warranty. Use oil and fluids that meet the defined specification and viscosity grades. • Longer engine cranking periods. • Increased emission levels. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 173: Technical Specifications - Rwd
7U7J-M2C938-AB Antifreeze Super Plus Premium WSS-M97B44-D 4U7J-19544-xxxx Antifreeze Super Plus Premium Ready Mix WSS-M97B44-D2 2U2J-19544-xxxx Brake Fluid DOT 4 LV High Performance WSS-M6C65-A2 BU7J-M6C65-xxxx Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 174: Technical Specifications - Awd
Specifications Materials Name Specification Engine Oil - 5W-30 WSS-M2C913-C Transmission Oil - 75W FE WSS-M2C200-D2 7U7J-M2C200-BA/CA Gear/Transmission Fluid - 75W90 GL-5 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 175 Increased emission levels. • Reduced engine performance. • Reduced fuel economy. • Degraded brake performance. We recommend that you use Castrol or Ford engine oil. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 176: Vehicle Care
Use a clean, lint free cloth or a damp chamois leather to clean the inside of the Do not use abrasives, or chemical rear window. solvents to clean them. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 177: Repairing Minor Paint Damage
Using other non-recommended cleaning Always read and follow the manufacturer’s products can result in severe and instructions before using the products. permanent cosmetic damage. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 178: Wheels And Tires
158° F). Note: The compressor is located in the load space area on vehicles with rear climate control. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 179: Using The Temporary Mobility Kit
44 psi (3 bar) or if there are any cracks, bumps or similar damage visible, do not continue driving with this tire. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 180: Wheels And Tires
Immediately drive approximately six mobility kit. miles (10 kilometers) so that the sealant can seal the damaged area. 4. Screw the hose C onto the sealant bottle. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 181: Tire Care
E from the tires when you are parking. auxiliary power point, unscrew the sealant bottle hose, fasten the valve cap and replace the protective cap A. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 182: Using Winter Tires
• Affect vehicle handling or stopping characteristics. To reduce this, switch ability. traction control off. See Using Traction Control (page 112). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 183 This is to remind you to repair the damaged road wheel and tire and refit the repaired road wheel and tire assembly to your Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 184 If the tires are correctly inflated and the system malfunction spare tire is not in use but the light remains on, the system has detected a fault that requires service. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 185 4. Carry out the tire pressure monitoring pressure and the warning lamp illuminates. system reset procedure. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 186: Changing A Road Wheel
If the spare wheel is not the same type and 2. Raise the cable end cover. size as your vehicle road wheel, it will have a label showing the maximum speed limit. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 187 If the to lower your vehicle. vehicle slips off the jack, you or someone else could be seriously injured. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 188: Front Jacking Points
Front Wheel Drive Vehicles and Rear Wheel Drive Vehicles up to T370. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 189: Rear Jacking Points
Front Wheel Drive Vehicles and Rear wheel. Wheel Drive Vehicles up to T370. Rear Wheel Drive Vehicles T410 and Over. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 190: Removing A Road Wheel
This can cause the lug nuts to loosen Make sure that your vehicle is on firm while driving. and level ground with the front wheels pointing straight ahead. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 191: Stowing The Wheel And Vehicle Jack
Make sure the wheel is secure. Note: Alloy wheel lug nuts are suitable for use on a steel spare wheel. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 192: Technical Specifications
58 psi (4 bar) 235/65 R16C 48 psi (3.3 bar) 58 psi (4 bar) 350L 235/65 R16C 48 psi (3.3 bar) 65 psi (4.5 bar) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 193 61 psi (4.2 bar) weight 1750 kg 350M, vehicles with maximum front axle 235/65 R16C 51 psi (3.5 bar) 61 psi (4.2 bar) weight 1850 kg Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 194 1750 kg 350M single and double cab, vehicles with 235/65 R16C 51 psi (3.5 bar) 61 psi (4.2 bar) maximum front axle weight 1850 kg Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 195 46 psi (3.2 bar) 195/75 R16C 67 psi (4.6 bar) 55 psi (3.8 bar) 195/75 R16C 67 psi (4.6 bar) 62 psi (4.3 bar) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 196 51 psi (3.5 bar) All vehicles with rear wheel drive. Only fit snow chains to the outer tires on vehicles with dual rear wheels. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 197: Capacities And Specifications
97.7 in (2,481 mm) 109.9 in (2,792 mm) Wheelbase 147.6 in (3,750 mm) Front track 68.2 in (1,732 mm) Rear track 68.6 in (1,743 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 198: Chassis Cab
86.3 in (2,192 mm) 87.4 in (2,219 mm) Wheelbase 123.5 in (3,137 mm) Front track 68.2 in (1,732 mm) Rear track 68.6 in (1,743 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 199: Capacities And Specifications
Overall length 259.0 in (6,579 mm) Overall width including standard or wide Minimum Maximum exterior mirrors 97.4 in (2,474 mm) 108.1 in (2,746 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 200 Front track single wheel and dual wheel 68.2 in (1,732 mm) 68.5 in (1,740 mm) Rear track single wheel and dual wheel 68.6 in (1,743 mm) 65.7 in (1,670 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 201: Motorhome Chassis
Overall height (measured at curb weight) 87.1 in (2,212 mm) Wheelbase 129.9 in (3,300 mm) Front track 68.2 in (1,732 mm) Rear track 68.6 in (1,743 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 202: Towbar Dimensions
68.2 in (1,732 mm) Rear track 68.6 in (1,743 mm) TOWBAR DIMENSIONS Maximum Permissible Nose Weight All Vehicles lb (kg) 247 lb (112 kg) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 203 Capacities and Specifications Van/Kombi/Bus Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 204: Single Chassis Cab
Center of tow ball – center 1.attachment point 9.3 in (237 mm) Center of tow ball – center 2.attachment point 13.5 in (343.5 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 205 Center of tow ball – center 1.attachment point 9.3 in (237 mm) Center of tow ball – center 2.attachment point 13.5 in (343.5 mm) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 206: Vehicle Identification Plate
Note: The information shown on your vehicle identification plate is dependent VEHICLE IDENTIFICATION upon market requirements. PLATE Note: Your vehicle identification plate design may vary to that shown. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 207 You can find your vehicle identification number and maximum weights on a plate, which is located at the bottom of the lock side of the passenger door aperture. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 208: Vehicle Identification Number
24.4 - 38.7 32.5 - 47.9 29.1 - 44.1 (9.7 169 - 255 All vehicles (11.6 - 7.3) (8.7 - 5.9) - 6.4) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 209: Audio System
Do not clean in a circular motion. Do not expose discs to direct sunlight or heat sources for extended periods. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 210: Audio Unit
Make sure you are aware of all applicable home computer and your in-vehicle local laws that may affect the use of system. electronic devices while driving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 211: Audio System
Numeric keypad: Press a button to recall a previously stored radio station. In PHONE mode, you can use the numeric keypad to enter a phone number. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 212 They can be recalled by another source. selecting the appropriate frequency band and pressing one of the preset buttons. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 213 3. Press the OK button to return. announcements will be heard. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 214 A broadcaster may run a fairly large network across a large part of the country. At various times of the day this Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 215 Press the OK button twice to confirm that the contents of your phonebook are downloaded to the system. 2. The Bluetooth device name is displayed on the audio unit. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 216: Making And Receiving Calls
Using the cell phone. Calls can be rejected using the end call button on the audio unit, or by using the cell phone directly. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 217: Bluetooth Audio Streaming
Compatible Bluetooth devices can be switching, the position of playback on the connected to the audio unit to playback USB device is remembered. using the vehicle audio system. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 218: Declaration Of Conformity
Bluetooth enabled car radio is in next and previous track. compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 219: Audio Unit - Vehicles With: Am/Fm/Cd
CD slot: Where you insert a CD. Eject: Press the button to eject a CD. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 220 Scroll to the required frequency band and make the necessary adjustment. The press OK. display indicates the level selected. 4. Press the OK button to confirm the new settings. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 221 If you are already tuned to a station that broadcasts traffic information, TP will also be displayed. Otherwise the unit will search for a traffic program. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 222 When available, automatic volume control adjusts the volume level to compensate for engine noise and road speed noise. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 223: Audio Unit - Vehicles With: Sync/Navigation System
Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 224 PHONE mode, you can use the numeric keypad to enter a phone number. Cursor arrows: Press a button to scroll through on-screen choices. OK: Press the button to confirm on-screen selections. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 225 2. Use the up and down arrow buttons to Press the RADIO button to select from the select the required setting. frequency bands available. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 226 TA or TRAFFIC button. A TA display will Select a frequency band. appear to show the feature is switched on. 2. Tune to the station required. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 227: Digital Signal Processing
Note: If you press TA or TRAFFIC at any other time it will switch all announcements Scroll to the required digital signal off. processing function. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 228 Under certain conditions, however, alternative frequencies tuning may temporarily disrupt normal reception. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 229: Audio Unit - Vehicles With: Sync/Am/Fm/Cd
Make sure you are aware of all applicable 2. Press the MENU button to return. local laws that may affect the use of electronic devices while driving. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 230 PHONE then MENU. AUX: Press the button to access the AUX and SYNC features, it will also cancel the menu or list browsing. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 231 You can repeat this on each frequency locates. band and for each preset button. Manual Tuning Press function button 2. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 232 If a non-traffic station is selected or recalled using a preset button, the audio unit will remain on that station unless TA or TRAFFIC is turned off, then on again. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 233 When the network is not split into regional variants, the whole network caries the same programming. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 234: Digital Radio
3. Press OK to confirm your selection. The radio station name displays below the Note: The display will only show radio ensemble name. stations in the current ensemble. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 235: Audio Input Jack
If you leave the coverage area of a DAB vehicle is moving. radio station the system will automatically switch to the corresponding FM radio station. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 236: Usb Port
General error message for CD fault conditions. For example a mechanism fault. drive too hot Ambient temperature too hot – unit will not work until it has cooled down. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 237: Sync
Access phonebook contacts and music regional Ford website. using voice commands • Stream music from your connected cell phone • Select pre-defined text messages Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 238: Using Voice Recognition
If you connect a media player, the spoken commands. system creates and retains an index of Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 239: Initiating A Voice Session
Command Description voice settings Provides access to change the interaction level. Then any of the following: Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 240 Makes a best guess from the cell phone suggestion list. The system may occasionally ask you questions. phone candidate lists on Clarifies your voice command for cell phone suggestions. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 241: Using Sync With Your Phone
Note: You must switch the ignition and Note: To scroll through the menus, press radio on. the up or down arrows on your audio system. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 242: Cell Phone Voice Commands
You do not need to say "phone" prior to these commands. ([go to] privacy [on] | transfer to phone | handsfree off) (hold call [on] | (put | place) call on hold) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 243 112 (one-one-two), 700 (seven hundred) etc. Pound Number 0 (zero) to 9 (nine) Asterisk clear Deletes all entered digits (delete | correct) Deletes one digit Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 244: Making A Call
Command Action call (someone | [[a] name]) dial [[a] number] Followed by a number. When the system dial [[a] confirms the number say: number] Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 245 Put an active call on hold. When selected, the audio display will indicate the call is on hold. Dial a number Enter numbers using the audio system numeric keypad, for example numbers for passwords. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 246 You can also access advanced features feature. such as emergency assistance. Press the PHONE button to enter the cell phone menu. 2. Select one of the options available. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 247: Text Messaging
Note: This is a cell phone dependent feature. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 248 More... Allows you to delete all messages or to manually trigger a download of all unread messages from your cell phone. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 249: Accessing Your Cell Phone Settings
Phonebook pref. Modify the contents of your phonebook, e.g. add, delete, download. Press the OK button to select and scroll between: Choose from the following: Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 250: Bluetooth Devices
2. When a message to begin pairing appears in the audio display, search for SYNC on your cell phone. Refer to your device's manual if necessary. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 251 2. Select the SYNC settings option, then System Settings press the OK button. 3. Scroll to select from the following Press the MENU button. options: Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 252: Sync Applications And Services
MENU button to access the A list of available applications appears. Emergency Assistance menu. Each application may have its own specific settings. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 253: Sync Emergency Assistance
On and Off Press the MENU button then select: Message Action SYNC-Apps Press OK. Emergency Assistance Press OK. Select the option you require and press OK. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 254: In The Event Of A Crash
The language the system uses to details. interact with the occupants of your vehicle may differ from the language used to deliver information to the emergency operator. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 255: Sync Applink
A crash ejects your cell phone from phone to the USB port. your vehicle. Note: Android users need to connect the phone to SYNC using Bluetooth. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 256 The system will prompt you to say the name of the app to tions) start it. list [mobile] (apps | The system will list all of the currently available mobile apps. applications) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 257 Updates may take place App Status automatically. You can view the current status of an app in the settings menu. There are three possible statuses: Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 258: Using Sync With Your Media Player
Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 259 Choose from the following: Message Play all Playlists Songs Artists Albums Genres Browse USB Reset USB Exit Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 260: What's Playing
Play song <name> <name> is a dynamic listing, meaning that it could be the name of anything such as desired group, artist or song. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 261 | what is) playing [now] | (what | which) (song | track | artist) is this | (who's | who is) playing | (what's | what is) this) Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 262 Bluetooth. Command Description and Action Bluetooth audio Then any of the following: Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 263: Media Menu Features
Each track must have the metadata tags populated for this feature. With certain playing devices, if your metadata tags Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 264: Accessing Your Usb Song Library
Songs Search for and play a specific indexed track. Press OK to select. 2. Scroll to select the desired track, and then press OK. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 265: Sync Troubleshooting
See Using SYNC With tables below. Your Phone (page 239). To check your cell phone's compatibility, visit the regional Ford website. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 266 Try switching off your cell phone, resetting Possible cell phone cell phone to it or removing the battery, then trying again. malfunction. SYNC. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 267 This is a cell phone limita- phone you are pairing. In fact, there can be tion. differences between cell phones due to brand, model, service provider and software version. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 268 I some- To listen to the iPhone or iPod Touch times do not through USB, select Dock Connector. hear any sound. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 269 I want to understand you. See Using Voice Recog- make a call. nition (page 236). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 270 SYNC. playlist names U2) such that you can always use the from my media English pronunciation for these artists. player or USB flash drive. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 271 Why media player (for example, " play artist can I not control Madonna). these systems with SYNC? Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 272 “call John Smith”) or selecting a control and track, artist, album, genre or playlist directly voice prompts). from your media player (for example, play artist Madonna). Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 273: Navigation
SD card, push the card in and release it. Do not attempt to remove the card without first pushing it in. This could cause damage. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 274: Setting A Route
Note: Some options may appear slightly different or not at all if the items are optional. Message Route Active guidance Route sections list Block next section Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 275 POIs nearby Near destination Along motorway POIs near address Search by name Tour planning New tour Stored tours Store position Route options Route Fast Short Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 276: Route Options
Uses the most fuel efficient route. Your driving style will influence this. Fast Uses the fastest route possible. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 277 When switched off the system will avoid ferry crossings and car train facilities on your route and automatically update your route distance and timings. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 278 You can also modify an existing tour or recall a previous tour. The system will automatically calculate and display your chosen journey. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 279 Adding a Favorite 4. Press the OK button to start navigation. Press the NAV button. 2. Scroll to the destination input option. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 280 Auto: Press function button one and using the up or down arrow key select the auto option. Press OK to confirm your setting. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 281: Hazard Spot Warning
The navigation software is based in part Annual navigation map updates are on the work of the independent JPEG available for purchase. See an authorized Group. dealer. Type Approvals Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 282: Appendices
50 W 1, 2 68 – 87.5 50 W 1, 2 142 – 176 50 W 1, 2 380 – 512 50 W 1, 2 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 283: End User License Agreement
("FORD MOTOR COMPANY") from an affiliate of Microsoft Corporation ("MS") . Those installed software products of MS origin, as well as associated media, printed materials, Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 284 Even if you receive multiple EULAs, you are licensed to use only one (1) copy of the SOFTWARE. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 285 COMPANY, third party software and service suppliers, MS, Microsoft Corporation, their affiliates and/or their designated agent to provide or make available to you SOFTWARE updates, Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 286 SOFTWARE onto the DEVICE as a replacement copy for the existing SOFTWARE, and use it in accordance with this EULA, including any additional EULA terms accompanying the upgrade SOFTWARE. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 287 BE PROVIDED FOR YOUR NEW as well as end-user, end-use and VEHICLE. destination restrictions issued by U.S. and other governments. For additional information, see http://www.microsoft.com/exporting/. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 288 User's Guide and read its instructions and safety information carefully. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 289 (b) use your own personal judgment while directions. driving. If you feel that a route suggested by the TeleNav Software instructs you to perform an unsafe or illegal maneuver, Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 290 TeleNav Software (in object code form only) in order to access and use the TeleNav Software. This license shall terminate upon Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 291 American Arbitration Association in the County of Santa Clara, California. The arbitrator shall apply the Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 292 Agreement constitute a waiver of any subsequent breach or default or a waiver of the provision itself. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 293 Data. If you wish to reject the terms of this agreement, and have not Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 294 ACTION ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT, WHICH MAY RESULT FROM THE USE OR POSSESSION OF THIS DATA; OR FOR ANY LOSS OF PROFIT, REVENUE, CONTRACTS Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 295 CONTRACTOR existing between us with respect to such (MANUFACTURER/SUPPLIER) subject matter. ADDRESS: 425 West Randolph Street, Chicago, IL 60606. Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 296 Gracenote ("Gracenote"). Data, the Gracenote Software, and the Gracenote Servers and Gracenote Content, including all ownership rights. Under no circumstances will either Gracenote Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 297 THAT GRACENOTE MAY CHOOSE TO PROVIDE IN THE FUTURE AND IS FREE TO DISCONTINUE ITS ONLINE SERVICES AT ANY TIME. GRACENOTE DISCLAIM ALL Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 298 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 299 Over Speed Warning..........61 Station Tuning Control........229 Parking Brake On...........61 Traffic Information Control......230 Safety Belt Minder..........61 Audio Control............41 Type 1.................41 Type 2...............42 Audio Input Jack...........233 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 300 Cleaning the Interior........174 Instrument Cluster Screens, LCD Screens Capacities and Specifications....195 and Radio Screens.........175 Car Wash Rear Windows............175 See: Cleaning the Exterior........174 Safety Belts............174 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 301 Type 1...............129 Fuel Burning Heater Type 2 and 3............129 See: Auxiliary Heater..........77 Fuel Consumption Figures.......206 Fuel Consumption........106 Calculating Fuel Economy......106 Filling the Fuel Tank..........106 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 302 Courtesy Lamp............52 Hill Start Assist..........111 Entrance Lamps............52 Switching the System On and Off....111 Reading Lamps.............52 Interior Mirror...........54 Using Hill Start Assist..........111 Auto-Dimming Mirror..........55 Introduction............5 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 303 Two-Stage Unlocking.........34 Unlocking..............31 Closing the Hood..........154 Zone Re-Locking..........34 Opening the Hood..........153 Locks..............31 Overhead Console..........91 Lug Nuts Overhead Storage Compartments....91 See: Changing a Road Wheel......184 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 304 Switching the Rear View Camera Off...117 Side Airbags.............29 Switching the Rear View Camera On...116 Side Curtain Airbags........29 Using the Display..........116 Sitting in the Correct Position....81 Vehicles with Parking Aid........117 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 305 Capacities..............172 Principle of Operation........112 Trailer Sway Control........133 Specifications............172 Technical Specifications Transmission..........107 Transmission See: Capacities and Specifications.....195 Technical Specifications - FWD....170 See: Transmission..........107 Capacities..............170 Specifications............170 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 306 Vehicle Care............174 Manual Operation..........40 Vehicle Dimensions........195 Resetting the System.........40 Using Snow Chains........180 Chassis Cab............196 Vehicles with Stability Control......180 Motorhome Chassis..........199 Van/Kombi/Bus..........195 Vehicle Identification Number....206 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 307 Safety Belt Minder Warning Lamp....60 Shift Indicator............60 Stability Control Indicator........60 Stability Control Off...........60 Start-Stop Indicator...........60 Water In Fuel Indicator........61 Warning Triangle...........138 Washer Fluid Check........158 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 308 Transit (TTG) Vehicles Built From: 06-01-2014, Vehicles Built Up To: 31-12-2014, CG3612en enGBR, Edition date: 12/2013...
Page 310 CG3612en...

Ford Transit Owner's Manual

Introduction

At a Glance

Child Safety

Safety Belts

Supplementary Restraints System

Keys and Remote Controls

Locks

Security

Power Running Boards

Steering Wheel

Wipers and Washers

Lighting

Windows and Mirrors

Instrument Cluster

Information Displays

Climate Control

Seats

Auxiliary Power Points

Storage Compartments

Starting and Stopping the Engine

Unique Driving Characteristics

Fuel and Refueling

Transmission

All-Wheel Drive

Brakes

Traction Control

Stability Control

Parking Aids

Cruise Control

Driving Aids

Load Carrying

Towing

Quick Links

Troubleshooting

Related Manuals for Ford Transit

Summary of Contents for Ford Transit
