Ford Transit Connect Quick Reference Manual

ESSENTIAL INFORMATION
TIRE PRESSURE MONITORING SYSTEM REMOTE ENTRY SYSTEM*
Your vehicle is equipped with a tire • Press once to unlock the front and sliding
pressure monitoring system, which doors. Press again within three seconds
alerts you when one or more of your tires to unlock all doors.
is significantly under-inflated. If the low
• Press to unlock the cargo doors.
tire pressure warning light illuminates,
• Press to lock all doors.
stop and check your tires as soon as
NOTE: Your keys are electronically
possible and ensure that they are inflated
coded to your vehicle. Using a non-coded
to the proper recommendations.
key will not permit your vehicle to start.
The recommended specifications can
Replacement keys are available through
be found on the Tire Label or Safety
your authorized dealer. Refer to your
Compliance Certification Label located on
Owner's Manual for more information.
the driver's door jamb or the edge of the
driver's door. Each tire including the spare CENTRAL LOCKING
should be checked monthly and inflated
• To unlock the front and sliding doors,
to the recommended levels. Refer to
insert the key into the driver's door and
your Owner's Manual for more information.
turn it toward the front of the vehicle.
ROADSIDE ASSISTANCE
• To lock all doors, turn the key toward the
rear of the vehicle.
Your new Ford comes with the
assurance and support of 24-hour
Refer to your Owner's Guide for
emergency roadside assistance. To more information.
receive roadside assistance in the United
OPENING THE HOOD
States, call 1-800-241-3673. In Canada,
Your vehicle is equipped with a locking
call 1-800-665-2006.
hood latch located beneath the badge
FUEL FILLER LOCK
on the hood.
Your vehicle is equipped with a lock on the
To open:
fuel filler door.
1. Rotate the
To unlock, simply insert your key into the
hood badge
lock and turn.
counterclockwise
and insert the key.
FUEL TANK CAPACITY /
FUEL INFORMATION
2. Turn the key to
the left to release
Your vehicle has a fuel tank capacity
the primary latch,
of 15.4 gallons (58.3L). Use only
then turn the key to the right
UNLEADED fuel or UNLEADED fuel
to release the secondary latch.
blended with a maximum of 15% ethanol.
Do not use ethanol (E85), diesel, fuel-
3. Lift the hood and support it using
methanol, leaded or any other fuel
the prop rod.
because it could damage or impair the
emission control system.
WARNING:
Driving while distracted can result in loss of vehicle control, accident and injury.
Ford Motor Company strongly recommends that drivers use extreme caution when using any
device or feature that may take their focus off the road. Your primary responsibility is the safe
operation of the vehicle. We recommend against the use of any hand-held device while driving,
encourage the use of voice-operated systems when possible and that you become aware of
applicable state and local laws that may affect use of electronic devices while driving.
LEARN HOW TO SYNC YOUR RIDE
SYNC is a voice-activated technology personalized
by you. It is a hands-free, voice recognition system
used for entertainment and communication.
SyncMyRide.com
SyncMyRide.ca
fordowner.com
Ford Motor Company
Customer Relationship Center
U.S. 1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952)
fordowner.com
ford.ca
Ford of Canada's
This Quick Reference Guide is not intended
Customer Relationship Centre
to replace your vehicle Owner's Manual,
which contains more detailed information Canada 1-800-565-3673 (FORD)
concerning the features of your vehicle,
ford.ca
as well as important safety warnings
designed to help reduce the risk of injury
to you and your passengers. Please read
your entire Owner's Manual carefully as
DT1J 19G217 AA
you begin learning about your new vehicle
June 2012
and refer to the appropriate sections when
First Printing
questions arise.

Quick Reference Guide

All information contained in this Quick
Transit Connect
Reference Guide was accurate at the
Litho in Europe
time of duplication. We reserve the right
to change features, operation and/or
functionality of any vehicle specification
at any time. Your Ford dealer is the best
source for the most current information. For
detailed operating and safety information,
please consult your Owner's Manual.
Quick Reference Guide
TRANSIT CONNECT 2013
