Stylish Design and Premium Performance
Owner's Manual
Please read the content
of your owner’s manual
before operating your
Exeter, PA
St. Catharines, ON
ATTENTION:
power chair.
1-800-800-8586
www.pridemobility.com
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JET 1HD and is the answer not in the manual?

Questions and answers

Alberta
May 30, 2025

What sequence do I install new batteries

0

Related Manuals for Pride Mobility JET 1HD

Summary of Contents for Pride Mobility JET 1HD

  • Page 1 Owner’s Manual ATTENTION: Please read the content of your owner’s manual before operating your power chair. Stylish Design and Premium Performance ® Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
  • Page 2 WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your power chair. Copyright ©2003 Pride Mobility Products Corp. INFMANU1742 www.pridemobility.com Jet1 HD/Rev H/Feb03...

  • Page 3: Table Of Contents

    T A B L E C O N T E N T S INTRODUCTION......................... 4 SAFETY ............................6 III. EMI/RFI ............................14 IV. THE JET 1 HD .......................... 16 ASSEMBLY..........................21 VI. COMFORT ADJUSTMENTS....................24 VII. DISASSEMBLY ......................... 28 VIII. OPERATION ..........................29 IX.

  • Page 4: Introduction

    I N T R O D U C T I O N INTRODUCTION Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride Power Chair. The Pride Power Chair design combines the most advanced state-of-the-art components with modern, attractive styling.
  • Page 5 I N T R O D U C T I O N Pride Owners Club As an owner of a Pride product, you are invited to register your product’s warranty and enroll in the Pride Owners Club. You may do so by filling out and returning your enclosed registration card or by visiting Pride’s web site at www.pridemobility.com.

  • Page 6: Safety

    I I . S A F E T Y SAFETY WARNING! Do not operate your new power chair for the first time without completely reading and understanding this owner’s manual. Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of products to best fit the individual needs of the power chair user.

  • Page 7: Weight Limitations

    I I . S A F E T Y n Check the brakes. See X. “Care and Maintenance.” n Check battery charge. See IX. “Batteries and Charging.” NOTE: If you discover a problem, contact your authorized Pride provider for assistance. Weight Limitations Your power chair is rated for a maximum weight capacity.
  • Page 8 I I . S A F E T Y WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline. Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.

  • Page 9: Freewheel Mode

    I I . S A F E T Y WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibil- ity of a tip or fall. To avoid personal injury and/or property damage, always exercise com- mon sense when cornering. Outdoor Driving Surfaces Your power chair is designed to provide optimum stability under normal driving conditions—dry, level surfaces composed of concrete, blacktop, or asphalt.

  • Page 10: Public Streets And Roadways

    I I . S A F E T Y Figure 2. Curb Approach (Correct and Incorrect) Public Streets and Roadways WARNING! You should not operate your power chair on public streets and roadways. Be aware that it may be difficult for traffic to see you when you are seated on your power chair.

  • Page 11: Motor Vehicle Transport

    I I . S A F E T Y Lift/Elevation Products If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in transportation. Pride recommends that you closely review the instructions, specifications, and safety information set forth by the manufacturer of the lift/elevation product before using that product.

  • Page 12: Reaching And Bending

    I I . S A F E T Y WARNING! Always be sure your power chair and its batteries are properly secured when it is being transported. Failure to do so may result in personal injury and/or damage to your power chair.

  • Page 13: Removable Parts

    I I . S A F E T Y Prescription Drugs/Physical Limitations Users must exercise care and common sense when operating a power chair. This includes awareness of safety issues when taking prescribed or over-the-counter drugs or when the user has specific physical limitations. WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you have certain physical limitations.

  • Page 14: Emi/Rfi

    I I I . E M I / R F I EMI/RFI Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unintended motion of power chairs. Radio waves are a form of electromagnetic energy. When this energy ad- versely affects the operation of an electronic device, it is called Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI).
  • Page 15 I I I . E M I / R F I Are all power chairs susceptible to EMI/RFI? Each make and model of chair differs in its ability to resist electromagnetic interference. That is, each has a particular level of “immunity” to interference, measured in volts per meter (Vm). A higher immunity level offers greater protection.

  • Page 16: The Jet 1 Hd

    I V . T H E J E T THE JET 1 HD The Jet has two main assemblies: the seat and the power base. See figures 2, 2a, and 3. Typically, the seating assembly includes the armrests, seat-back, seat base, and a controller. The Jet seat may also have some optional accessories attached to it, such as a basket, a cane/crutch holder, or a cup holder.
  • Page 17 I V . T H E J E T ARMREST ARMREST HEIGHT ADJUSTMENT SETSCREWS ARMREST WIDTH ADJUSTMENT KNOBS ELECTRONICS TRAY Figure 2a. Rear View Figure 3. Onboard Battery Charger AC Power Cord Jet1 HD/Rev H/Feb03 www.pridemobility.com...
  • Page 18 I V . T H E J E T Specifications Suspension: Limited Drive Wheels: 14 in. solid (pneumatic tires optional) Rear Caster Wheels: 8 in. solid, rear articulating Anti-tip Wheels: 6 in. solid, front mounted Maximum Speed: Up to 4.5 mph Brakes: “Intelligent Braking,”...
  • Page 19 I V . T H E J E T Electronics Tray The electronics tray is located on the back of the power base. See figure 4. The ammeter, the onboard charger AC power cord receptacle, the main circuit breaker, the controller connector, and the charger inhibit connector are all located on the electronics tray.

  • Page 20: Freewheel Levers

    I V . T H E J E T Freewheel Levers For your convenience, the Jet is equipped with two freewheel levers located under the front of your seat. See figures 5 and 6. These levers allow you to disengage the drive motors and maneuver the chair manually. WARNING! Do not use the Jet while the drive motors are disengaged unless you are in the pres- ence of an attendant! Do not disengage the drive motors when the Jet is on an incline.

  • Page 21: Assembly

    A S S E M B L Y To reduce the possibility of shipping damage, your Jet’s seat is removed from the power base, and the seat back is removed from the seat assembly before your Jet is shipped. The joystick may also have been removed from the armrest.

  • Page 22: Seat Installation

    A S S E M B L Y Seat Installation To install the seat: 1. Set the seat on the seat post. See figure 8. 2. Push the seat down until the latch engages. See figure 9. 3. Plug the controller and charger inhibit into the connector on the electronics tray.
  • Page 23 A S S E M B L Y Figure 11. Charger Inhibit Connector SLIDE CONTROLLER INTO BRACKET SETSCREW BRACKET Figure 12. Controller And Bracket Jet1 HD/Rev H/Feb03 www.pridemobility.com...

  • Page 24: Comfort Adjustments

    V I . C O M F O R T A D J U S T M E N T S NUT AND BOLT COMFORT ADJUSTMENTS After you have become familiar with your Jet’s operation, you may find the need to adjust the seat.

  • Page 25: Armrest Angle Adjustment

    V I . C O M F O R T A D J U S T M E N T S Armrest Height Adjustment (op- tional) Your Jet may be equipped with height-adjust- LOOSEN THIS SETSCREW TO ADJUST CONTROLLER. able armrests. See figure 15. To change the armrest height: 1.
  • Page 26 V I . C O M F O R T A D J U S T M E N T S Footrest Height The footrest height is easily adjusted to one of six different heights in 1-inch increments. To raise or lower the footrest: 1.
  • Page 27 V I . C O M F O R T A D J U S T M E N T S 3. Slide the leg rest in or out to the desired length. 4. Tighten the bolt and reinstall the two screws on each leg rest extension.

  • Page 28: Disassembly

    V I I . D I S A S S E M B L Y Seat Removal You may wish to remove the seat for transportation. See figure 23. To remove the seat: 1. Turn the power off. 2. Make sure your Jet is not in freewheel mode. See IV. “The Jet 1 HD.”...

  • Page 29: Operation

    V I I I . O P E R A T I O N The electronic controller is what you use to operate your power chair. It takes the battery voltage and sends it to the appropriate system. For example, when the electronic controller power is on and you move the joystick, you send battery voltage to the motors to move your power chair.

  • Page 30: Speed Control

    V I I I . O P E R A T I O N n Red, yellow, and green lights lit: Battery charged; Pilot and electrical system OK. n Red and yellow lightslit: Charge battery if possible; Pilot and electrical system OK. n Red lights only lit or slow flash: Charge battery as soon as possible;...

  • Page 31: Troubleshooting

    V I I I . O P E R A T I O N WARNING! Under strenuous driving conditions, it is possible for the bottom and side case tempera- ture of the Pilot to exceed 105° F. DO NOT touch the side or bottom of the controller under these circumstances.
  • Page 32 V I I I . O P E R A T I O N VSI CONTROLLER The electronic controller is what you use to operate your power chair. It takes the battery voltage and sends it to the appropriate system. The electronic controller enables you to move the power chair, as well as monitor battery charge, electronic controller functions, and the condition of your electrical system.
  • Page 33 V I I I . O P E R A T I O N On/Off Key The on/off key turns the VSI on and off. WARNING! Unless faced with an emergency situation, do not use the on/off key to stop the chair.
  • Page 34 V I I I . O P E R A T I O N NOTE: We recommend that the first few times you operate your power chair, you set the speed to the slowest setting until you become familiar with your new power chair. Actuator Keys and Actuator Lights (for optional equipment) Actuator keys and actuator lights are used for optional equipment such as power elevating seats or power elevating leg rests.

  • Page 35: Troubleshooting

    V I I I . O P E R A T I O N Troubleshooting The VSI controller is designed with the user’s safety as the prime consideration. It incorporates many sophisticated self-test features which search for potential problems at a rate of 100 times per second. If the VSI detects a problem either in its own circuits or in the power chair’s electrical system, it may stop the power chair, depending on the severity of the problem.

  • Page 36: Batteries And Charging

    I X . B A T T E R I E S A N D C H A R G I N G BATTERIES The Jet uses two long-lasting, 12-volt, deep-cycle batteries. These batteries are sealed and maintenance free batteries. Since they are sealed, there is no need to check the electrolyte (fluid) level. Deep-cycle batteries are designed to handle a longer and deeper discharge.
  • Page 37 I X . B A T T E R I E S A N D C H A R G I N G 3. Remove the battery charger cord from the back pouch of your Jet and plug it into the battery charger AC power cord receptacle located on the electronics tray.
  • Page 38 I X . B A T T E R I E S A N D C H A R G I N G Frequently Asked Questions (FAQs) How does the charger work? The battery charger takes the standard wall outlet voltage of 120 VAC (alternating current) and converts it to 24 VDC (direct current).
  • Page 39 I X . B A T T E R I E S A N D C H A R G I N G What type of battery should I use? We recommend deep-cycle batteries that are sealed and maintenance free. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries that are similar in performance.
  • Page 40 I X . B A T T E R I E S A N D C H A R G I N G How should I store my Jet and its batteries? If you do not use your Jet regularly, we recommend maintaining battery vitality by charging the batteries at least once per week.

  • Page 41: Care And Maintenance

    C A R E A N D M A I N T E N A N C E ROUTINE MAINTENANCE The Jet is a sophisticated power chair. Like any motorized vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from your authorized Pride provider. Preventive maintenance is very important.

  • Page 42: Daily Checks

    C A R E A N D M A I N T E N A N C E n Use a rubber conditioner on the tire sidewalls to help preserve them. WARNING!Never use a rubber conditioner on the tread area of the tires; doing so may make the tires slippery and cause your Jet to skid.

  • Page 43: Cleaning Instructions

    C A R E A N D M A I N T E N A N C E Yearly Checks Take your Jet to your authorized Pride provider for yearly maintenance. This helps ensure that your Jet is function- ing properly and helps prevent future complications. Storage Your power chair should be stored in a dry place, free from temperature extremes.

  • Page 44: Battery Replacement

    C A R E A N D M A I N T E N A N C E Battery Replacement A diagram is printed on a decal located on the Jet frame near the battery tray. WARNING! Pride power chair batteries are heavy. Refer to the specifications table for specific weights.

  • Page 45: Corrective Maintenance

    C A R E A N D M A I N T E N A N C E When to See Your Authorized Pride Provider for Service The following symptoms could indicate a serious problem with your Jet. If necessary, contact your authorized Pride provider.

  • Page 46: Optional Accessories

    X I . O P T I O N A L A C C E S S O R I E S OPTIONAL ACCESSORIES The following accessories are available from your authorized Pride provider. Oxygen Tank Holder The removable oxygen tank holder is mounted to the back of the seat by means of the accessory bracket. Cane and Crutch Holder The removable cane and crutch holder is mounted to the back of the seat by means of the accessory bracket.

  • Page 47: Warranty

    X I I . W A R R A N T Y FIVE-YEAR LIMITED FRAME WARRANTY There will be a five year limited frame warranty on Pride workmanship. One-year limited Warranty For one year from the date of purchase, Pride will repair or replace at our option to the original purchaser free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship: n Plastic components except body...
  • Page 48 Power Chairs Quality Control - Model Thank you for making the Jet 1 HD your choice in power chairs. We have thoroughly inspected your Jet 1 HD. The following checkmarks indicate that it has been driven and inspected. Controller Model #______________ Controller Serial # Serial #______________ Inclusion of all Parts...
