CYBEX VR3 Back Extension Owner's And Service Manual page 34

ITEM QTY PART NO.
1 1 08229
2 1 11040-301
3 1 11040-440
4 1 11040-560
5 1 11070-332
6 1 11080-337
7 2 11090-398
8 2 11090-400
9 1 12000-392
10 1 12000-393
11 1 12000-395
12 2 12000-396
13 4 12000-398
14 1 12000-407
15 1 12050-343
16 1 12050-355
17 1 12090-202
18 1 12090-306
19 1 12090-312
20 4 12090-322
21 1 12100-202
22 1 12100-304
23 1 12100-598-X*
24 1 12100-999-X*
25 1 12101-300
26 1 12102-200
27 1 12102-204
28 2 12210-347
29 2 12210-348
30 2 12210-350
31 1 4000Y316
32 1 4505-331
33 1 4510-321-X*
34 1 4605-381-X*
35 1 51198
36 2 8500-026-X*
37 1 BS070201
38 2 BS070208
39 1 CM000202
40 2 FB030232
41 2 FB030249
42 2 FC030006
43 2 FC030009
44 74" GB000202
45 2 GP000209
46 1 HC700415
47 4 HC700417
48 2 HC700428
49 4 HC700430
50 12 HF579000
51 1 HH320030
52 8 HN704901
53 3 HS347600
54 3 HS347700
55 10 HT512517
Service
Page 6-2
Cybex VR3 12100 Back Extension Owner's Manual
DESCRIPTION
P/PIN,DETENT
CLAMP BLOCK INSERT
KNOB
DECAL, WEIGHT PLATE (10 - 290)
COUNTERWEIGHT
SHAFT PIVOT
END CAP
GRIP 8.75
CHANNEL, INCREMENT WEIGHT
CHANNEL, INCREMENT WEIGHT
TOP CAP
END CAP
SPACER
PANEL INSERT
WASHER
ROTATION DECAL
W/ FOOT REST
SPACER
DECAL FOOT REST
FOOT PAD
CAM
BUMPER MOUNT
PLACARD, VR3 BACK EXTENSION
OWNER'S MANUAL
SPACER
FRAME
INPUT ARM
GUIDE ROD CAP
GUIDE ROD CAP
WT ROD .625 DIA X 49.53
DECAL, CAUTION
BUMPER, 1.50 DIA
DECAL, CAUTION
WARNING LABEL
WARRANTY BOOK (NOT SHOWN)
DECAL, CAUTION
COM SPRING .56 x .66 1.50 LG
COMPRESSION SPRING
DECAL, PATENT PENDING
BEARING, RADIAL 17 mm
EXTENDED RACE
BEARING, RADIAL 35 MM
EXTENDED RACE
TOLERANCE RING 1.575 ID
TOLERANCE RING 72MM
STANDARD WEIGHT STACK BELT
.95 WIDE
PULLEY ASSEMBLY-3.50
BHSCS .375-16 X .75
BHSCS .375-16 X 1.00
BHSCS .375-16 X 2.25
BHSCS .375-16 X 2.50
PANEL FASTNER, 10-24 U TYPE
KEY .313 X .313 X 2.50
LOCKNUT, .375-16 NYLON
WASHER, SAE .375
WASHER, USS .375
TAP SC 10-24 X 1.00 TYPE WB PN
HD PHIL BLK
*Language Key
1-German
2-French
3-Spanish
4-English
6- Japanese
7-Swedish
8-Russian
ITEM QTY PART NO.
56 12 HX570412
57 2 HY740000
58 2 JC700412
59 5 JC700422
60 1 JC700424
61 1 JC780422
62 6 JS347400
63 1 PN660200
64 2 PP130003
65 4 PP660006
66 2 PR060005
67 3 PR740300
68 1 JC780422
69 6 JC700420
70 1 12102-202
71 1 FB030239
72 1 12102-316
73 1 12102-206
74 1 11050-333
75 1 11050-407
76 1 12102-313
77 1 11050-408
78 1 12102-203
79 1 12050-379
80 1 JC700924
81 1 12102-339
82 5 HN704902
83 1 12102-388
84 2 JC700917
85 1 12102-310
86 2 12100-303
87 1 JC620412
88 1 12102-315
89 1 JC620415
90 1 12102-201
91 1 12050-378
92 1 HN624901
93 1 FB130213
94 1 12050-377
95 1 12102-205
96 1 4800-014
97 1 4800-094
98 1 4800-127
99 1 4800-130
100 1 4800-172
101 4 HT570410
102 1 12000-466
103 1 11000-407-X*
104 1 13000-402
105 1 13000-400
106 1 HT552515
107 1 12100-303
108 1 JC620415
109 2 JC700420
110 1 HN625200
111 1 12100-203
112 1 11040-790
DESCRIPTION
BHSCS, 10-24 X .50, SS
SET SCREW
BHSCS .375-16 X .50
BHSCS .375-16 X 1.50
BHSCS .375-16 X 1.75
BHSCS .500-13 X 1.50
LOCKWASHER, INT TOOTH .375
INSERT, PLASTIC 1.00 DIA-11 GA
INSERT, DOMED PLASTIC
PLUG, SNAP IN
BUMPER, WEIGHT
MOUNT, CENTER BONDED
BHSCS, 500-13 X 1.50
BHSCS.375-16 X 1.25
C PIVOT SHAFT
CAM FOLLOWER 10mm
DECAL START CAM
CAM MOUNT
CAM
RETAINER
ECCENTRIC PLATE
SPACER
RH CAM PLATE
PLATE,ROUND MOUNTING
FHSCS .375-16 X 1.75
STOP GUARD
LOCKNUT, .375-16 NYLON
CAM GUIDE
FHSCS .375-16 X 1.00
DETENT PLATE
BUMPER
BHSCS .250-20 X .50
DECAL STOP RLD
BHSCS .250-20 .75
STOP PLATE
DECAL, TOTAL RLD
LOCKNUT, .250-20 NYLON BLK ZN
BRG, FLG 1.375 X 1.625 X .750 LG
DECAL, START RLD
CAM MOUNT
UPPER BACK PAD W/WEAR
COVER
WEAR COVER
LOWER BACK PAD W/WEAR
COVER
WEAR COVER
SEAT PAD
TAP SC 10-24 X 3.75 TYPE WB
PAN HEAD PHIL BLACK
PULLEY COVER
DECAL, INCREMENT WEIGHT
WATER BOTTLE HOLDER MOUNT
WATER BOTTLE HOLDER
TAP SCREW 8-16 X .75
BUMPER
BHSCS .250-20X.75
BHSCS .375 -16 X 1.25
LOCKNUT .250-20 NYLON
INPUT STOP
DECAL, MADE IN U.S.A.
