VR1
Lat/Row
®
Owner's Manual
Strength Systems
Part Number 13250-999-4 E
www.cybexintl.com

Advertisement

Table of Contents
loading

Summary of Contents for CYBEX VR1 Lat/Row

  • Page 1 Lat/Row ® Owner’s Manual Strength Systems Part Number 13250-999-4 E www.cybexintl.com...
  • Page 2: Table Of Contents

    ® DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
  • Page 3: Safety

    It is imperative the floor be level. Cybex recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion of the owner.
  • Page 4 Cybex Owner’s Manual Use the selectorized and plate loaded machines as shown on placards. DO NOT modify the • machine. Never pin the weights in an elevated position. DO NOT use the machine if found in this condition. • Seek assistance from floor staff. Weights pinned up have the potential to fall if the user pulls the pin.
  • Page 5 Death or serious injury will occur if the following requirements are not met: Cybex is not able to anchor the equipment due to local building codes. The owner is responsible for the actual anchoring of equipment. Consult with a professional contractor.
  • Page 6: Securing Equipment

    A minimum pull out force of 220 lbs/100 kgs is required for each anchor position. PROPER USAGE Use equipment only as described in the manual or on the placards located on each machine. Failing to follow proper instructions may result in injury. STANDARD COMPLIANCE Cybex products meets applicable ASTM and EN Standards.
  • Page 7: Warnings And Cautions

    Cybex Owner’s Manual Warnings and Cautions Warning decals indicate a potentially hazardous situation that could result in death or serious injury if the precautions are not observed. Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury.
  • Page 8: Label Placement

    Cybex Owner’s Manual Label Placement 4000Y316-X 8500-311-X 8500-025-X 4000Y316-X 4605-381-X 4000Y316-X...
  • Page 9: Assembly

    Cybex Owner’s Manual Assembly Machine Specifications Total Weight and Size VR1 Lat/Row 13250 Standard Stack Weight Machine Dimensions at Rest Machine Dimensions in Use 496 Lbs 73” L x 50” W x 77” H Same 225 Kg 185 cm L x 127 cm W x 211 cm H...
  • Page 10 Cybex Owner’s Manual 4800-557 Decal, Weight Plate (10-150) (Light) 13000-552 Decal, Weight Plate (10-220) (Standard) NOTES: MATERIAL: EXCEPT AS NOTED DIMENSIONS REMOVE ALL BURRS OWATONNA IN INCHES BREAK SHARP EDGES 1. Font - 40 POINT HELVETICA BOLD. GENERAL .005/.010 R...
  • Page 11 Cybex Owner’s Manual Then 4. Remove guide rod caps. Guide rod cap contains a compression spring that will fly if grasp is not released slowly. Slide spring loaded guide rod cap down guide rod until cap is clear of frame. Slowly release grasp of guide rod cap and remove.
  • Page 12 Cybex Owner’s Manual Securely anchor machine to the floor Cybex strongly recommends to maximize stability, equipment must be secured to a solid level surface. CAUTION: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. WARNING: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8’’ grade 2 bolts or better).
  • Page 13: Environment And Storage

    Cybex Owner’s Manual 3. Place weight stack pin in each plate to verify proper installation. 4. Lift top weight up and down simulating normal operation (without selecting any resistance). 5. Verify that the cable is moving smoothly and is routed straight from the pulley bracket to the top of the weight plate connector.
  • Page 14: Exercise

    Cybex Owner’s Manual Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual.
  • Page 15: Maintenance

    Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. Cybex is not responsible for performing regular inspection and maintenance actions for your machines.
  • Page 16 Cybex Owner’s Manual Clean Upholstery Then 1. Prepare a solution of 10% household liquid soap and warm water. 2. Apply with a soft damp cloth. Light Soiling 3. If necessary, apply a solution of liquid cleanser with a soft bristle brush.
  • Page 17 Cybex Owner’s Manual Clean Chrome Clean chrome tubes, first using chrome polish and then using a car wax seal. Neutral cleaners with a pH between 5.5 and 8.5 are recommended. Be sure to dry thoroughly. AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.
  • Page 18: Weekly Procedures

    Cybex Owner’s Manual Weekly Procedures Inspect All Nuts and Bolts Tighten all loose nuts and bolts as required. WARNING: Serious injury or death may result if the following precautions are not followed. Replace all worn cables and belts. Worn cables and belts can fail if not replaced.
  • Page 19 Cybex Owner’s Manual Belts Condition of Belt 3D View 3D or Side View Peeling of the belt’s skin. Wave in belt Replace belt if any Examine edge of belt (both sides). section is over 1/32” Replace belt if any section is (.03) narrower than the...
  • Page 20: Yearly Procedures

    Cybex Owner’s Manual CAUTION: Personal injury or property damage may occur if the following precautions are not followed. Do not use if less than 1/8” of material remains to the edge. Replace all worn handles immediately. Failure to replace worn handles can result in injury or property damage.
  • Page 21: Cable Adjustment

    Cybex Owner’s Manual Cable Adjustment Tools Required 9/16” Wrench (2) Four types of cable tension adjustment are used on Cybex Strength Systems: Cable Description Diagram Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at...
  • Page 22: Belt Adjustment

    Cybex Owner’s Manual Belt Adjustment Tools Required 7/32” Wrench • Torque wrench (lbs-in) • Belt Adjustment Action 1. Using a 7/32” Allen wrench loose set screws. 2. Pull belt tight. 3. Secure belt in place with set screws. Loose Belt 4.
  • Page 23: Customer Service

    Hours of phone service are Monday through Friday from 8:30 a.m. to 6:00 p.m. Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax 508-533-5183. email address internationaltechhelp@cybexintl.com Find information on the web at www.cybexintl.com.
  • Page 24: Ordering Parts

    Provide the model and serial number of your Cybex equipment. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label.
  • Page 25: Damaged Parts

    Cybex Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent.
  • Page 28 10 Trotter Drive Medway, MA 02053 508-533-4300 FAX 508-533-5183 • • www.cybexintl.com...
