CYBEX VR3 Lat Pull Owner's And Service Manual

Strength systems
Hide thumbs Also See for VR3 Lat Pull:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
®
Cybex VR3
Lat Pull
Owner's and Service Manual
Strength Systems
Part Number 12130-999-4 K
www.cybexinternational.com

Advertisement

Table of Contents
loading

Related Manuals for CYBEX VR3 Lat Pull

Summary of Contents for CYBEX VR3 Lat Pull

  • Page 1 ® Cybex VR3 Lat Pull Owner’s and Service Manual Strength Systems Part Number 12130-999-4 K www.cybexinternational.com...
  • Page 3 Cybex International, Inc. DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.

  • Page 5: Table Of Contents

    Table of Contents 1 Safety Safety......1-1 Safety Guidlines and Practices ..1-2 Warning/Caution Decals .

  • Page 7: Safety

    • Securely anchor each machine to the fl oor using the anchor holes provided in each machine. NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts or better).

  • Page 8: Safety Guidlines And Practices

    SECURING EQUIPMENT: The machine has holes in the feet, which allow for ease in anchoring to the fl oor. Cybex strongly recommends that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a solid, level surface.

  • Page 9: Warning/Caution Decals

    Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance requirements as specifi ed in the manual. STANDARD COMPLIANCE: Cybex products meet or exceed applicable ASTM and EN Standards. Warning/Caution Decals Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury.
  • Page 10 Cybex VR3 12130 Lat Pull Owner’s Manual CAUTION Personal injury may occur. Keep away from moving parts to avoid injury. 4000Y316-4 4605-381-4 A Safety Page 1-4...
  • Page 11 Cybex VR3 12130 Lat Pull Owner’s Manual Lat Pull - 12130 DESCRIPTION PART NO. Warning Decal ....4605-381-4 Caution Decal ....4000Y316-4 Warning Decal ....8500-311-4 Safety Page 1-5...

  • Page 12: Regular Maintenance Activities

    Cybex VR3 12130 Lat Pull Owner’s Manual Regular Maintenance Activities Preventative maintenance activities must be performed to maintain normal operation of your equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities.

  • Page 13: Exercises

    Cybex VR3 12130 Lat Pull Owner’s Manual 2 - Exercise Intended Use MUSCLES USED The intended use of this equipment is to aid or improve general physical fi tness and exercise. For Commercial use. Instructions Read and understand all instructions and warnings prior to using this machine.
  • Page 14 Cybex VR3 12130 Lat Pull Owner’s Manual Set Up 1. Adjust thigh pad for stabilization during exercise. 2. Grasp bar and sit with thighs under pads. Movement 1. Pull bar down until elbows are by your sides and hands are approximately level with shoulders.

  • Page 15: Customer Service

    Fax orders to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers living within the USA) or 508-533-4300 (for customers outside the USA). You may also con- tact us through e-mail at techhelp@cybexintl.com Having the following information ready when calling will assist our Cybex representatives in serving you. •...

  • Page 16: Return Material Authorization (Rma)

    Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA from Cybex, if applicable. Under no circumstances will defective parts or equipment be accepted by Cybex without proper RMA and an Automated Return Service (ARS) label.

  • Page 17: Damaged Parts

    Cybex VR3 12130 Lat Pull Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent.
  • Page 18 Cybex VR3 12130 Lat Pull Owner’s Manual This page intentionally left blank Customer Service Page 3-4...

  • Page 19: Assembly

    Cybex VR3 12130 Lat Pull Owner’s Manual 4 - Assembly TOOLS REQUIRED • 7/32” Allen wrench • 1/8” Allen wrench • Medium weight automotive engine oil • Torque wrench • 3/4” Wrench NOTE: Two people will be required for this procedure.
  • Page 20 Cybex VR3 12130 Lat Pull Owner’s Manual Slide spring loaded top guide rod cap down guide rod until guide rod cap is clear of frame. NOTE: Top guide rod cap is spring loaded. Slowly release grasp of guide rod cap.
  • Page 21 Cybex VR3 12130 Lat Pull Owner’s Manual 6. Belt Routing. Correct belt routing Wrong belt routing Verify belt is routed through top of pulley bracket and Insert Insert then route end of belt down to the top weight. Belt Belt...
  • Page 22 NOTE: It is important that you perform regular inspection and maintenance activities on your equipment. See the CYBEX Owner’s Manual for inspection and maintenance activities. If you do not have a CYBEX Owner’s Manual or if you have any questions or concerns, call CYBEX Customer Relations at 888-462-9239.

  • Page 23: Maintenance

    5 - Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines.
  • Page 24 Do not inhale or swallow any cleaning product. Protect surrounding area/clothing from exposure. Use in well ventilated area. Follow all product manufacturer’s warnings. CYBEX and its vendors can- not be held responsible for damage or injuries resulting from the use or misuse of cleaning products.
  • Page 25 Cybex VR3 12130 Lat Pull Owner’s Manual • Don’t apply cleaners in direct sunlight or at elevated temperatures. • Don’t use scrapers, squeegees or razors. • Don’t clean with gasoline. Compatible Cleaners and Detergents: • Formula 409 • Top Job •...

  • Page 26: Weekly Procedures

    Cybex VR3 12130 Lat Pull Owner’s Manual Weekly Procedures 1. Check all nuts and bolts for looseness. Tighten as required. 2. Inspect all belts (entire length) for any non-uniformity and wear. Immediately replace belt if any of the following conditions are present:...
  • Page 27 Cybex VR3 12130 Lat Pull Owner’s Manual 3. Some machines use cables in addition to belts. Inspect all cables for wear or damage and proper tension. When inspecting cables, run your fingers on the cable, paying particular attention to bends in the cable and attachment points.

  • Page 28: Yearly Procedures

    Cybex VR3 12130 Lat Pull Owner’s Manual 4. Inspect bars and handles for wear, paying particular attention to tab area connecting points. Replace all worn handles immediately. 5. Inspect snap links for proper latching (indicates wear). Replace all worn snap links immediately.

  • Page 29: Environment

    Cybex VR3 12130 Lat Pull Owner’s Manual Environment Static Electricity - Depending upon where you live, you may experience dry air, causing a common experience of static electricity. This may be especially true in the winter time. You may notice a static build-up just by walking across a carpet and then touching a metal object.
  • Page 30 Cybex VR3 12130 Lat Pull Owner’s Manual This page intentionally left blank. Maintenance Page 5-8...

  • Page 31: Service

    Cybex VR3 12130 Lat Pull Owner’s Manual 6 - Service Please refer to the next several pages for parts lists, exploded-view diagrams and cable and belt routing diagrams. NOTE: All inspections and repairs must be performed by trained ser- vice personnel only.
  • Page 32 Cybex VR3 12130 Lat Pull Owner’s Manual This page intentionally left blank Service Page 6-2...

  • Page 33: Exploded-View Diagram

    Cybex VR3 12130 Lat Pull Owner’s Manual LAT PULLDOWN PRODUCT NO. 12130 NOTE: See exploded-view diagram for location of I (serial number decal) DESCRIPTION PART NO. DESCRIPTION PART NO. A. Caution Decal ....4000Y316-X G. Wear Cover (Item F).....4800-093 B. Warning Decal ....8500-311-X H.
  • Page 34 Cybex VR3 12130 Lat Pull Owner’s Manual Service Page 6-4...
  • Page 35 Cybex VR3 12130 Lat Pull Owner’s Manual Service Page 6-5...
  • Page 36 Cybex VR3 12130 Lat Pull Owner’s Manual Service Page 6-6...
  • Page 37 Cybex VR3 12130 Lat Pull Owner’s Manual ROD LOCATION DETAIL Service Page 6-7...
  • Page 38 Cybex VR3 12130 Lat Pull Owner’s Manual BELT ROUTING DETAIL Service Page 6-8...
  • Page 39 Cybex VR3 12130 Lat Pull Owner’s Manual Light Stack Assembly Configuration 12020-020 ITEM PART NO. DESCRIPTION 11040-007 Top Weight Assembly 15 12000-378 Support 12000-384 Panel, Insert 12000-388 Extrusion, Inc Wt Channel 12102-330 Insert, Increment Weight 12210-351 Spacer Tube 12210-352 Plastic Insert...
  • Page 40 Cybex VR3 12130 Lat Pull Owner’s Manual Heavy Stack Assembly Configuration 12020-021 ITEM PART NO. DESCRIPTION 11040-007 Top Weight Assembly 15 12000-378 Support 12000-384 Panel, Insert 12000-388 Extrusion, Inc Wt Channel 12102-330 Insert, Increment Weight 3900-441 Decal, Cybex HF579000 Panel Fastner, 10-24 U Type...
  • Page 41 Cybex VR3 12130 Lat Pull Owner’s Manual 12430 VR3 Lat Pull Graduated Stack Assembly Configuration 12301-007 Assembly ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 11040-216 Belt Clamp BR030206 Ring, Retaining 11040-301 Belt Clamp Insert BR030220 Retaining Ring 1.250 Internal...
  • Page 42 Cybex VR3 12130 Lat Pull Owner’s Manual Top Weight Assembly (Light Stack and Heavy Stack Configurations) ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 11040-366 Top Weight Assembly, Molded HT562715 Tap SC NO 10 x .750 F Phil 11040-367 Hub, Molded HT582510 Tap SC NO 10 x .375 PN...
  • Page 44 10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183 www.cybexinternational.com • techhelp@cybexintl.com...
