Cybex VR3 Torso Rotation Owner's Manual
A
(Both Sides)
K
M
D
I, J
L
NOTE: See exploded-view diagram for location of L (serial number decal),
E. (belt) and N (increment weight decal).
DESCRIPTION
A. Placard Decal .................... 12190-498
B. Caution Decal .................... 4000Y316
C. Caution Decal .................... 4520-362
D. Warning Label ................... 4605-381
E. Weight Stack Belt .............. GB000202
F. Chest Pad w/Wear Cover ... 4800-023
G. Wear Cover ....................... 4800-095
TORSO ROTATION
PRODUCT NO. 12190
E
B
(Both Sides)
DESCRIPTION
PART NO.
H. Seat Pad ........................... 4800-172
I. Thigh Pad w/Wear Cover.. 4201S065-0
J. Wear Cover........................ 4201S076-0
K. Grip ................................... 4605-510
L. Serial Number Decal
M. Weight Selector Pin............. BH030207
N. Increment Weight Decal...... 11000-407
F, G
I, J
H
A
C
PART NO.
Service
Page 6-3
