Optional computer connections

To get sound from the projector, connect an audio cable (optional cable, not
included) to your computer and to the Audio 1 (used with VGA 1) or Audio 2
(used with VGA 2) connector on the projector. You can also assign a your
source to a different audio in connector, see page 25 and page 32
also need an adapter.
If you are using a desktop computer and want to see the image on your
computer screen as well as on the projection screen, connect the computer's
monitor cable to the Monitor Out connector on the projector.
NOTE: Only VGA video is sent to the Monitor out connector.
To display a presentation from a USB flash drive, see the Using LitePort sec-
tion on page 40. This feature converts presentations to JPEG images and
eliminates the need for a computer source. It can also be integrated with
common wall plates and conference room input/output panels.
To advance slides in a PowerPoint presentation using the remote control,
plug the USB cable between the projector's DisplayLink connector and your
computer. Then press the up and down arrow buttons on the remote control
to move through your slides.
Connect monitor cable
You may
.
Connect audio cable
11
audio 5 audio 4 audio 3
L L L audio 1 audio out screen trigger
12V DC
250 mA
wireless
R R R audio 2 IR ready DisplayLink
TM
+5V DC; 2A certified
serial
video 5 video 4 LAN
monitor out
LitePort computer 1
DisplayLink
computer 4 video 3
V H B G R computer 2 computer 3 Y Pb Pr
remote
audio 5 audio 4 audio 3
L L
L audio 1 audio out screen trigger
12V DC
250 mA
wireless
R R R audio 2 IR ready
DisplayLink TM
certified
+5V DC; 2A
serial
video 5 video 4 LAN
monitor out LitePort
DisplayLink computer 1
computer 4
V H B G R video 3
computer 2 computer 3 Y Pb Pr
remote
