Summary of Contents for InFocus IN5312

  • Page 2 Adobe Systems Incorporated. DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are eith er registered trademarks or trademarks of InFocus Corporation in the United States and other countries.
  • Page 3 General Safety Information Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in the unit. For servicing, contact InFocus at www.infocus.com/support Follow all warnings and cautions in this manual and on the unit case.
  • Page 4 Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. Allow at least 50 cm (19.69 inch) clearance around the exhaust vent.
  • Page 5 User’s Manual Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 42 for clear and safe instructions for this procedure. Before replacing the lamp: Unplug the power cord. Allow the lamp to cool for about one hour. Cleaning the Projector Unplug the power cord before cleaning.

  • Page 6: Table Of Contents

    Preface Table of Contents GETTING STARTED................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-angled View ................................ 2 Top view—On-screen Display (OSD) buttons ......................3 Rear view..................................4 Bottom view................................... 6 ..............................7 EMOTE ONTROL ARTS SETUP AND OPERATION..............................9 ........................
  • Page 7 User’s Manual SPECIFICATIONS ................................51 ................................. 51 PECIFICATIONS ........................52 ROJECTION ISTANCE VS ROJECTION ................................ 54 IMING ABLE ..............................56 ROJECTOR IMENSIONS REGULATORY COMPLIANCE............................57 FCC W .................................. 57 ARNING .................................... 57 ANADA WEEE ....................................57 ..............................57 AFETY ERTIFICATIONS —...

  • Page 8: Getting Started

    IN5312/IN5314 – User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR CD-ROM EMOTE CONTROL ’ ATTERIES NOT INCLUDED S MANUAL CABLE OWER CORD EGISTRATION VARIES PER COUNTRY AFETY...

  • Page 9: Views Of Projector Parts

    User’s Manual Views of Projector Parts Front-angled View ABEL ESCRIPTION EE PAGE IR receiver Receives the IR signals from the remote control Lens Projection Lens Focus ring Focuses the projected image Zoom ring Enlarges the projected image Elevator foot Adjusts level of projector See Top view—On-screen Display (OSD) but- Function keys tons.

  • Page 10: Top View-On-Screen Display (Osd) Buttons

    IN5312/IN5314 – User’s Manual Top view—On-screen Display (OSD) buttons ABEL ESCRIPTION EE PAGE MENU Open and exit OSD menus Navigate and change settings in the OSD ◄ (Left cursor) Quick Menu – For Volume Navigate the OSD ▲ (Up cursor) Quick Menu –...

  • Page 11: Rear View

    User’s Manual Rear view ABEL ESCRIPTION EE PAGE DC 12V TRIGGER Connect a 12V screen trigger (200ma max) AUDIO 5 (L and R) Connect the AUDIO CABLE from an input device VIDEO Connect the COMPOSITE CABLE from a video device S-VIDEO Connect the S-VIDEO CABLE from a video device Connect the COMPONENT CABLE from a component video enabled...
  • Page 12 IN5312/IN5314 – User’s Manual Connect the USB CABLE from a computer (used for presentation slide control with the projector remote) HDMI Connect the HDMI CABLE from an HDMI device AUDIO 2 Connect the AUDIO CABLE from an input device DVI-D...

  • Page 13: Bottom View

    EE PAGE Raise and rotate the feet to change and fine tune Leveling/Elevator Feet the angle of the projector. Only use with an InFocus ceiling mount system (p/n PRJ-MNT-UNIV). Ceiling support holes See your InFocus dealer or go to www.infocusstore.com. Note: When installing, ensure that you use only UL Listed ceiling mounts.

  • Page 14: Remote Control Parts

    IN5312/IN5314 – User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 15 User’s Manual ABEL ESCRIPTION EE PAGE Power ON Turn the projector on LED indicator Only lights when the remote keys are pressed Display Mode Choose a suitable preset mode for usage environment Contrast Display the Contrast setting bar and use the right and left keys to adjust Display the Brightness setting bar and use the right and left keys to ad- Brightness just.

  • Page 16: Setup And Operation

    IN5312/IN5314 – User’s Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the di- rection of the arrow. Insert the batteries (not included) as shown in the illustration. Replace the cover.

  • Page 17: Installing Or Removing The Optional Lens

    User’s Manual Installing or Removing the Optional Lens Caution: Do not shake or place excessive pressure on the projector or the lens components as the projec- tor and lens components contain precision parts. Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch.

  • Page 18: Installing The New Lens

    IN5312/IN5314 – User’s Manual Installing the New Lens Align the notches and correctly posi- tion the electrical contact pad as shown in the picture. Note: Pin of IRIS should be in the direction as shown in the picture. Rotate the lens clockwise until you feel it click into place.

  • Page 19: Starting And Shutting Down The Projector

    User’s Manual Starting and Shutting down the Projector Remove the lens cap. Connect the power cord to the pro- jector. Connect the other end to a wall outlet. Verify that the AC Power switch on the back of the unit is turned on.
  • Page 20 IN5312/IN5314 – User’s Manual If more than one input device is connected, press the SOURCE button and use ▲▼ to scroll among devices. • VGA 1 : Analog RGB • VGA 2 : Analog RGB • BNC : Analog / serial digital interface video inputs •...

  • Page 21: Setting An Access Password (Security Lock)

    OSD on page 21 and Setting the OSD Language on page 22 for help on using OSD menus.) Important: Keep the password in a safe place. Without the password, you will not be able to use the projector. If you lose the password, contact InFocus at www.infocus.com/support. Press the MENU button to open the OSD menu.
  • Page 22 IN5312/IN5314 – User’s Manual Use the arrow buttons ▲▼◄► on either the keypad or remote control to enter a password. Any combination can be used, including the same arrow button, but you must use a combination of five arrow button presses.

  • Page 23: Adjusting The Projector Level

    User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. • Remove and discard the foam spacers on the rear leveling feet before adjusting the pro- jection angle.

  • Page 24: Adjusting Projected Image Position Using Shift

    Adjusting the vertical image position The vertical image height can be adjusted between 100% and 40% offset for IN5312 (XGA); 105% and 35% for IN5314 (WXGA) (offset =[(O+H)/H] x100%, O: distance from bottom of image to center of lens).

  • Page 25: Adjusting The Horizontal Image Position

    For example it is not possible to achieve the maximum horizontal image position if the vertical image position is at maximum. Please consult the Shift Range diagram below for further clarification. Shift Range Diagram For IN5312 (XGA) For IN5314 (WXGA) Wx5% Wx5%...

  • Page 26: Adjusting Zoom, Focus And Keystone

    IN5312/IN5314 – User’s Manual Adjusting Zoom, Focus and Keystone Use the Zoom ring to resize the projected im- age and screen size. Use the Focus ring to sharpen the projected image. Use the KEYSTONE buttons (on the projec- tor or the remote...

  • Page 27: Adjusting The Volume

    User’s Manual Adjusting the Volume Press the Volume but- tons (on the projector or the remote control). The volume control appears on the display. Use the Vol +/- buttons (on the projector or the remote control). Press the MUTE button to turn off the audio (This feature is only available on the re-...

  • Page 28: On-Screen Display (Osd) Menu Settings

    IN5312/IN5314 – User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the projector keypad to navigate and make changes to the OSD.

  • Page 29: Setting The Osd Language

    User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3.

  • Page 30: Osd Menu Overview

    IN5312/IN5314 – User’s Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 23 –...

  • Page 31: Osd Sub-Menu Overview

    User’s Manual OSD Sub-Menu Overview – 24 –...

  • Page 32: Image Menu

    IN5312/IN5314 – User’s Manual Image Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to change setting values.

  • Page 33: Advanced Features

    User’s Manual Advanced Features Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Ad- vanced menu.
  • Page 34 IN5312/IN5314 – User’s Manual Color Manager (Enter) / ► to enter the Color Manager sub menu. Press ESCRIPTION Select to enter the Red Color Manager. Press the ◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the Green Color Manager.

  • Page 35: Computer Menu

    User’s Manual Computer Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Computer menu. Press the cursor ▲▼ button to move up and down in the computer menu. Press ◄► to change setting values.

  • Page 36: Video/Audio Menu

    IN5312/IN5314 – User’s Manual Video/Audio Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Video/Audio menu. Press the cursor ▲▼ button to move up and down in the Video/Audio menu.

  • Page 37: Audio

    User’s Manual Audio (Enter) / ► to enter the Audio sub menu. Press ESCRIPTION Press the ◄► buttons to adjust the audio volume. Volume Press the ◄► buttons to turn the speaker on or off. Mute – 30 –...

  • Page 38: Installationi Menu

    IN5312/IN5314 – User’s Manual Installation I Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion I menu. Press the cursor ▲▼ button to move up and down in the Installation I menu. Press ◄►...

  • Page 39: Advanced

    User’s Manual Advanced (Enter) / ► to enter the Advanced sub menu. Press ESCRIPTION Press the cursor ◄► button to enable or disable security lock function. Security Lock When displaying the image against a wall, press the cursor ◄► button to select dif- Wall Color ferent wall color settings.

  • Page 40: Installation Ii Menu

    IN5312/IN5314 – User’s Manual Installation II Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion II menu. Press the cursor ▲▼ button to move up and down in the Installation II menu.

  • Page 41: Advanced Features

    User’s Manual Advanced Features Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu.
  • Page 42 IN5312/IN5314 – User’s Manual OSD Menu Setting ESCRIPTION Press ◄► button to move the OSD menu position. Menu Position Press ◄► button to select OSD background translucent level. Translucent Menu Press ◄► button to select OSD timeout delay. Menu Display...
  • Page 43 User’s Manual Lamp Hour Reset Please refer to Replacing the Projection Lamp on page 42 to reset the lamp hour counter. Select the correct 3D setting for your 3D glasses: - Select DLP-Link™ if your glasses are compliant with Texas Instruments’ DLP 3D standard. This type of glasses do not require an external trigger, they are triggered by the projected image.
  • Page 44 IN5312/IN5314 – User’s Manual Network State ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields. IP Address Enter a valid IP address if DHCP is turned off.
  • Page 45 User’s Manual For simplicity and ease of operation, the projector provides diverse networking and remote management fea- tures. The LAN/RJ45 feature allows the projector to be connected to a network and remotely managed. Available remote management controls include: Power On/Off, Video-Source, Brightness and Contrast settings, Sound- Mute, etc.
  • Page 46 IN5312/IN5314 – User’s Manual Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex- ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Mail Settings.
  • Page 47 User’s Manual The From field is the sender’s email address (for example, the projector administrator). This is a required field. Select the alert conditions by checking the desired boxes. Note: Fill in all fields as specified. Select the desired alert condition and click Submit to con- duct an Email Alert Test.

  • Page 48: Factory Reset

    IN5312/IN5314 – User’s Manual Factory Reset Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Factory Re- (Enter) / ► to reset all the menu items to factory default values (except set sub menu and press Language, Network Settings and Security Lock).

  • Page 49: Maintenance And Security

    ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. Be sure to use the InFocus lamp module de- signed for this projector. You can order new lamps from www.infocusstore.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. Use of non InFo- cus lamps may cause electrical shock and fire, and may void the projector warranty.
  • Page 50 IN5312/IN5314 – User’s Manual Loosen the captive screw on the lamp cover. Pull up and remove the cover. Use a screwdriver to re- move the two captive screws from the lamp module. Pull out the lamp module. – 43 –...
  • Page 51 User’s Manual Reverse steps 1 to 7 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the screws.

  • Page 52: Cleaning The Projector

    IN5312/IN5314 – User’s Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 60 minutes before cleaning. Failure to do so could result in a severe burn.

  • Page 53: Troubleshooting

    Common Problems and Solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact InFocus at www.infocus.com/support Often the problem is traced to something as simple as a loose connection. Check the following before proceeding to problem-specific solutions.

  • Page 54: Led Error Messages

    IN5312/IN5314 – User’s Manual LED Error Messages Error Code Messages PWR LED TEMP LED READY LED Over temperature Solid Red Thremal break Flashing Red 4x Lamp strike fail Flashing Red 5x Flashing Red 1x Ballast said Lamp off Flashing Red 5x...

  • Page 55: Lamp Problems

    User’s Manual Problem: The image is streaked 1. Set the Frequency and Tracking settings on the Computer menu of the OSD to the de- fault settings. 2. To ensure the problem is not caused by a connected PC’s video card, connect to another computer.

  • Page 56: Audio Problems

    3. Have the projector serviced. Having the Projector Serviced If you are unable to solve the problem contact InFocus Technical Support at www.infocus.com/support. If your projector needs repair, pack the projector in the original carton and include the return authorization number on the outside of the box.

  • Page 57: Hdmi Q & A

    User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 58: Specifications

    IN5312/IN5314 – User’s Manual PECIFICATIONS Specifications Model IN5312 IN5314 Display type TI DMD XGA 0.7” TI DMD WXGA 0.65” Native Resolution 1024x768 1200x800 Projection distance 1.5 meters ~ 7 meters ( 4.92 ft ~ 22.97 ft ) (standard lens) Projection screen size 37.3"...

  • Page 59: Projection Distance Vs. Projection Size

    User’s Manual Projection Distance vs. Projection Size For XGA Projection Distance Standard projection lens: TR: 1.6~2; offset=100% IN5312 1.63/ 3.25/ 4.06/ 8.13/ 1.63/ 3.25/ 6.50/ 9.75/ Distance (m/inch) Diagonal (inch/ ft) 40/3.3 80/6.7 100/8.3 200/16.7 50/4.2 100/8.3 200/16.7 300/25 Keystone Correction angle 10.62...
  • Page 60 IN5312/IN5314 – User’s Manual For WXGA Projection Distance Standard projection lens: TR: 1.6~2.03; offset=105% IN5314 1.75/ 3.50/ 4.37/ 8.74/ 1.74/ 3.49/ 6.98/ 10.47/ Distance (m/inch) Diagonal (inch/ ft) 40/3.3 80/6.7 100/8.3 200/16.7 50/4.2 100/8.3 200/16.7 300/25 Keystone Correction angle 9.61 9.61...

  • Page 61: Timing Mode Table

    User’s Manual Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. HDMI OMPOSITE IGNAL ESOLUTION / S-V IDEO ANALOG DIGITAL － － NTSC — 15.734 60.0 － －...
  • Page 62 IN5312/IN5314 – User’s Manual HDMI OMPOSITE IGNAL ESOLUTION / S-V IDEO ANALOG DIGITAL — 720p 37.5 50.0 — 720p 45.0 60.0 — 1080i 33.8 60.0 — 1080i 28.1 50.0 — HDTV 1080p 24.0 — 1080p 28.13 25.0 — 1080p 33.75 30.0...

  • Page 63: Projector Dimensions

    User’s Manual Projector Dimensions – 56 –...

  • Page 64: Regulatory Compliance

    IN5312/IN5314 – User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
