Summary of Contents for InFocus IN5533

  • Page 2 Input ratings: AC 100-240V, 9.5-3.5A, 50-60Hz of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either InFocus reserves the right to alter product offerings and specifications at any time registered trademarks or trademarks of InFocus Corporation in the United States without notice.

  • Page 3: Table Of Contents

    Table of Contents Introduction Positioning the projector Ceiling Mount Cable management Connecting power Connecting a computer source Optional computer connections Displaying an image Adjusting the image Connecting a video device Video device connections Shutting down the projector Troubleshooting your setup Using the remote control Using the audio Using the keypad buttons...
  • Page 4 Locate the projector at least 4' (1.2m) away from any heating or cooling vents. • Only genuine InFocus lamps are tested for use in this projector. Use of non • Do not block ventilation openings. Locate the projector in a well-ventilated InFocus lamps may cause electrical shock and fire, and may void the projector area without obstructions to intake or exhaust vents.
  • Page 5 IMPORTANT: Unpacking/Transport Notes for the IN5533 and IN5535 When unpacking your projector, remove the black Lens Protector Ring from around the lens in order to allow full movement of the lens. KEEP the Lens Protector Ring for future transport purposes. The Lens Protector ring should be re-installed before transporting the projector to prevent damage to the lens shift mechanism.

  • Page 6: Introduction

    It is a versatile projector that is flexible enough for business presentations DisplayLink Wireless Adapter, and LiteShow II. These items and other accessories and home video viewing, too. The IN5533 and IN5533L have WXGA 1280x800 can be found on our website at www.infocus.com or at your local dealer.
  • Page 7 (powered off) if Network and DisplayLink items in the Always-On Functions submenu are set to Yes. It is designed to provide power to an InFocus LiteShow II wireless device or InFocus DisplayLink Extender device.

  • Page 8: Positioning The Projector

    Positioning the Projector To determine where to position the projector, consider the size and shape of your Vertical Image Offset is 50 - 110% screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Here are some general guidelines: •...

  • Page 9: Ceiling Mount

    It is not recommended you install the projector yourself. • We strongly recommend using InFocus approved ceiling mounts for proper fitting, ventilation and installation. Refer to the installation guide that comes with the InFocus Ceiling Mount Kit (p/n SP-CEIL-INSTALL) for more information.

  • Page 10: Connecting Power

    Macintosh: A folder will open containing a file named DisplayLink Installer.pkg. Open that file and follow the instructions on the screen. * For detailed DisplayLink instructions and troubleshooting, and to download the latest DisplayLink software, go to www.infocus.com/support/displaylink. VGA connection Connect computer cable Connect one end of the provided computer cable to the VGA 1 or VGA 2 connector on the projector and the other to the VGA connector on your computer.

  • Page 11: Optional Computer Connections

    Optional computer connections Connect monitor cable To get sound from the projector, connect an audio cable (optional cable, sold separately) to your computer and to the Audio 1 (used with VGA 1) or Audio 2 (used with VGA 2) connector on the projector. You can also assign your source to a different audio in connector, see page 24 and page 31 You may also need an adapter.

  • Page 12: Displaying An Image

    No laptop image? Try pressing the Auto Image button on the keypad or remote. Get help on page 25. Is your laptop connected to the projector's DisplayLink connector? See the InFocus DisplayLink Software User's Guide (available on the InFocus website at www.infocus.com/displaylink) for troubleshooting information.

  • Page 13: Adjusting The Image

    Adjusting the image Adjust distance Position the projector to the desired distance from the screen at a 90 degree angle to the screen. See the Appendix for screen sizes and distances associated with the various lens options. If the image is square but not centered on the screen or viewing area, adjust Zoom Adjust zoom, focus and or Focus in the Basic Picture menu.

  • Page 14: Connecting A Video Device

    1 or VGA 2 connector on the projector. Video device connections Component video connection No video cables are provided with the projector. You can order cables from InFocus Plug the component cable into the video device. Plug the other end of the or use your own.
  • Page 15 What is Aspect Ratio? 4:3 screen 16:9 screen Aspect ratio is the ratio of the image width to image height. Standard TV screens and older laptops are 4:3; HDTV and most DVDs are 16:9; and widescreen computers are 16:10. If you are projecting onto a screen, the size/shape of the screen will influence the aspect ratio you decide to use.

  • Page 16: Shutting Down The Projector

    The projector is too hot. Make sure the vents aren’t blocked (see page 21). Turn the projector off and wait one minute, then turn the projector on again. Contact Technical Support if the problem persists. Visit www.infocus.com/support to contact service. Lamp Turn the projector off and wait one minute, then turn the projector on again.
  • Page 17 Problem Solution Result No start up screen. Correct image. Plug the power cord into the projector then press the power button. If your computer is using the projector's DisplayLink connector, see the DisplayLink Computer image projected. Only the start up screen appears. Software User's Guide for troubleshooting information.
  • Page 18 Problem Solution Result No computer image, just the words “Signal out of Press the Auto Image button on the keypad or remote. To Computer image projected. adjust computer refresh rate, go to Control Panel > Display range.” > Settings > Advanced > Adapter (location varies by operating system).
  • Page 19 Problem Solution Result Image fuzzy or cropped Set your computer’s display resolution to the native Image clear and not cropped. resolution of the projector (Start > Settings > Control Panel > Display > Settings tab). For a laptop, disable laptop monitor or turn- on dual-display mode...
  • Page 20 Problem Solution Result Image not square. Adjust Keystone in the Basic Picture menu. Square image. Image not sharp. Adjust Sharpness in the Basic Picture menu. Correct image. Image does not fit 4:3 or 16:9 screen. Change aspect ratio to 4:3 or 16:9 in Basic Correct image.
  • Page 21 Problem Solution Result Image upside down. Turn off Ceiling Mount in Setup menu. Correct image. Image reversed left to right. Turn off Rear Project in Setup menu. Correct image. Projected colors don’t match source. Adjust color, tint, brightness, contrast in the Basic Correct image.
  • Page 22 Problem Solution Result The video embedded in my PowerPoint If your computer is using the projector's DisplayLink Embedded video plays correctly. presentation does not play on the screen. connector, see the DisplayLink Software User's Guide for video troubleshooting information. Turn off the internal LCD display on your laptop. Lamp won’t turn on, Temperature light is on.
  • Page 23 Lamp door Replace lamp Still need assistance? If you need assistance, visit our support website at www.infocus.com/support or call us. Check out the How To section for additional information on using this projector for home theater or gaming applications. This product is backed by a limited warranty. An extended warranty plan may be purchased from your dealer.

  • Page 24: Using The Remote Control

    Using the remote control • Mute button to silence the audio. • Auto Image button to resynchronize the projector to the source. The remote uses two (2) AA batteries. You can install the batteries by removing the • Resize button to switch among aspect ratios (see page 28). cover from the remote’s back, aligning the + and - ends of the batteries, sliding them into place, and then replacing the cover.

  • Page 25: Using The Audio

    Adjust volume • If your computer is using the projector's DisplayLink connector, see the InFocus DisplayLink Software User's Guide on the website at www.infocus.com/displaylink for audio troubleshooting information. • Make sure the audio cable is connected to the correct audio in connector, Computer or Video.

  • Page 26: Using The Keypad Buttons

    Help–button to access the projector’s help feature (page 33) • If your computer is using the projector's DisplayLink connector, see the InFocus DisplayLink Software User's Guide for information about optimizing images. Presentation features Several features are provided to make giving presentations easier. Here is an overview, details are found in the menu section.

  • Page 27: Optimizing Video Images

    Using command codes, text messages can be sent for display by the projector (and can optimize the image using the onscreen menus. For general information on using all other InFocus projectors with the Dynamic Messaging feature) over a network or the menus, see page 27.

  • Page 28: Using The Menus

    Using the menus To open the menus, press the Menu button on the keypad or remote. (The menus automatically close after 60 seconds if no buttons are pressed.) Use the arrow buttons to move up and down to highlight the desired menu, then press the Select button.

  • Page 29: Basic Picture Menu

    Basic Picture menu Digital Zoom: Changes the size of projector’s display area. If the display area has been resized by this setting, it can be moved by changing the Horz Shift and Vert To adjust the following settings, highlight the setting, press Select, use the arrow Shift settings.

  • Page 30: Advanced Picture Menu

    Advanced Picture menu Color Offset Settings: Adjusts the offset of the red, green, or blue channel of the image. BrilliantColor™: Produces an expanded onscreen color spectrum that delivers Horizontal/Vertical Position: Adjusts the position of a computer source. enhanced color saturation for bright, true-to-life images. Choose Normal Look for most video sources and Bright Look for most computer sources.

  • Page 31: Setup Menu

    Setup menu • Overscan: Removes noise around the image. • AV Mute: Enables or disables AV Mute function. Language: Allows you to select a language for the onscreen display. • Closed Captions: Enables or disables Closed Captions. Network: Allows you to setup network settings. See page 34 for details on network •...
  • Page 32 Current Lamp: Controls which lamp(s) is in use. Search Screen: Allows you to display one of the following options instead of the default screen at startup, and when no source is detected. Options include the Lamp Auto Switch: Controls when the projector switches between lamps. Choices factory logo screen, a custom Snapshot, or a blue, black or white screen.

  • Page 33: Status And Service Menu

    Select OK or Cancel by pressing the Select button. Verify the new PIN. If you lose or forget your custom PIN: Contact InFocus support at www.infocus.com/support. Serial Port, Baud Rate: Selects the serial port and baud rate. Serial Port Echo: Controls whether the serial port echoes characters.

  • Page 34: Help

    Take Snapshot command in the Setup menu. When you see the Snapshot Successful message, hold down the Help button until the message is removed. To revert a customized Help screen back to the InFocus default Help screen, a Factory Reset will be needed.

  • Page 35: Using Network Functions

    For network control, you can access the projector through Port 23 (Telnet). We use NOTES: the same control codes on serial as we do over the network. InFocus network • To access the projector’s web pages, the projector must be connected to the control uses the Telnet packet structure.
  • Page 36 For command codes, see the • Apply: Saves the values that are currently shown on the page. Appendix or visit the InFocus website at: www.infocus.com/support. Projector Controls Page (All users) This page lets you control the same settings that are available via the projector's main menu and remote control.
  • Page 37 Commands list. The RS-232 command codes are available in the Appendix and on our website at www.infocus.com/support. NOTE: Custom commands you enter Daylight Savings Settings: Click this link to show daylight savings settings: here should be in write format (do not include '?'), and should use '<' and '>' instead Start: Select when daylight savings starts.
  • Page 38 This page lets you configure security options for the projector, including log in • If your web browser displays Page Not Found or a similar error when you try passwords and projector access restrictions. to access the projector's web pages, verify that the projector is connected to the network (select the Network item in the Web Access - Administrator tab: Select whether or not Administrators must enter projector's Setup menu and verify that Network Status shows as...

  • Page 39: Using Liteport

    Using LitePort To start the slide show: While viewing thumbnails, press the arrow buttons to highlight a thumbnail, then press the Select button to start the slide show at the LitePort displays a slide show of JPEG images stored on a USB flash drive highlighted image.
  • Page 40 (For remaining items below, highlight the setting, then press Select one or more Click the Office button in the upper left corner of the PowerPoint document times to change the setting value.) window. Auto Start: Select On to have the player start the slide show when the USB flash Point to Save As, then click Other Formats.
  • Page 41 Troubleshooting LitePort • If images load slowly: Make sure you are using a newer USB 2.0- compatible (high speed) USB flash drive. Larger image file sizes may also slow down the player; to reduce file size, use an image editing program on your computer to resize images smaller;...

  • Page 42: Maintenance

    Maintenance Cleaning the lens Turn the projector off and unplug the power cord. Apply a non-abrasive camera lens cleaner to a soft, dry cloth. • Avoid using an excessive amount of cleaner, and don’t apply the cleaner directly to the lens. Abrasive cleaners, solvents or other harsh chemicals might scratch the lens.

  • Page 43: Cleaning The Lens

    You can order new lamps from www.infocus.com (in select areas), your Wait 60 minutes to allow the projector to cool thoroughly. retailer or your dealer. Only genuine InFocus lamps are tested for use in this Remove the lamp door: projector. Use of non InFocus lamps may cause electrical shock and fire, and may void the projector warranty.
  • Page 44 Turn off and Wait 60 unplug projector minutes (3b) (3c) SP-LAMP-055 SP-LAMP-056 (Lamp #1) (Lamp #2) (3a) (3a)

  • Page 45: Rs-232 Commands

    Replacing the lens Remove the top cover by: (a) Releasing the left and right latches on both sides of the projector. (b) Sliding the top front cover in the direction of the lens. Loosen the four screws then lift the lens door.
  • Page 46 Remove the lens by: (a) Pushing the release lever up to release lock (b) Removing the lens through the front of the projector Install the new lens by: (a) Inserting the new lens into the projector, label side up, through the front of the projector (b) Aligning the alignment pins at the top of the lens retaining frame and insert into the front of the engine.

  • Page 47: Using The Security Lock

    Using the security lock The projector has a security lock for use with a Cable Lock System. Refer to the information that came with the lock for instructions on how to use it. Security lock...

  • Page 48: Appendix

    Appendix Projection WUXGA WXGA Projected image size Size: Projection Distance (inch/ Projection Distance (inch/ Standard Lens m) +/-10% m) +/-10% NOTE: Visit the Service section of our website for interactive image size calcula- tors for the standard and optional lenses. Screen Size Maximu (inch/m)

  • Page 49: Optional Lenses

    Projection Distance Projection Distance lens. Lens (inch/m) +/-10% (inch/m) +/-10% NOTE: You can order optional lenses from www.infocus.com (in select areas), your retailer or your dealer. Screen Size (inch/m) 30/0.8 20/0.5 21/0.5 Fixed Short Throw Lens Features and Specifications (LENS-050): 40/1.0...
  • Page 50 Short Throw Lens Features and Specifications (LENS-051): • Focal Length: 18.1-21.7 • Screen Size: 30-500 inch • Motorized Zoom and Focus • Zoom Ratio: 1.20:1 • Lens Shift Position: 50-110% Vertical; +/-10% Horizontal • Throw Distance Ratio: 1.21-1.45: 1 (WUXGA); 1.27-1.52:1 (WXGA) •...
  • Page 51 Long Throw Lens Features and Specifications (LENS-052): • Focal Length: 28.6-54.3 • Screen Size: 30-500 inch • Motorized Zoom and Focus • Zoom Ratio: 1.90:1 • Lens Shift Position: 50-110% Vertical; +/-10% Horizontal • Throw Distance Ratio: 1.93-3.67 (WUXGA); 2.03-3.85:1 (WXGA) •...
  • Page 52 Ultra Long Throw Lens Features and Specifications (LENS-053): • Focal Length: 54.1-102.7 • Screen Size: 30-500 inch • Motorized Zoom and Focus • Zoom Ratio: 1.90:1 • Lens Shift Position: 50-110% Vertical; +/-10% Horizontal • Throw Distance Ratio: 3.67-6.97:1 (WUXGA); 3.85-7.32:1 (WXGA) •...

  • Page 53: Splitscreen Compatibility

    SplitScreen Compatibility secondary source image displayed on top of the primary source in one of four placement options. See page 28 for details. The following source combinations are Splitscreen allows two distinct sources to be displayed simultaneously. Switch supported: primary sources, make picture adjustments and choose one of multiple display options: either two side by side horizontal or vertical source regions, or a small Table 2: DisplayLi...
  • Page 54 Network Communication Configuration Write Command Examples For network control, you can access the projector through Port 23 (Telnet). We use the same control codes on serial as we do over the network. InFocus network control Function Command Response uses the Telnet packet structure.
  • Page 55 Error Conditions Auto Off Time Not all commands are supported for all projectors. If an unsupported command is issued, the 0: Never command will be ignored. If a command is received that is not understood, a ‘?’ character will 1: 5 minutes be returned indicating the command was not understood.
  • Page 56 Color Space Detect Film 0: RGB 0: Disable; 1: Enable 1: REC709 Digital Zoom 2: REC601 3: RGB Video Disable Snapshots 4: Auto 1: Disabled (Flash needed to re-enable.) Color Temp Source 0: Warmest Specific DisplayLink Source 1: Warm Enable: 1 2: Cool 4: Bright Dual Lamp Auto Switch...
  • Page 57 Factory Reset Key Click 1: Reset 0: Disable; 1: Enable Fast Color Refresh Keypad Enable 0: Off 0: Disable; 1: Enable 1: Video only Lamp 1 High Power Hours 2: On (all sources) ? = Query Flesh Tone Correction Lamp 1 Low Power Hours Force Wide ? = Query 0: Disable;...
  • Page 58 Language LitePort Next Slide 0: English (9 for China 0: Disable; 1: Enable 1: French models) LitePort Show All Folders 2: German 0: Disable; 1: Enable 3: Italian 5: Korean LitePort Show Info 6: Norwegian 0: Disable; 1: Enable 7: Portuguese 8: Russian LitePort Source Command 9: Simp Chinese...
  • Page 59 Menu Motorized Zoom In 0: Clear; 1: Display 1: Execute Menu Lockout Motorized Zoom Out 1: Basic Picture 1: Execute 2: Adv Picture Mute 4: Setup Menu 0: Disable; 1: Enable 8: Status & Service 15: All Menus Network Default Gateway GT1 = 1st Octet Menu Navigation GT2 = 2nd Octet...
  • Page 60 Network Restart Power-up Source 1: Restart 0: DisplayLink 1: VGA 1 Network Subnet Mask 2: VGA 2 NM1 = 1st Octet 3: RGBHV NM2 = 2nd Octet 4: LitePort NM3 = 3rd Octet 5: HDMI 1 NM4 = 4th Octet 6: HDMI 2 7: Component Noise Reduction...
  • Page 61 Projector Model string Serial Port Baud Rate ? = Query 0: 2400 1: 4800 Projector Resolution string 2: 9600 ? = Query 3: 14400 4: 19200 Projector Serial No. string 5: 38400 ? = Query 6: 57600 7: 115200 Projector Total Hours 8: 1200 ? = Query Serial Port Echo...
  • Page 62 Source Info menu SplitScreen 2nd Source Source Spe- 1: Display 0: Off cific - See 1: DisplayLink User Guide Source Info - string 2: VGA 1 SplitScreen Active Source Name 3: VGA 2 Matrix in ? = Query 4: RGBHV Appendix 5: LitePort Source Info - Aspect Ratio...
  • Page 63 System State Dynamic Messaging string 1: Off (max: 53 characters) 2: Start Up 3: PIN Escape codes: 4: Search \c - Initialize (Box mode) 7: Source Displayed \d -Initialize (Ticker Bottom 9: Blank Screen mode) 12: Cool Down \u - Initialize ticker top 13: Screen Save mode 17: Flash Update...

  • Page 64: Index

    9 computer 9 Presentation features 25 video device 13 Projected image size 47 Connecting a computer source 9 Projector contacting InFocus 22 keypad buttons 25 customer service contact information 22 menus 27 projector Digital Zoom 28 connecting computers 9...
  • Page 65 speakers, connecting external 24 SplitScreen Compatibility 52 S-video connector 13 Troubleshooting Network Functions 37 TV tuner 13 USB 9 User Access and Security Page 37 Viewing a Slide Show 38 Volume button 24 warranty 22 zoom 12...
