Related Manuals for InFocus IN5212a
Summary of Contents for InFocus IN5212a
- Page 2 Adobe Systems Incorporated. DLP® , DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.
- Page 3 Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in the unit. For servicing, contact InFocus at www.infocus.com/support Follow all warnings and cautions in this manual and on the unit case.
- Page 4 Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees. In addition, the projector should not be installed in any other way except desktop and ceiling mount positions. Otherwise lamp life could decrease dramatically, and may lead to other unpredictable damage.
- Page 5 Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
-
Page 6: Table Of Contents
Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-angled View ................................ 2 Top view—On-screen Display (OSD) buttons ......................3 Rear view ..................................4 Bottom view ................................... 6 ..............................7 EMOTE ONTROL ARTS SETUP AND OPERATION .............................. - Page 7 SPECIFICATIONS ................................51 ................................. 51 PECIFICATIONS (1080P) ..................... 52 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................... 52 (XGA) ....................... 53 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................... 53 ................................ 54 IMING ABLE ..............................56 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................
-
Page 8: Getting Started
ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR CD-ROM EMOTE CONTROL ’ ATTERIES NOT INCLUDED S MANUAL & CABLE OWER CORD AFETY WARRANTY VARIES PER COUNTRY OOKLET Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is recommend that you keep the original packing material should you ever need to return the equipment for warranty service. -
Page 9: Views Of Projector Parts
Views of Projector Parts Front-angled View ABEL ESCRIPTION EE PAGE IR receiver Receives the IR signals from the remote control. Lens Projection Lens. Focus ring Focuses the projected image. Zoom ring Enlarges the projected image. Elevator foot Adjusts level of projector. See Top view—On-screen Display (OSD) Function keys buttons. -
Page 10: Top View-On-Screen Display (Osd) Buttons
Top view—On-screen Display (OSD) buttons ABEL ESCRIPTION EE PAGE MENU Open and exit OSD menus. Navigate and change settings in the OSD. ◄ (Left cursor) Quick Menu – For Volume Navigate the OSD. ▲ (Up cursor) Quick Menu – For Keystone. Navigate the OSD. -
Page 11: Rear View
Rear view 2 3 4 5 6 7 8 9 10 11 28 29 30 31 ABEL ESCRIPTION EE PAGE VGA1 Connect the RGB CABLE from a computer or a video enabled device. AUDIO 1 Connect the AUDIO CABLE from an input device. Turns the projector on or off (main power switch must POWER button be turned on first). - Page 12 SERVICE For service use. IR receiver Receives the remote control IR signal. RS-232 Connects RS-232 serial port cable for remote control. AUDIO 3 (L and R) Connect the AUDIO CABLE from an input device. Connect a security lock system to the projector and attach to a Security Lock permanent object.
-
Page 13: Bottom View
Refer to the installation guide that comes with the InFocus Ceiling Mount kit for more information. The warranty does not cover any damage caused by use of non-approved ceiling mount kits or by installing in an improper location. -
Page 14: Remote Control Parts
Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 15 ABEL ESCRIPTION EE PAGE Power ON Turn the projector on. LED indicator Only lights when the remote keys are pressed. Display Mode Choose a suitable preset mode for usage environment. Contrast Display the Contrast setting bar and use the right and left keys to adjust. Display the Brightness setting bar and use the right and left keys to Brightness adjust.
-
Page 16: Setup And Operation
ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert batteries (not included) as shown in the illustration. Replace the cover. Caution: 1. Only use AA batteries (Alkaline batteries are recommended). 2. -
Page 17: Installing Or Removing The Optional Lens
Installing or Removing the Optional Lens Caution: Do not shake or place excessive pressure on the projector or the lens components as the projector and lens components contain precision parts. Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans stop, and turn off the main power switch. -
Page 18: Installing The New Lens
Installing the New Lens Align the notches and correctly position the electrical contact pad as shown in the picture. Note: Pin of IRIS should be in the direction as shown in the picture. Rotate the lens clockwise until you feel it click into place. –... -
Page 19: Starting And Shutting Down The Projector
Starting and Shutting down the Projector Remove the lens cap. Connect the power cord to the projector. Connect the other end to a wall outlet. Verify that the AC Power switch on the back of the unit is turned on. When connected, the PWR LED will turn solid Red. - Page 20 If more than one input device is connected, press the SOURCE button and use ▲▼ to scroll among devices. DVI : Digital Visual Interface HDMI : High Definition Multimedia Interface (HDMI) DisplayPort : DisplayPort input VGA 1 / 2 : Analog RGB1 / 2 ...
-
Page 21: Adjusting The Projector Level
Adjusting the Projector Level Take note of the following when setting up the projector: The projector table or stand should be level and sturdy. Position the projector so that it is perpendicular to the screen. Remove and discard the foam spacers on the rear leveling feet before adjusting the projection angle. -
Page 22: Adjusting Projected Image Position Using Shift
Adjusting Projected Image Position Using Shift The Shift feature provides a lens shift function that can be used to adjust the position of the projected image either horizontally or vertically within the range detailed below. Shift is a unique system that provides lens shift while maintaining a much higher ANSI contrast ratio than traditional lens shift systems. -
Page 23: Adjusting The Horizontal Image Position
For IN5312a (XGA) -60% offset -50% offset 0% offset Distance(H) Adjusting the horizontal image position With the lens in the center position the horizontal image position can be adjusted to the left or right by up to a maximum of 5% of the image width. Note that the maximum horizontal image height adjustment can be limited by the vertical image position. -
Page 24: Shift Range Diagram
Shift Range Diagram For IN5316HDa (1080P) Wx5% Wx5% 10% offset -10% offset Max H image shift=10% offset Max W image shift=Wx5% When Wx5%, Max image shift=-10% offset When 10% offset, Max image shift=Wx0% For IN5312a (XGA) Wx5% Wx5% 0% offset -20% offset Max H image shift=0% offset Max W image shift=Wx5%... -
Page 25: Adjusting Zoom, Focus And Keystone
Adjusting Zoom, Focus and Keystone Use the Zoom ring to resize the projected image and screen size. Use the Focus ring to sharpen the projected image. Use the KEYSTONE buttons (on the projector or the remote control) to correct image trapezoiding (wider top or bottom). -
Page 26: Adjusting The Volume
Adjusting the Volume Press the Volume buttons (on the projector or the remote control). The volume control appears on the display. Use the Vol +/- buttons (on the projector or the remote control). Press the MUTE button to turn off the audio (This feature is only available on the remote). -
Page 27: On-Screen Display (Osd) Menu Settings
(OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the projector keypad to navigate and make changes to the OSD. -
Page 28: Setting The Osd Language
Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the cursor ▲▼ button to move to the Advanced 1 menu. (Enter) / ►... -
Page 29: Osd Menu Overview
OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. ETTINGS Image Display Mode Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User Brightness 0~100 Contrast 0~100 Computer Horizontal Position -50~50 (depending on Autolock) Vertical Position -50~50 (depending on Autolock) Frequency... - Page 30 ETTINGS Settings 1 Source Source Reference Input Source Select (IR/Keypad) Projection Normal, Real, Ceiling, Real+Ceiling Aspect Ratio Fill, 4:3, 16:9, Letter Box, Native, 2.35:1 Keystone -40~40 Digital Zoom -10~10 Audio Volume 0~10 Mute Off, On Advanced 1 Language English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano, Norsk, Svenska, Nederlands, Русский, Polski, Suomi, Ελληνικά, 한국어, Magyar,...
- Page 31 ETTINGS Settings 2 Auto Source Off, On No Signal 0~180 Power Off Auto Power Off, On Lamp Mode ECO , Normal, Boost Reset All Status Active Source Video Information Lamp Hours (ECO, Normal, Boost) Software Version Serial Number Advanced 1 Menu Position Center, Down, Up, Left, Right Translucent Menu...
-
Page 32: Image Menu
Image Menu Attention ! When image options are changed, the Display Mode changes to User. Press the MENU button to open the OSD menu. Press ◄► to move to the Image Menu. Press ▲▼ to move up and down in the Image menu. Press ◄► to enter and change values for settings. ESCRIPTION Press ◄►... -
Page 33: Computer Menu
Computer Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the Computer menu. -
Page 34: Advanced Feature
Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu. -
Page 35: Color Manager
Color Manager Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in the Color Manager menu. -
Page 36: Settings 1 Menu
Settings 1 Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press the ▲▼ to move up and down in the Settings 1 menu. Press ◄► to enter and change values for settings. -
Page 37: Audio
Audio Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the Audio menu. -
Page 38: Advanced 1 Feature
Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu. - Page 39 3D Setting ESCRIPTION Press ◄► to enter and select a different 3D mode. Press ◄► to enter and enable or disable 3D Sync Invert. 3D Sync Invert Press ◄► to enter and enable or disable different 3D Formats. 3D Format Note: 1.
-
Page 40: Advanced 2 Feature
Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu. -
Page 41: Settings 2 Menu
Settings 2 Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move up and down in the Settings 2 menu. ESCRIPTION Press ◄► to enter and enable or disable automatic source detection. Auto Source Press ◄►... -
Page 42: Status
Status Press ▲▼ to move up and down in the Settings 2 menu. Select the Status menu and press Enter or ► to enter. ESCRIPTION Active Source Displays the active source. Displays resolution/video information for RGB source and color standard for Video Video Information source. -
Page 43: Advanced 1 Feature
Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu. - Page 44 Lamp Hour Reset Please refer to Resetting the Lamp Timer on page to reset the lamp hour counter. Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields.
- Page 45 This projector supports all commands of PJLink Class1 (Version 1.00). http://pjlink.jbmia.or.jp/english/ For detailed information about the diverse types of external devices which can be connected to the LAN/RJ45 port to control the projector, as well as related control commands, go to www.infocus.com/support — 38 —...
-
Page 46: Advanced 2 Feature
Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu. - Page 47 Source Filter Press the ENTER button to enter the Source Filter sub menu. ESCRIPTION Press ◄► to enter and enable or disable the DVI source. Press ◄► to enter and enable or disable the HDMI source. HDMI Press ◄► to enter and enable or disable the DisplayPort source. DisplayPort Press ◄►...
-
Page 48: Maintenance And Security
ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. Be sure to use the InFocus lamp module designed for this projector. You can order new lamps from www.infocusstore.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. Use of non InFocus lamps may cause electrical shock and fire, and may void the projector warranty. - Page 49 Loosen the captive screw on the lamp cover. Pull up and remove the cover. Use a screwdriver to loosen the two captive screws from the lamp module. Pull out the lamp module. — 42 —...
- Page 50 Reverse steps 1 to 7 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the screws.
-
Page 51: Resetting The Lamp Timer
Resetting the Lamp Timer After replacing the lamp, you should reset the lamp hour timer to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the ◄► buttons to move to the Settings 2 menu. Press the ▼ button to move down to Advanced 1 and press enter. -
Page 52: Cleaning The Projector
Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 60 minutes before cleaning. Failure to do so could result in a severe burn. 2. -
Page 53: Troubleshooting
Common Problems and Solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact InFocus at www.infocus.com/support Often the problem is traced to something as simple as a loose connection. Check the following before proceeding to problem-specific solutions. -
Page 54: Led Error Messages
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before restarting the projector. If the PWR or READY LED is still blinking or the TEMP LED is lit, contact InFocus Technical Support at www.infocus.com/support. Image Problems Problem: No image appears on the screen 1. -
Page 55: Lamp Problems
Problem: The image is reversed Check the Projection setting on the Settings 1 menu of the OSD. Problem: The image is streaked 1. Set the Frequency and Tracking settings on the Image->Computer menu of the OSD to the default settings. 2. -
Page 56: Audio Problems
3. Have the projector serviced. Having the Projector Serviced If you are unable to solve the problem contact InFocus Technical Support at www.infocus.com/support. If your projector needs repair, pack the projector in the original carton and include the return authorization number on the outside of the box. -
Page 57: Hdmi Q & A
HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 58: Specifications
PECIFICATIONS Specifications Model IN5312a IN5316HDa TI DMD XGA 0.7” TI DMD 1080P 0.65” Display type Native Resolution 1024x768 1920x1080 Projection distance 1.5 meters ~ 7 meters ( 4.92 ft ~ 22.97 ft ) (standard lens) Projection screen size 35.1”~205” (89cm~521cm) 37.3"... -
Page 59: Projection Distance Vs. Projection Size (1080P)
Projection Distance vs. Projection Size (1080P) Projection Distance Projection Distance and Size Table Standard projection lens: TR: 1.54– 1.93; offset=10% IN5316HDa 1.71/ 3.42/ 4.27/ 8.55/ 1.70/ 3.41/ 6.82/ 10.23/ Distance (m/inch) 67.3 134.6 168.2 336.4 67.1 134.2 268.4 402.7 100/ 200/ 200/ 300/... -
Page 60: Projection Distance Vs. Projection Size (Xga)
Projection Distance vs. Projection Size (XGA) Projection Distance Projection Distance and Size Table Standard projection lens: TR: 1.6~2; offset=0% IN5312a 1.63/ 3.25/ 4.06/ 8.13/ 1.63/ 3.25/ 6.50/ 9.75/ Distance (m/inch) Diagonal (inch/ ft) 40/3.3 80/6.7 100/8.3 200/16.7 50/4.2 100/8.3 200/16.7 300/25 Keystone Correction angle... -
Page 61: Timing Mode Table
Timing Mode Table The projector can display multiple resolutions. The following table outlines the resolutions that can be displayed by the projector. VGA 1/2 HDMI OMPOSITE /RGBHV IGNAL ESOLUTION IDEO DIGITAL DIGITAL ANALOG — — — — NTSC 15.734 60.0 —... - Page 62 VGA 1/2 HDMI OMPOSITE /RGBHV IGNAL ESOLUTION IDEO DIGITAL DIGITAL ANALOG — 720p 37.5 50.0 — 720p 45.0 60.0 — 1080i 33.8 60.0 — 1080i 28.1 50.0 — HDTV 1080p 24.0 — 1080p 28.13 25.0 — 1080p 33.75 30.0 — 1080p 67.5 60.0...
-
Page 63: Projector Dimensions
Projector Dimensions — 56 —... -
Page 64: Regulatory Compliance
EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. -
Page 65: Serial Communication
PPENDIX Serial Communication The following table describes the serial communication configuration that should be used when interfacing to CLI via the serial port. Windows HyperTerminal or ProComm are two tools that can be used to send CLI commands across the serial port. Setting Value Bits per second... - Page 66 Function Command RW Min Max Default Step Parameter 0 = Computer1 1 = Computer 2 3 = RGBHV 4 = HDMI1 Current Source 7 = DisplayPort1 9 = Component1 11 = Composite 12 = S-Video 20 = DVI Digital Zoom Digital Zoom 0:No error 1:Lamp not lit after 5...
- Page 67 Function Command RW Min Max Default Step Parameter Total Projection Displays the total number of Hours 9999 hours the projector has been (lamp1+lamp2+…) in operation (all lamps). Lamp Life n/a 1500 1500 Lamp life 1500 Lamp Power Select This Read/Write command sets the lamp mode High power (Boost) / 0 = Eco...
- Page 68 Function Command RW Min Max Default Step Parameter Display mode 0:Presentation 1:Bright 2:Game source 3:Movie Presets Specific 4:TV 5:sRGB 6:Blackboard 7:User1 8:User2 Projector Firmware string LX737-692IF-DPEXX Ver. 1:Display Projector Info menu Status Menu XGA: IN5312a Projector Model string 1080P: IN5316HDa Projector Resolution string 0:Blue...
