Main Menu

The MAIN MENU of the DVR. In this picture, the mouse cursor is currently
highlighting the DISPLAY icon.
"Display Setup Menu" on page 20: The camera menu contains all the options for
setting up how the DVR interfaces with and displays the images from the cameras
connected to it. This is where channels are enabled or disabled in live viewing, and
where the AUTOSEQ (Automatic Sequence) function can be confi gured.
Record Menu:
"Record Setup Menu" on page 23: Where you can confi gure the recording
options for the DVR. You can set channels to be armed for recording constant-
ly or on a schedule, and set the recording resolution, quality and size. You can
also enable or disable the associated audio channel. Additionally, the record-
ing function for some or all channels can be disabled entirely.
"About Motion Detection" on page 28: To confi gure how and where the
DVR looks for motion. This can be used as (and is recommended as) the pri-
mary recording mode of the DVR.
18
View Mode: Advanced Setup
V-OUT CH SEQUENCE SETUP
Here, you can set what order you'd like the DVR to present channels. You can set all
sixteen, or choose a smaller selection of either four (2 x 2) or eight (3 x 3) channels to
be displayed.
You can choose each channel only once - if, for example, you chose to display CH5
in the spot initially assigned to CH1, then CH1 will automatically be swapped to the
position that CH5 occupied.
The order of channels selected here will eff ect the
layout of the main viewing screen.
