  • Page 1 Thank you for purchasing this Factory Service Manual CD/DVD from servicemanuals4u.com. Please check out our eBay auctions for more great deals on Factory Service Manuals: servicemanuals4u...
  • Page 2 Upgrade Guide Evo D510 e-pc Document Part Number: 305513-001 August 2002...
  • Page 3 The warranties for Compaq products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

  • Page 4: Table Of Contents

    Contents For Your Safety and Comfort Upgrading and Replacing Hardware General Precautions............3 Opening the e-pc .
  • Page 5 Refer to the Safety & Comfort Guide, included in the documentation provided with your computer and available on the Web site at http://www.compaq.com/comfortguide , for more information on choosing a workspace and creating a safe and comfortable work environment.

  • Page 6: Upgrading And Replacing Hardware

    If you want to find out about accessories available for your e-pc, refer to the following Web site: http://www.compaq.com/products/desktops/options/index.html General Precautions Before upgrading or replacing components, be sure to carefully read all of the applicable instructions, cautions, and warnings in this guide.
  • Page 7 Upgrading and Replacing Hardware 3. Disconnect all cables from the computer. 4. Push the two green latches inward. 5. Slide out the chassis from the enclosure. Upgrade Guide...

  • Page 8: Internal Components

    Upgrading and Replacing Hardware Internal Components Main Memory Modules: (266MHz DDR SDRAM) 2 sockets for 128 MB, 256 MB, 512 MB or 1GB modules up to 2 GB maximum Hard Drive You can replace hard drive with a larger one One Front-Access Device Shelf CD-ROM drive, CD-RW drive or DVD drive One Front-Access Device Shelf...

  • Page 9: Upgrading Or Replacing Memory

    ✎ Use only memory modules provided for your e-pc model. The use of other memory modules is not supported. For information about http://www.compaq.com. supported accessories, connect to 32 MB and 64 MB modules are not supported. Install 128 MB, 256 MB, 512 MB or 1 GB non-ECC DDR SDRAM modules.

  • Page 10: Replacing The Hard Drive

    Upgrading and Replacing Hardware 4. There are two memory sockets. Align the notches on the bottom of the module with the corresponding marks on the socket and push it firmly into place. The clips close automatically. 5. Replace the chassis in the enclosure. Replacing the Hard Drive WARNING: For your safety, disconnect the power cord and all external Å...
  • Page 11 Upgrading and Replacing Hardware 3. Detach the data and power cables from the hard drive. ✎ To prevent damage to the data and power cables, pull on the tab or connector instead of the cable itself. To prevent damage to the hard drive, handle it with care and do not drop it.
  • Page 12 To reinstall the operating system and drivers on the newly-installed hard drive, use the Restore Plus! CD and operating system CD provided with the e-pc. In addition, you can find the most up-to-date versions of drivers on the support site at http://www.compaq.com/support. Upgrade Guide...

  • Page 13: Replacing The Optical Drive

    Å procedures to a laser device other than those specified in the operators manual or in the laser device installation guide. Allow only Compaq authorized service technicians to repair the laser equipment. 1. Open the e-pc as shown in “Opening the e-pc” on page 3.
  • Page 14 6. Attach the cable to the new drive and slide the drive tray back into the e-pc until it clicks into place. 7. Replace the chassis in the enclosure. 8. Verify the new configuration by checking the Summary screen. Restart the computer. When the Compaq logo is displayed, Esc. press then press...

  • Page 15: Configuring An Ide Device After Installation

    After installing any device, you can check via the Summary Screen that your e-pc has correctly identified the new configuration. To view the Summary screen, restart the computer. When the Compaq logo is displayed, press then select Summary from the list of options.

  • Page 16: Removing Or Replacing The System Board

    Upgrading and Replacing Hardware Removing or Replacing the System Board 1. Open the e-pc as shown in “Opening the e-pc” on page 3. 2. Remove all cables from the old system board. 3. Turn the chassis over and remove the six screws that secure the system board to the chassis.
  • Page 17 Upgrading and Replacing Hardware 4. Remove the old system board from the chassis. a. Lift up the board at the front side of the chassis. b. Carefully disengage the rear connectors and lift the board out of the chassis. 5. If you are replacing the system board, remove the memory modules, heatsink, and processor from the old system board and install them on the new system board.

  • Page 18: Replacing The Processor

    Upgrading and Replacing Hardware Replacing the Processor 1. Open the e-pc as shown in “Opening the e-pc” on page 3. 2. Remove the system board as shown in “Removing or Replacing the System Board” on page 13. 3. Locate the processor (it is covered by a heatsink). processor (covered by heatsink) 4.
  • Page 19 Upgrading and Replacing Hardware 5. Lift the processor socket lever and remove the old processor. Carefully insert the new processor, then lower the lever back into place while pressing lightly down on the processor to ensure that it seats properly. CAUTION: Insert the processor carefully, making sure that the orientation Ä...
  • Page 20 12. Ensure that the latest version of BIOS is installed on your e-pc. To learn which version of BIOS is currently installed on your e-pc, restart the e-pc. When the Compaq logo is displayed, press then select Summary from the list of options. To get the latest BIOS version for your e-pc, connect to the support Web site http://www.compaq.com/support.

  • Page 21: Replacing The Power Supply Unit

    Upgrading and Replacing Hardware Replacing the Power Supply Unit 1. Open the e-pc as shown in “Opening the e-pc” on page 3. 2. Remove the two internal power supply connectors. Lift the retaining lever and free the cable from the tabs that hold it in place.

  • Page 22: Replacing The Battery

    Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water. ■ Replace the battery only with the Compaq spare designated for this product. CAUTION: Before replacing the battery, it is important to back up the Ä...
  • Page 23 In order to forward them to recycling or proper disposal, please use the public collection system or return them to Compaq, their authorized partners, or their agents. Ä CAUTION: Static electricity can damage the electronic components of the computer or optional equipment.
  • Page 24 8. Plug in the computer and turn on power to the computer. Reset the date and time, your passwords, and any special system setups, using Computer Setup. To access Computer Setup, restart the computer. When the Compaq logo is displayed, press Upgrade Guide...
