QuickSpecs
Overview
W h a t ' s N ew
Intel Pentium 4
processors
Intel 845 chipset
New Evo industrial design
with carbon and silver color
Front audio and USB ports
A t A G l a n c e
Intel Pentium 4
processors with 400-MHz
Front Side Bus
Available in Convertible
Minitower form factor
Pre-loaded Microsoft Office
on D300s
Energy Star compliant with
energy-saving features
Windows XP Ready
Protected by Compaq
Services, including a 1-1-1
limited warranty. Certain
restrictions and exclusions
apply.
DA-10948
North America — Version 13 — May 9, 2002
Compaq Evo Desktop D300/300s
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D300 and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq D300

Summary of Contents for Compaq D300

  • Page 1 Pre-loaded Microsoft Office on D300s Energy Star compliant with energy-saving features Windows XP Ready Protected by Compaq Services, including a 1-1-1 limited warranty. Certain restrictions and exclusions apply. DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s...
  • Page 2 Example: 470023-466 470023-467 470031-669 470023-794 470031-671 DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s D3Ms/P1.5/20j/2/128c6E D3Ms = Evo D300s Convertible Minitower P1.5 = Pentium 4 1.5-GHz processor 20 = Hard Drive, 5400rpm 845 chipset...

  • Page 3: Standard Features - Custom Components

    Note. Intel Pentium 4 processors with speeds of 2.0-GHz or above have 512-KB L2 cache. Note: Compaq Evo D300v Series Microtower with 845 chipset contains three DIMM slots, but can only be upgraded to a maximum of 3-GB when 1-GB PC133 SDRAM are available.

  • Page 4: Intel Pentium

    Front Side Bus Speed Standard L2 Cache L2 Cache Architecture / Speed DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 3 DIMMs 3 (3 on PCA) (slot occupied by video card) 1 (1.5V AGP 4X) (2) HDD (2) 5.25"...
  • Page 5 P4 / PCI / AGP 4X Intel 845 Chipset Super I/O 3 Standard uATX Yes (3) Yes (1) 3 standard ® ® Convertible Minitower Compaq Evo Desktop D300/300s Solenoid Lock PCB (Option) PCI Extender Board - 2 additional PCI Slots Front I/O Board (Option)
  • Page 6 Front Headphone, Mic, and 2 USB (Option) Standard ATX I/O Panel 250-Watt Enhanced ATX PS Kensington Cable Lock Security Module (Solenoid Hood Lock and Hood Sensor) Compaq Lock Bracket – 173234 (chassis securement only, hood lock required to secure hood)
  • Page 7 Network Keyboard Mouse Video Audio DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Optional Yes (with captive thumbscrew) Yes (Can also Rotate Drives) No (Not needed) Super IO 3 Yes (2) / SN75185 2 USB 1.1 (Optional 2 Front USB)
  • Page 8 System Idle Mode Processor/Cache Memory Power-Down (S3) CD-Rom Spins Down when not in use DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 90 to 264VAC 100 to 240VAC 50-60 Hz 3.6A @ 100VAC 250W...
  • Page 9 Vibration (Non-Operating) DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 50° to 95°F/10°to 35° C (Derating of 1.0°C per 300m (1000ft) to 3000m (10,000ft), no direct sustained sunlight) -22° to 140° F-30° to 60° C (Maximum rate of change is 20°C/Hr.) 10% to 90% (28°C maximum wet bulb temperature)
  • Page 10 Monitor serial number, model & manufacturer System serial number, model, & manufacturer ROM revision levels System board revision level Compaq Fingerprint Identification Technology (Optional) DMI BIOS Memory Change Alert (Intelligent Manageability needed to work) Ownership Tag Smart Cover Lock (Optional)
  • Page 11 Terms and conditions may vary by country. Certain restrictions and exclusions apply. On-site service may be provided pursuant to a service contract between Compaq and an authorized Compaq third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

  • Page 12: After-Market Options

    Keyboards Compaq Easy Access Keyboard (carbon) Mice Compaq 2-Button Scroll Mouse (PS/2) Compaq 2 Button Scroll Mouse (USB) Memory (DIMMs) 133-MHz SDRAM DIMMs 512-MB Memory Kit (1 x 512-MB SDRAM DIMM, 133 MHz) 256-MB Memory Kit (1 x 256-MB SDRAM DIMM, 133 MHz)

  • Page 13: Optical Drives

    After-Market Options Monitors (continued) CRTs Professional Series Compaq P1220 CRT Monitor (21-inch, Carbon/Silver) Compaq P1210 CRT Monitor (21-inch, Opal) Compaq P1210 CRT Monitor (21-inch, Carbon/Silver) Compaq P920 CRT Monitor (19-inch, Carbon/Silver) Compaq P910 CRT Monitor (19-inch, Opal) Compaq P910 CRT Monitor (19-inch, Carbon/Silver)

  • Page 14: Removable Storage

    Tape Drives TR5 10/20-GB Tape Drive (carbon) TR5 10/20-GB Media 3-Pack Security USB Biometric Identification Device Basic Smartcard Keyboard DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 294402-B22 127591-001 294416-B22 217896-B21 294243-B21 125782-B21 240238-B21...
  • Page 15 Maximum Memory when 1-GB 3-GB Note: All Compaq Evo Desktop D300s contain three DIMM slots, but can only be upgraded to a maximum of 3-GB when 1-GB DIMMs are available. Note: 1-GB PC133 SDRAM not currently offered as after-market options.
  • Page 16 Up to 2 SCSI Hard Drives Up to 2 DA-10948 North America — Version 13 — May 9, 2002 R I V E U P P O R T Position Supported Controller Floppy Ultra ATA SCSI Compaq Evo Desktop D300/300s...

  • Page 17: Technical Specifications - Audio

    Ports Sampling Compression OS support Wavetable Syntheses (software) DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Integrated Microphone-in (10-Kohm Minimum) Line-in (10-Kohm Minimum) Headphone/Line-out (16-ohm Minimum) 7 kHz to 48 kHz ADPCM, ESPCM Windows 98 S.E.

  • Page 18: Technical Specifications - Communications

    Power management Flash package Network management LED indicators Standards compliance DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Intel ® Intel SingleDriver™ technology (10/100-Mbps support) RJ-45 PCI 2.2 Network transfer rate 10BASE-T (Half-Duplex) 10 Mbps...
  • Page 19 Operating humidity Operating System Driver Support DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s V.90/K56flex technology speeds: 56,000 Kb/s maximum downstream data; controllerless (upload only): 33,600; 31,200; 28,800; 26,400; 21,600; 19,200; 16,800; 14,400; 12,000; 9600; 7200; 4800; 2400; 1200; and 300 b/s ITU V.90, ITU-T, V.34, V.32 (bis), V.22bis, V.22, V.21, V.23, and Bell...

  • Page 20: Technical Specifications - Graphics

    1152 x 864 1024 x 768 800 x 600 640 x 480 DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Half-size ATX AGP 4X 16-MB SDRAM (64-bit frame buffer interface) 125 MHz 250 MHz...
  • Page 21 1152 x 864 1024 x 768 800 x 600 640 x 480 DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 60-85 Hz NVIDIA GeForce2 MX 200 and 400 AGP 4X Integrated 350 MHz RAMDAC SDRAM...
  • Page 22 1280 x 1024 1600 x 1200 DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s AGP 1X, 2X, 4X: PCI Rev 2.2 bus specification AGP: 32 MB / PCI: 16 MB 360 MHz (secondary DAC: 200 MHz)
  • Page 23 Optional software bundles (not included) DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Low profile (LP) board with ATX bracket attached (kit also includes a Small Form Factor (SFF) bracket) AGP 4X, AGP 2X, and AGP 1X 32-MB, high-speed DDR 360-MHz RAMDAC;...

  • Page 24: Resolutions Supported

    1920 x 1200 DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Digital flat panel + digital flat panel , VGA monitor/analog flat panel + VGA monitor/analog flat panel DualHead Multi-Display support; DualHead Browser Enhancement Suite, DualHead...

  • Page 25: Technical Specifications - Hard Drives

    41 to 131 F/5 to 55 C Note: 20-GB capacity points include Quiet Idle technology, which reduces acoustic levels approximately 5 decibels Compaq Evo Desktop D300/300s 1.2 ms (2.7 ms quiet seek) 8 ms (10.1 ms quiet seek) 18 ms (21.1 ms quiet seek) 78,165,360 1.2 ms (2.7 ms quiet seek)
  • Page 26 41 to 131 F/5 to 55 C Note: 20-GB capacity points include Quiet Idle technology, which reduces acoustic levels approximately 5 decibels. Compaq Evo Desktop D300/300s 1.5 ms (2.9 ms quiet seek) 10.5 ms (12.4 ms quiet seek) 23 ms (23 ms quiet seek) 39,102,336 1.5 ms (2.9 ms quiet seek)

  • Page 27: Technical Specifications - Input/Output Devices

    Weight Electrical Mechanical Environmental DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 18.3 x 6.3 x 1.4 in/465 x 160 x 36 mm Approximately 2 lbs/0.9 kg Operating Voltage 5VDC 5% Power Consumption 50 mA maximum (with 3 LEDs on)
  • Page 28 Mechanical Life Environmental Electrical Mechanical Regulatory Approvals DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s 8 mm 30 mm/s Light force micro-switch 1 million operations Minimum 200,000 revolutions Operating Temperature 50 to 122 F/10 to 50 C...

  • Page 29: Technical Specifications - Optical Storage

    Weight Operating systems supported MPEG playback graphics solution support DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s ATAPI IDE 16.6 Mbps Sustained—150 Kbps minimum Variable (CD)—3,000 to 7,200 Kbps (audio) CAV (Constant Angular Velocity) Random: <100 ms...
  • Page 30 Mounting orientation Dimensions Weight Approvals/environmental Operating systems supported DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s ATAPI IDE CD-R and CD-RW 650 MB Disc-at-once, track-at-once, session-at-once, fixed packet, and variable packet 74 minutes Sustained CD-R write—2,400 Kbps (16X)
  • Page 31 Control) Minimum CPU supported Mounting orientation DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Ultra DMA 33 Sustained DVD = 8.1 Mbps to 21.6 Mbps CD-ROM = 2.55 Kbps to 6.00 Kbps DVD—CAV (Constant Angular Velocity) CD—CAV...
  • Page 32 Access times (typical reads, including settling) DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Either horizontal or vertical ATAPI 5.8 x 1.7 x 7.7 inches (146.5 x 42.1 x 196 mm) 5 inches, 3 inches (12 cm, 8 cm) 0.05 inch (1.2 mm)

  • Page 33: Audio Output Level

    Certifications, requirements Operating systems supported Option kit contents DA-10948 North America — Version 13 — May 9, 2002 Compaq Evo Desktop D300/300s Sustained—1,200 KB/s (8X) CD-R write Sustained— 600 KB/s (4X) CD-RW Sustained—1,200 KB/s (8X Digital audio extraction (minimum) CAV) Variable—1,500 to 4,800...

  • Page 34: Technical Specifications - Removable Storage

    Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.
