- Page 1 HIGH CONTRAST VIDEO-PROJECTOR...
- Page 2 Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders. All brands and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products of their manufactures. R699823 - Yunzi Family User Manual...
-
Page 3: Table Of Contents
Mask..............................26 Progressive (only 480i, 576i, 1080i)....................26 3D Setting ............................26 INSTALLATION SETTINGS ..................27 Lens Control ............................ 27 Pixel Adjust............................28 Installation Style ..........................28 Keystone ............................28 Pincushion............................28 Anamorphic ............................. 28 R699823 - Yunzi Family User Manual... - Page 4 Clean Dirt on the Cabinet ........................ 31 13.2 Dirt on the Lens ..........................31 13.3 Replacing the Lamp ......................... 31 13.4 Cleaning and Replacing the Dust Filters ..................33 13.5 Troubleshooting ..........................33 13.6 Specifications........................... 35 R699823 - Yunzi Family User Manual...
-
Page 5: Safety Instructions
Do not use this product near water. Do not use immediately after moving from a low temperature to high temperature, as this causes condensation, which may result in fire, electric shock, or other hazards. R699823 - Yunzi Family User Manual... - Page 6 Fragments from a broken light-source lamp dangerous voltages and other hazards. Refer all may cause injuries. service to qualified service personnel. • The light-source lamp used in this projector is a R699823 - Yunzi Family User Manual...
-
Page 7: Regional Specific Information
United States. The FCC's jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions. R699823 - Yunzi Family User Manual... -
Page 8: Installation Guidelines
This causes visual fatigue and discomfort. That means that the more 3D effect, the more outward effects, and the more your eyes will try to focus nearer than R699823 - Yunzi Family User Manual... -
Page 9: Synchro Emitter And 3D Glasses
Do not use this unit in rooms with cigarette smoke or oily smoke. This may cause the unit to malfunction. Check temperature during install. If there is a heater, the air may reach a higher temperature than expected. R699823 - Yunzi Family User Manual... -
Page 10: Air-Flow And Space Requirements
This unit can be installed in table, ceiling, rear table or rear ceiling position. Make sure that the unit is installed within the space requirements described below (A: air inlets, B: air outlets). Air flow 200 mm 200 mm 150 mm 200 mm Space requirements R699823 - Yunzi Family User Manual... -
Page 11: Ceiling Mounting The Unit
The projection screen sizes and projecting distances in the table above are provided only as a guide. Please use them as reference during installation. • The distances are calculated for a projection image of 16:9 aspect ratio R699823 - Yunzi Family User Manual... -
Page 12: Setting The Lens And Using Lens Memories
Adjust the picture position The Yunzi Family projector has motorized vertical and horizontal shifts. Browse into the Menu to the [Lens Control] setting into the Installation menu, select the shift adjustment. Or use the direct access button on the Remote Control Unit [Lens Control] to make the lens adjustment. -
Page 13: Remote Control Unit (Rcu)
PICTURE MODE Select a Picture Mode FILM CINEMA ANIME NATURAL STAGE C.M.D. (Clear Motion Drive) USER INFO C.M.D. Gamma Adj. Basic Picture Adj. COLOR COLOR PIC. GAMMA TEMP P.FILE ADJ. Color Profile Color temp. Adj. R699823 - Yunzi Family User Manual... -
Page 14: Loading And Replacing Batteries
The remote control unit can be used by having the transmission signal reflected off a screen, as the effect of signals reflected from the RCU differ with the type of screen used, operable distance may decrease. R699823 - Yunzi Family User Manual... -
Page 15: Getting Started
Main Power: connect the power cord as shown below. • Lamp trap: see “Procedure for Lamp Replacement”, page 32 for more details about lamp replacement. • Air Inlets: see “Air-Flow and Space Requirements”, page 10. R699823 - Yunzi Family User Manual... -
Page 16: Connecting The Power Cord
When in Cool Down mode, do not pull out the plug from the outlet. Also, do not block the air inlets/exhaust vents by standing the projector on its end or laying it on its side. When the projector is running for more than 1 minute, the Standby/ON LED will automatically switch OFF. R699823 - Yunzi Family User Manual... -
Page 17: Operating And Navigation Buttons
Prior to connecting any device to this unit, switch the projector in standby mode. Never connect a HDMI source to this unit when the projector is in operate mode. The HDMI termination is a self-powered connection and can cause electric discharges. R699823 - Yunzi Family User Manual... -
Page 18: Connecting A Video Source To The Projector
Make sure to use a certified HDMI cable, especially when the distance between the different devices are longer than 5 meters. If it is the case, the use of a split system or optical fiber cable is highly recommended. R699823 - Yunzi Family User Manual... -
Page 19: Connecting An Automation Or Control Device
Local Network (this is not a web interface). ONNECTING AN AUTOMATION CONTROL DEVICE This unit can control or be controlled by using several input/output terminals. Each terminal is ruled by specific protocols. Please refer to Appendix for more information. R699823 - Yunzi Family User Manual... -
Page 20: Menu Structure
On, Off Color Space (close to HDTV std.) Standard (close to DCI std.) Wide (natural colors, no adj.) Custom Gamma: Custom1 Custom2 Custom3 User Name Edit: User1 - User5 edit name 10 char. max R699823 - Yunzi Family User Manual... - Page 21 1 - 5 Vert. Blue 1 - 5 Installation Style Front Ceiling Mount (Front) Rear Ceiling Mount (Rear) Keystone (disable with 3D signal) Horizontal -40 +40 Vertical -30 +30 Pincushion (disable with 3D signal) -20 +20 R699823 - Yunzi Family User Manual...
-
Page 22: Picture Adjust Settings
Film Cinema Animation Natural Stage There are 5 additionnal User defined profiles. 7.2 Contrast The contrast function is used to adjust the contrast between the light and dark areas of the displayed image. A R699823 - Yunzi Family User Manual... -
Page 23: Brightness
Paste: paste values stored in memory to current profile. • Reset: reset to the default 2.2 gamma coefficient. Gamma Adjustment can be copied from all modes. Paste can only be used for Custom modes. R699823 - Yunzi Family User Manual... -
Page 24: Advanced Picture Settings
Adjust from the correct aperture from partially closed to fully opened. Lamp Power Set the lamp power used by the current Picture Profile: Low: lamp is set to 180W R699823 - Yunzi Family User Manual... -
Page 25: Reset Picture Profile
8.4 Aspect Ratio When watching a movie or video program, you can manually set the desired aspect ratio to fill your screen. Select the correct aspect ratio depending on your source: R699823 - Yunzi Family User Manual... -
Page 26: Mask
Adjustments White, Red, Green and Blue: -8 +8 Negative values reduce visible Crosstalk, positive values bring a brighter 3D picture at the cost of more Crosstalk. Intensity (2D to 3D Conversion is On) R699823 - Yunzi Family User Manual... -
Page 27: Installation Settings
You can edit the Lens Memory Name within the limit of 10 characters. Same procedure as Section , “User Name Edit”, page 24. Lens Center Reset the lens position to the original, central position. R699823 - Yunzi Family User Manual... -
Page 28: Pixel Adjust
Mode B: This setting squeezes horizontally the picture to fit a 16:9 image into cinemascope screen. This setting is to be used with an anamorphic installation where the lens is permanently fixed in front of the unit and to watch R699823 - Yunzi Family User Manual... -
Page 29: Screen Adjust
Off: Don’t display. Logo On: Display D-ILA logo during startup for 5 seconds. Off: Don’t display. Language Choose the OSD language between: English, Japanese, German, Spanish, Italian, French, Portuguese, Dutch, Swedish, Norwegian, Russian and Chinese. R699823 - Yunzi Family User Manual... -
Page 30: Function Settings
11.8 Lamp Reset Resets the lamp use time to "0" during the lamp replacement procedure. See “Replacing the Lamp”, page 31 for more details. 12.0INFORMATION MENU Input Terminal Displays the active video input. Input Source Format R699823 - Yunzi Family User Manual... -
Page 31: Maintenance
You can also check the accumulated hours of usage. Please refer to Lamp Time in the Information menu. When the lamp usage time exceeds 2900 hours The Lamp replacement message will be displayed on the screen the next three projection starts. R699823 - Yunzi Family User Manual... -
Page 32: Procedure For Lamp Replacement
When the projector is in standby mode (red STANDBY/ON led), use the remote control and press sequentially the [BACK] - [OK] - [HIDE] within 1 second interval then [DOWN] for at least 2 seconds. R699823 - Yunzi Family User Manual... -
Page 33: Cleaning And Replacing The Dust Filters
Unit is in operate mode (during projection) Unit is in operate mode, but HIDE is ON. blinking Press again on HIDE button to obtain a green picture. blinking red Unit is in cooldown mode. (switching off) R699823 - Yunzi Family User Manual... - Page 34 When in Cool Down mode, do not pull out the plug from the outlet. Also, do not block the air inlets/exhaust vents by standing the projector on its end or laying it on its side. R699823 - Yunzi Family User Manual...
-
Page 35: Specifications
13.0 MAINTENANCE 13.6 Specifications Overview The Yunzi Family uses the latest technology developed to provide the ultimate video-projection experience. LCoS (Liquid Crystal on Silicon) technology based on a reflective principle features an extremely high-definition picture and seamless color gradations. Emission Method LCoS (Reflective Active Matrix Principle) - Page 36 13.0 MAINTENANCE Dimensions 215 mm 8.5’’ 455 mm 505 mm 17.9’’ 19.9” 455 mm 17.9’ R699823 - Yunzi Family User Manual...
- Page 37 13.0 MAINTENANCE HOW TO REPLACE BATTERIES ON INFRA-RED 3D-GLASSES RADIO FREQUENCY 3D-GLASSES Radio-Frequency 3D-Glasses uses rechargeable batteries that can be recharge using the mini-USB connector. R699823 - Yunzi Family User Manual...
- Page 38 13.0 MAINTENANCE R699823 - Yunzi Family User Manual...
