Summary of Contents for Dream Vision Inti
- Page 2 Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders. All brands and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products of their manufactures. R699800 - Inti Series User Manual...
-
Page 3: Table Of Contents
Picture Mode ........................29 Color Profiles (Inti 2 & Inti 3) ..................29 Color Temperature......................29 Gamma ..........................29 Film Tone (Inti 2 & Inti 3, Film Picture Profile)............... 30 Dark / Bright Level ......................30 Contrast ..........................30 Brightness.......................... 30 Color.......................... - Page 4 Lamp Time ........................37 Expert Calibration (Inti 2 & Inti 3) ....................37 ANAMORPHIC LENS ....................38 Optional 2.35 CineWide and 2.35 THEATRE System (for Inti) ............. 38 Using the Remote Control Unit....................... 38 2.35 CineWide ..........................39 2.35 THEATRE System (for Inti) ....................39 MAINTENANCE......................
-
Page 5: Safety Instructions
Do not use attachments not recommended by the product manufacturer as they may be hazardous. • Do not use this product near water. Do not use immediately after moving from a low temperature to high R699800 - Inti Series User Manual... - Page 6 Do not use a damaged light source lamp. If the light- • Do not attempt to service this product yourself as source lamp is broken, ask your dealer to repair R699800 - Inti Series User Manual...
-
Page 7: Regional Specific Information
United States. The FCC's jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions. R699800 - Inti Series User Manual... -
Page 8: Installation Guidelines
The human brain then perceives stereo objects based on the visual differences between two images of the same object but taken from different angles. R699800 - Inti Series User Manual... -
Page 9: Comfort And Caution
-If the 3D-glasses do not face directly to the 3D synchro emitter Depending on the use of 3D emitters such as Radio Frequency synchro emitter, it may be possible that its operation influences the operation of other devices using the same bandwidth. R699800 - Inti Series User Manual... -
Page 10: Environment Of Use
This unit can be installed in table, ceiling, rear table or rear ceiling position. Make sure that the unit is installed within the space requirements described below. • A: Air inlets • B: Air outlet Air flow 200 mm 200 mm 100 mm 200 mm Space requirements R699800 - Inti Series User Manual... -
Page 11: Ceiling Mounting The Unit
Regardless whether the unit is still under guarantee, Dreamvision is not liable for any product damage caused by mounting the unit with third party ceiling mount or when the environment is not suitable for ceiling-mount. R699800 - Inti Series User Manual... -
Page 12: Projection Distance
The optimum image can be obtained when the centre of this projector’s lens and the screen are placed perpendicular to each other. Take note of the projection angle when placing them. You can also use up to +/- 15° up R699800 - Inti Series User Manual... - Page 13 Adjust the picture position The Inti Series projector has motorized vertical and horizontal shifts. Browse into the Menu to the [Lens Control] setting into the [Installation] menu, select the shift adjustment. Or use the direct access button on the Remote Control Unit [Lens Control] to make the lens control adjustment.
-
Page 14: Adjust The Picture Focus
Select the [Focus] adjustment and obtain a clear picture using [Up] and [Down] buttons. Adjust the picture Zoom Into the [Lens Control] menu, press the [Ok] button to access the [Zoom] adjustment. Use the up and down buttons R699800 - Inti Series User Manual... - Page 15 filled. STAND BY INPUT LENS CONTROL HIDE LIGHT MENU BACK PICTURE MODE Select the [Zoom] adjustment and resize the picture using [Up] and [Down] buttons. R699800 - Inti Series User Manual...
-
Page 16: Remote Control Unit (Rcu)
Insert two AAA size batteries, making sure the polarities match the + and - marks inside the battery compartment. • Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover until it is firmly closed. R699800 - Inti Series User Manual... -
Page 17: How To Use The Remote Control Unit
The remote control unit can be used by having the transmission signal reflected off a screen, as the effect of signals reflected from the RCU differ with the type of screen used, operable distance may decrease. R699800 - Inti Series User Manual... -
Page 18: Getting Started
Main Power: connect the power cord as shown below. • Lamp trap: see “Procedure for Lamp Replacement”, page 41 for more details about lamp replacement. • Air Inlets: see “Air-Flow and Space Requirements”, page 10. R699800 - Inti Series User Manual... -
Page 19: Connecting The Power Cord
Do not cut, tear or modify the power cords. Also, do not place a heavy object on, heat or stretch the power cords as this may cause damage to the cords. Do not insert or pull plugs with a wet hand. R699800 - Inti Series User Manual... -
Page 20: Operating Leds
When in Cool Down mode, do not pull out the plug from the outlet. Also, do not block the air inlets/exhaust vents by standing the projector on its end or laying it on its side. NB: When the projector is running for more than 1 minute, the Standby/ON LED will automatically switch OFF. R699800 - Inti Series User Manual... -
Page 21: Operating And Navigation Buttons
To select or to confirm action. Up - down - left - right To navigate into On Screen Display (OSD) Menu. Menu To display On Screen Display (OSD) Menu. Back To return to previous menu or cancel action. R699800 - Inti Series User Manual... -
Page 22: Connections
Multimedia box, Analog Camera. VGA (Sub D-15) For Inti 2 & Inti 3: Computer (VGA output), Multimedia box . (Inti 2 & Inti 3) Make sure to use a certified HDMI cable, especially when the distance between the different devices are longer than 5 meters. -
Page 23: Connecting An Automation / Control Device
When the LAN Control is selected, the RS-232 port cannot be used for automation. In addition, the control device must send specific functions to this unit using the Local Network (this is not a web interface) See “LAN protocole (Inti 2 & Inti 3)”, page 49 for more details on the network configuration and protocol. ONNECTING AN AUTOMATION CONTROL DEVICE This unit can control or be controlled by using several input/output terminals. -
Page 24: Caution When Connecting A Device To Hdmi Input
Prior to connecting any device to this unit, switch the projector in standby mode Never connect a HDMI source to this unit when the projector is in operate mode. The HDMI termination is a self- powered connection and can cause electric discharges. R699800 - Inti Series User Manual... -
Page 25: Menu And Picture Setting
Natural (Concerts) Stage User1 User2 (Inti One only) User3 (Inti 2 & Inti 3) (Inti 2 & Inti 3) Color Profiles (Xenon, Eastman Kodak) Film1 availabble Color Profiles list varies (Xenon, Fujifilm) Film2 upon current Picture Mode (Extended colors) Standard... - Page 26 If Picture mode is not 3D: focus on tone film S curve more contrast than B brighter Custom1 Custom2 Custom3 Film Tone (Inti 2 & Inti 3) available when Picture mode is Film: White -16 +16 -16 +16 Green -16 +16 Blue -16 +16 Dark/Bright Level (Inti 2 &...
- Page 27 (interpolation weak) Mode3 (interpolation strong) Mode4 (only for 60i or 60p) Film Motion Clear Motion Drive Demo Lens Aperture -15 +0 Lamp Power (Inti 2 & Inti 3): (160W) Normal (220W) High Reset Profile Confirm Input Signal HDMI Input levels...
- Page 28 Subnet Mask 255.255.255.0 Default Gateway 192.168.0.254 Mac Address Display MAC Display network settings Lamp Reset Confirm Information Input Terminal Input Source name PC Resolution PC H Freq. PC V Freq. Deep Color Depth Lamp Time R699800 - Inti Series User Manual...
-
Page 29: Picture Adjust Menu
3D setting is to be used dedicated settings for 3D content watched through active glasses compensation. Additionally, you can define 2 user modes (3 user modes for Inti One only) to finely tune the projector to your video source and the ambient light. -
Page 30: Film Tone (Inti 2 & Inti 3, Film Picture Profile)
Gamma Adjustment can be copied from all modes. Paste can only be used for Custom modes. Film Tone (Inti 2 & Inti 3, Film Picture Profile) It allows 32 fine adjustment steps of the global picture brightness while maintaining the correct contrast level to keep good black and bright levels. -
Page 31: Reset
Wde2: same color space as DCI but within a wider color gamut 6.2.0.6 Color Management (TSL adjustments) (Inti 2 & Inti 3) The Color Management gives the installer an unique calibration ease with the integrated Color Adjustment menu: each primary, secondary colors and orange can be independently calibrated to obtain a precise color balance in a snap. -
Page 32: Component
Y Pb/Cb Pr/Cr: Select this option if the COMP. input is connected to a component video signal. • RGB: Select this option if the COMP. input is used with a RGB video source. PC (Inti 2 & Inti 3) This menu is available if the selected active input is PC (Sub-D15) input. •... - Page 33 1:1 mode, pixel to pixel mapping, no scaling. • Full. Stretch the picture full screen. Sub-D15 or HDMI ASPECT RATIO SOURCE XGA (4:3) Auto Full SXGA (4:3) Auto Full 1280x768 Auto Full Aspect Ratio applied to PC-signals. R699800 - Inti Series User Manual...
-
Page 34: Mask
Horizontal Keystone from -40 to +40. Anamorphic (not available with 3D sources) • Off: No modification to original picture. • ModeA: The picture is vertically stretched to fit an installation with anamorphic lens. A cinemascope picture is R699800 - Inti Series User Manual... -
Page 35: Screen Adjust
Configures the screen color displayed when there is no active input. Set to Blue or Black. Menu Position Upper left, Upper right, Center, Lower right, Lower left. Menu Display 15sec: Display menu for 15 seconds before fade out. On: Always display menu. R699800 - Inti Series User Manual... -
Page 36: Line Display
Network (Inti 2 & Inti 3) When the Communication Terminal selected is LAN, this unit will be visible on the local Network and the following parameters need to be configured. See “LAN protocole (Inti 2 & Inti 3)”, page 49 for more details. Lamp Reset Resets the lamp use time to "0"... -
Page 37: Deep Color
Lamp Time Displays the accumulated hours of usage of the lamp. 6.8 Expert Calibration (Inti 2 & Inti 3) Expert Calibration is accessed only by using a programmable IR-RCU, RS-232C or LAN control. Two pairs of Picture Mode can be activated. Each pair of profiles, similar to Custom1 and Custom2 Picture Modes have to be calibrated. -
Page 38: Anamorphic Lens
7.1 Optional 2.35 CineWide and 2.35 THEATRE System (for Inti) The Inti Series centralizes the controls and automation commands for both the 2.35 CineWide and the 2.35 THEATRE System (for Inti) for a unique, versatile and unexpectedly simple to operate 2.35:1 theatre experience using an anamorphic Lens. -
Page 39: Cinewide
Plug the 12V Trigger output of the projector to the Anamorphic motorization 12V Trigger to anamorphic motorization Connect the 2.35 THEATRE System (for Inti) to the 12V Trigger output ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ Configure into Function “Menu Trigger On (Anamo)”... - Page 40 The Anamorphic Lens is automatically placed in front of the projector to restore the correct picture aspect ratio. Quick [Anamo]rphic mode change on the same input If the Trigger setting is set to On (Anamo), the 2.35 THEATRE System (for Inti) is automatically operated when selecting the correct anamorphic mode.
-
Page 41: Maintenance
Replacing a lamp with the plug connected to the outlet may cause injuries or electric shocks. Procedure for Lamp Replacement During the lamp replacement process, you may have access to sensitive parts of the projector. R699800 - Inti Series User Manual... -
Page 42: Cleaning And Replacing The Dust Filters
Clean the filters with water and dry them, avoiding direct sunlight. In extremely soiled cases, use of a neutral detergent is recommended. Insert the filters in their original positions and make sure that the claws are firmly inserted. Dust Filters R699800 - Inti Series User Manual... -
Page 43: Troubleshooting
The Cool Down mode is indicated by the blinking red STANDBY/ON led. When in Cool Down mode, the projector cannot be turned ON. After the Cool Down process is completed, the unit will automatically switch to the Standby mode indicated by a red STANDBY/ON led. R699800 - Inti Series User Manual... -
Page 44: Miscellaneous
If Command code is “52h 43h”, the Data sent may also be sent to the projector by a programmable RCU using NEC 5 protocole. Data 1 byte. See the list of the available data for each command below. Fixed to (0Ah) R699800 - Inti Series User Manual... - Page 45 52h 43h 37h 33h 30h 31h 37h 33h 30h 32h DOWN 37h 33h 30h 33h BACK 37h 33h 32h 45h MENU 37h 33h 32h 46h 37h 33h 33h 34h RIGHT 37h 33h 33h 36h LEFT R699800 - Inti Series User Manual...
- Page 46 37h 33h 37h 39h Contrast - Brightness 52h 43h 37h 33h 37h 41h Brightness + 37h 33h 37h 42h Brightness - Color 52h 43h 37h 33h 37h 43h Color + 37h 33h 37h 44h Color - R699800 - Inti Series User Manual...
- Page 47 Focus far Lens Focus - 52h 43h 37h 33h 33h 32h Focus near Lens Zoom T 52h 43h 37h 33h 33h 35h Zoom Tele Lens Zoom W 52h 43h 37h 33h 33h 37h Zoom Wide R699800 - Inti Series User Manual...
- Page 48 32h: Component 33h: VGA 36h: HDMI 1 37h: HDMI 2 Gamma Table 47h 54h Check the current Gamma table 30h: Normal (header 3Fh) 31h: A 32h: B 33h: C 34h: Custom1 35h: Custom2 36h: Custom3 R699800 - Inti Series User Manual...
-
Page 49: Lan Protocole (Inti 2 & Inti 3)
06h 89h 01h 49h 50h 0Ah (confirm cmd) receive: 40h 89h 01h 49h 50h 36h 0Ah (HDMI 1 is active) 9.2 LAN protocole (Inti 2 & Inti 3) LAN / RJ-45 communication specification To set the projector to LAN Control Mode, go to the Function menu, then set the Communication Terminal from RS- 232C (default) to LAN. -
Page 50: Infra Red, Long Hex-Pronto Compatible Rcu
0014 0014 0014 003C 0014 0014 0014 003C 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0336 A complete device/function chart with their corresponding long hex commands is available, ask your dealer if required. R699800 - Inti Series User Manual... -
Page 51: Pc Compatible Signals
35.000 66.667 30.240 H- V- 864 x 525 MAC 16” 832 x 624 49.107 75.087 55.000 H- V- 1120 x 654 MAC 19” 1024 x 768 60.241 74.927 80.000 H- V- 1328 x 804 R699800 - Inti Series User Manual... - Page 52 9.0 MISCELLANEOUS 9.5 Specifications Overview The Inti Series uses the latest technology developed to provide the ultimate video-projection experience. LCoS (Liquid Crystal on Silicon) technology based on a reflective principle features an extremely high-definition picture and seamless color gradations. Emission Method LCoS (Reflective Active Matrix Principle)
- Page 53 9.0 MISCELLANEOUS Dimensions 215 mm 8.5’’ 455 mm 505 mm 17.9’’ 19.9’’ 455 mm 17.9’’ Contact Information: TEC - Dreamvision 7, rue La CAILLE, 75017 Paris - FRANCE Web: www.dreamvision.net R699800 - Inti Series User Manual...
- Page 54 9.0 MISCELLANEOUS R699800 - Inti Series User Manual...
