Instruction Manual
1000 Mbps Gigabit Multi Mode SC/ ST Fiber
PCI Express Card - 550m
PEX1000MMSC
PEX1000MMST
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/06/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com PEX1000MMSC
Summary of Contents for StarTech.com PEX1000MMSC
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/06/2012...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ...................1 Features ................................ 1 Package Contents ............................. 1 Installation ....................2 Hardware Installation ..........................2 Connecting to a Network ........................3 Software Installation ..........................4 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com Multi Mode Fiber Gigabit Ethernet Card. A simple solution for connecting a host computer directly to a fiber network, the PEX1000MMSC/ PEX1000MMST provides full gigabit performance, ensuring the fastest network connections and reliable performance. -
Page 5: Installation
Be sure that you are properly grounded before opening your computer case or touching your PCI Express card. StarTech.com recommends that you wear an anti-static strap when installing any computer component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. -
Page 6: Connecting To A Network
Connecting to a Network Please note: You must connect the PCI Express Fiber Gigabit Ethernet Adapter to the network before installing the network driver. For connector type, cabling requirements, and maximum segment distance when connecting the PCI Express Gigabit Ethernet Adapter to your network, please refer to the following tables. -
Page 7: Software Installation
7. Check the LNK (Link) LED. The LED will come on when the PCI Express Fiber Gigabit Ethernet Adapter is receiving a good link signal from the connected device, a switch. Software Installation 1. Once PEX1000MMSC/ PEX1000MMST has been installed in the computer, turn on the power to the computer. - Page 8 4. Installation will begin... 5. Click Finish to complete the driver installation. Instruction Manual...
-
Page 9: Specifications
Specifications IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/100Base-FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX Applicable Standards IEEE802.3x IEEE802.1Q IEEE802.1p IEEE802.3ad LED Indicators Link, Activity Operating Temperature 0°C ~ 45° C (32°F ~ 113°F) Storage Temperature -10°C ~ 70°C (14°F ~ 158°F) Humidity 5% ~ 95% RH non-condensing Realtek RTL8168B Chipset Marvell 88E1111... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
