Sony DVP-NS71HP Service Manual page 79

DVP-NS71HP/NS75H/NS76H
Ref. No. Part No.
1 3-070-883-41
2 A-1164-622-A SERVICE ASSY, CASE UPPER
3 2-660-717-11
3 2-660-717-41
4 X-2108-001-1
4 X-2108-006-2
4 X-2148-042-1
5 3-087-053-01
6 3-077-331-11
7 1-828-451-11
7 1-828-450-11
7 1-828-454-11
7 1-828-871-11
8 1-831-570-11
9 1-831-569-11
* 10 1-831-571-11
* 11 1-831-572-11
* 12 1-831-575-11
13 3-077-331-21
14 A-1164-623-A SERVICE ASSY, MV (NS71HP/NS75H)
14 A-1164-642-A SERVICE ASSY, MV (NS76H:E)
14 A-1164-630-A SERVICE ASSY, MV (NS76H:SP)
14 A-1166-008-A SERVICE ASSY, MV (NS76H:KR)
14 A-1171-331-A SERVICE ASSY, MV (NS76H:AEP,UK)
14 A-1171-483-A SERVICE ASSY, MV (NS76H:RUS)
15 1-468-974-11
15 1-468-973-11
16 3-081-834-21
17 1-479-179-11
17 1-479-179-21
18 3-088-023-01
Description
SCREW, TAPPING
COVER, TRAY (NS71HP/NS75H)
COVER, TRAY (NS76H)
PANEL ASSY, FRONT (NS71HP/NS75H)
PANEL ASSY, FRONT (NS76H)
PANEL ASSY, FRONT (NS71HP)
+BVTP2.6 (3CR)
+BV3 (3-CR)
POWER-SUPPLY CORD (NS71HP/NS75H)
POWER-SUPPLY CORD (EXCEPT NS76H:UK,KR)
POWER-SUPPLY CORD (NS76H:UK)
POWER-SUPPLY CORD (NS76H:KR)
CABLE, FLEXIBLE FLAT (FMO-010)
CABLE, FLEXIBLE FLAT (FSW-002)
CABLE, FLEXIBLE FLAT (FMS-011)
CABLE, FLEXIBLE FLAT (FIM-014)
CABLE, FLEXIBLE FLAT (FME-005)
(NS76H:AEP,UK,RUS)
+BV3 (3-CR)
POWER SUPPLY BLOCK (NS71HP/NS75H)
POWER SUPPLY BLOCK (NS76H)
BATTERY COVER (SMK7G)
REMOTE COMMANDER (RMT-D175A)
(NS71HP/NS75H/NS76H:E,KR)
REMOTE COMMANDER (RMT-D175P)
(NS76H:SP,AEP,UK,RUS)
+B3 (3-CR)
Remark
8-2
Note :
The components identified by
mark or dotted line with mark
are critical for safety.
Replace only with part number
specified.
