IF-146 (INTERFACE) PRINTED WIRING BOARD
IF-146 BOARD (SIDE A)
C
B
A
1
2
IF-146 BOARD (SIDE B)
C
B
A
1
2
INTERFACE
IF-146
3 4 5 6
3 4 5 6
4-9
• : Uses unleaded solder.
7 8
7 8
DVP-NS71HP/NS75H/NS76H
For printed wiring board
There are a few cases that the part printed on
this diagram isn't mounted in this model.
Power Board
ER-41 Board (SCART)
(DVD-NS76H: AEP,UK ONLY)
MV-49 Board
(CPU, Servo-DSP, AVDEC, DRIVE,
VIDEO, AUDIO (2ch), AUDIO (8ch),
POWER SUPPLY, HDMI)
SW-470 Board
(SWITCH) IF-146 Board
(INTERFACE)
IF-146 BOARD
SIDE B
IC404 B-7
IC407 B-4
IC408 B-5
Q401 B-1
Q402 B-2
Q404 A-4
Q405 A-4
D402 B-2
D403 A-2
D406 A-2
4-10
