DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
SERVICE MANUAL
This service manual applicable for
DVP-NS47P/NS57P/NS64P/NS67P
starting from the serial number below:
4,100,001 ~ (BLACK)
5,200,001 ~ (SILVER )
RMT-D185P
Notes: Australia/NZ model only
RMT-D175A/RMT-D185A/RMT-D175P/RMT-D185P
Photo : DVP-NS67P
RMT-D185P
CD/DVD PLAYER
Argentina Model
Australian/
New Zealand Model
Brazilian Model
India Model
Iran Model
E Model
Saudi Arabia Model
Singapore Model
DVP-NS508P/NS608P
Canadian Model
DVP-NS64P/NS67P
Korea Model
Malaysia Model
Mexican Model
Pakistan,
Morocco Model
Taiwan Model
Thailand Model
Vietnam Model
DVP-NS508P
PX Model
US Model
DVP-NS57P
US Model
DVP-NS47P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-NS508P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony DVP-NS508P

Summary of Contents for Sony DVP-NS508P

  • Page 1 India Model Iran Model 4,100,001 ~ (BLACK) 5,200,001 ~ (SILVER ) E Model Saudi Arabia Model Singapore Model DVP-NS508P/NS608P Canadian Model DVP-NS64P/NS67P Korea Model Malaysia Model Mexican Model Pakistan, Morocco Model Photo : DVP-NS67P...
  • Page 2 COMPONENT VIDEO OUT (Y, P Laser: Semiconductor laser (DVP-NS47P/NS57P/NS508: AR, BR, E, Power requirements: MX/NS67P/64P/NS608: E, AR, BR): 110 V AC, 60 Hz (DVP-NS508P: TW) Outputs Phono jack/Y: 1.0 Vp-p/P 110 – 240 V AC, 50/60 Hz (DVP-NS57P: (Jack name: interlace = 0.648 Vp-p, progressive or...
  • Page 3 PART CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY MENTS PUBLISHED BY SONY. DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

  • Page 4: Table Of Contents

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P TABLE OF CONTENTS SERVICE NOTE BLOCK DIAGRAMS Disc Removal Procedure (at POWER OFF) ......5E 3-1. Overall Block Diagram ............3-1 Child Lock Disabled Procedure ........5E 3-2. Power Line Block Diagram ..........3-3 3-3. System Control/Signal Processor Block Diagram ....3-5 3-4.

  • Page 5: Service Note

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SERVICE NOTE 1. DISC REMOVAL PROCEDURE (at POWER OFF) 1) Open dust cover to access to a hole insert a tapering driver into the aperture of the unit bottom, and move the lever of chuck can in the direction of the arrow A. (See Fig. 1) 2) Draw out the tray in the direction of the arrow B, and remove a disc.

  • Page 6: General

    • Do not use solvents such as concerning your player, please consult your collection systems. benzine, thinner, commercially nearest Sony dealer. On operation available cleaners, or anti-static Please recycle used batteries. spray intended for vinyl LPs. • If the player is brought directly from a cold •...

  • Page 7: Guide To Parts And Controls

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Note on playback operations of Notes Guide to Parts and Controls • Notes about DVD+RWs/DVD+Rs/ DVDs and VIDEO CDs DVD+Rs DL, DVD-RWs/DVD-Rs/ For more information, see the pages indicated in parentheses. DVD-Rs DL, or CD-Rs/CD-RWs Some playback operations of DVDs and Some DVD+RWs/DVD+Rs/DVD+Rs DL, VIDEO CDs may be intentionally set by DVD-RWs/DVD-Rs/DVD-Rs DL, or CD-Rs/...

  • Page 8: Guide To The Control Menu Display

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P List of Control Menu items SETUP Guide to the Control Menu Display QUICK Setup Item Item Name, Function Use Quick Setup to choose the desired language of the on-screen TITLE/SCENE/TRACK Use the Control Menu to select a function and to view related information. Press DISPLAY display, the aspect ratio of the TV Selects the title, scene, or track to be repeatedly to turn on or change the Control Menu display as follows:...

  • Page 9: Step 3: Connecting The Audio Cords

    Plug the player and TV mains lead (power cord) into a mains. You can control the sound level, input source, Sony 01 (default) and power switch of your Sony TV with the Aiwa 01 (default) supplied remote. Step 5: Preparing the Remote...

  • Page 10: Step 6: Quick Setup

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Press X/x to select the type of Press ENTER. Step 6: Quick Setup Dolby Digital signal you wish to The Setup Display for selecting the aspect ratio of the TV to be connected send to your audio component. appears. Follow the steps below to make the minimum number of basic adjustments for using the player.

  • Page 11: Various Play Mode Functions (Programme Play, Shuffle Play, Repeat Play, A-B Repeat Play)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Press TIME/TEXT repeatedly to Resuming Playback From the Using the DVD’s Menu Playing VIDEO CDs With PBC change the time information. Point Where You Stopped the Functions (PBC Playback) A DVD VIDEO is divided into long sections The available time information depends Disc (Multi-disc Resume) of a picture or a music feature called “titles.”...

  • Page 12: Adjusting The Playback Picture (Custom Picture Mode)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P ◆ When Programme Play is activated Follow step 5 for new programming. To “TRACK” is displayed when you play PROGRAM cancel a programme, select “--” under • ON: shuffles titles, chapters, or tracks a VIDEO CD or CD. ALL CLEAR “T,”...

  • Page 13: Sharpening The Picture (Sharpness)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P • DYNAMIC 2: produces a more Press ENTER. Sharpening the Picture Locking Discs dynamic picture than DYNAMIC 1 by The adjustment is saved, and (CUSTOM further increasing the picture contrast “BRIGHTNESS” adjustment bar (SHARPNESS) PARENTAL CONTROL, PARENTAL and colour intensity. appears.

  • Page 14: Searching For A Scene

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P ◆ When playing a CD Playback direction Searching for a Title/ TRACK × 2B t 1M t 2M t 3M Searching for a Scene Chapter/Track/Scene, ◆ When playing a DATA CD/DATA DVD 3M (DVD/VIDEO CD only) ALBUM Searching for a etc.

  • Page 15: Changing The Sound

    ◆ When playing in DVD-VR mode Dolby Digital 5.1 ch When playing a DVD VIDEO recorded in TVS was developed by Sony to produce multiple audio formats (PCM, Dolby Digital, The types of sound tracks recorded on a surround sound for home use using just a...
  • Page 16 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Press H. When you insert a DATA CD/DATA DVD Selecting a JPEG image file and press H, the numbered tracks (or files) Playing MP3 Audio Playback starts from the selected album. are played sequentially, from 1 through 7. To select MP3 audio tracks, see Tracks or JPEG Image Any sub-albums/tracks (or files) contained After step 2 of “Selecting an album,”...

  • Page 17: Using The Setup Display

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Press X/x to select “CUSTOM,” Selecting the slides’ appearance then press ENTER. (EFFECT) Settings and Adjustments The Setup Display appears. You can select the way the slides are Using the Setup Display LANGUAGE SETUP displayed during a slide show. OSD: ENGLISH MENU:...

  • Page 18: Custom Settings (Custom Setup)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P ◆ PROGRESSIVE (COMPONENT OUT ◆ 4:3 OUTPUT ◆ PAUSE MODE (DVDs only) Custom Settings ONLY) This setting is effective only when you set Selects the picture in pause mode. (CUSTOM “TV TYPE” in “SCREEN SETUP” to If your TV accepts progressive (525p/625p) AUTO The picture, including subjects SETUP)

  • Page 19: Additional Information

    When the self-diagnosis function is activated disc. , Contact your Sony dealer or local to prevent the player from malfunctioning, a five-character service number (e.g., C 13 50) authorized Sony service facility.

  • Page 20: Specifications

    LINE OUT (VIDEO): Phono jack/1.0 Vp-p/75 ohms Specifications and design are subject to change without notice. NERGY is a U.S. registered mark. As an NERGY Partner, Sony Corporation has determined that this product meets the NERGY guidelines for energy efficiency. 1-15E 1-15...

  • Page 21: Disassembly

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 2 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. 2-1. UPPER CASE 4 Two Tapping Screws 6 Upper case 3 Tray Cover 5 Three Tapping Screws Chassis Back 2-2. FRONT PANEL ASSEMBLY 4 Claw 1 Claw...

  • Page 22: Loading Assembly

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-3. LOADING ASSEMBLY 6 Three Screws +BV3 (3-CR) 7 Loading Assembly 1 FMO-013 Flat Flexible Cable (CN101, 24P) 2 MD-119 Harness (CN201, 6P) 3 FMS-015 Flat Flexible Cable (CN202, 5P) 4 PM-136 Harness (CN501, 10P) 5 PM-136 Harness (CN201, 10P)

  • Page 23: Optical Pick-Up (Device, Optical Khm-313Caa/C2Rp)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-4. OPTICAL PICK-UP Note: (DEVICE, OPTICAL KHM-313CAA/C2RP) Solder shortland before remove the FMO-013 Flat Flexible Cable from 24 pin BU connector. 6 Two Insulator 3 Optical Device 5 FMO-013 Flat Flexible Cable (CN101, 24P) (KHM-313CAA/C2RP) 6 Two Insulator 4 MD-119 Harness (CN201, 6P) 1 Four Insulator Screws 2 FFC Holder Caution Point on the Laser Diode:...

  • Page 24: Rear Panel, Mv-57 Board And If-156 Board

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-5. REAR PANEL, MV-57 BOARD and IF-156 BOARD Note: Caution Point on the PWB IF-156 When handling IF-156 PWB avoid contact with the sharp metal edge on the top side of Vacuum Fluorescent Display (ND402). 6 FMO-008 Flat Flexible Cable (CN101, 24P) 7 PM-136 Harness (CN501, 10P)

  • Page 25: Switching Regulator

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-6. SWITCHING REGULATOR 2 Two Screws +BV3 (3-CR) 1 Connector (PM-136 Harness, CN201, 10P) 3 Power Board...

  • Page 26: Internal Views

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-7. INTERNAL VIEWS TOP VIEW MS-203 MOUNT BOTTOM VIEW...

  • Page 27: Circuit Boards Location

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-8. CIRCUIT BOARDS LOCATION Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO,AUDIO, POWER) MS-203 Board IF-156 Board (INTERFACE) 2-7E...

  • Page 28: Block Diagrams

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 3 BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM • Abbreviation : Argentina Model AUS : Australia/NZ Model : Brazilian Model CND : Canadian Model : Latin America Model : Saudi Arabia Model : India Model : Iran Model : Korea Model ME5 : PAK,MOR Model MX : Mexican Model MY : Malaysian Model...

  • Page 29: Power Line Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-2. POWER LINE BLOCK DIAGRAM (SEE PAGE 4-11 TO 4-22) (SEE PAGE 4-25 TO 4-26) (SEE PAGE 4-29 TO 4-30E) RECTIFIER FG002 The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified.

  • Page 30: System Control/Signal Processor Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-3. SYSTEM CONTROL/SIGNAL PROCESSOR BLOCK DIAGRAM (SEE PAGE 4-13 TO 4-14) IC101 3.3Vp-p 121.5MHz CXD9932 R-K CHIP (DVP-NS47P/NS57P/NS508P) CXD9933R-L CHIP (DVP-NS64P/NS67P/NS608P) (SEE PAGE 3-13 TO 3-14) (SEE PAGE 3-11 TO 3-12) IC101 IC101 C/BAR/PB IC101 C/BAR PB IC101 C/BAR PB IC101 C/BAR/PB 1.9Vp-p...

  • Page 31: Rf/Servo Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-4. RF/SERVO BLOCK DIAGRAM (SEE PAGE 4-15 TO 4-16) TO CN401 IF-156 BOARD (SEE PAGE 3-13 TO 3-14) IC101 (CD PB) IC101 (DVD PB) (0.5Vp-p to (0.65Vp-p to 200nsec 100nsec 1.48Vp-p) 1.1Vp-p)

  • Page 32: Video Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-5. VIDEO BLOCK DIAGRAM (SEE PAGE 4-17 TO 4-18) IC304 C/BAR PB 2.0Vp-p IC304 C/BAR PB IC304 C/BAR PB IC304 C/BAR PB 1.4Vp-p 1.4Vp-p 2.0Vp-p 3-10...

  • Page 33: Audio Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-6. AUDIO BLOCK DIAGRAM (SEE PAGE 4-19 TO 4-20) (SEE PAGE 3-5 TO 3-6) (SEE PAGE 3-5 TO 3-6) 3-11 3-12...

  • Page 34: Interface Control Block Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 3-7. INTERFACE CONTROL BLOCK DIAGRAM IF-156 BOARD (SEE PAGE 4-5 TO 4-8) LDMP OCSW OCSW SYSTEM CONTROL TO CN107 MV-57 BOARD (SEE PAGE 3-5 TO 3-6) XIFSDO X IFSDI X IFSCK XA_MUTE XV_MUTE 3-13 3-14E...

  • Page 35: Frame Schematic Diagram

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. FRAME SCHEMATIC DIAGRAM FRAME SCHEMATIC DIAGRAM...

  • Page 36: Waveform

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P WAVEFORM 4-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS MV-57 BOARD THIS NOTE IS COMMON FOR WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block) IC101 C/BAR PB IC101 (CD PB) IC304 C/BAR PB For printed wiring boards: •...
  • Page 37 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P IF-156 (INTERFACE) PRINTED WIRING BOARD For printed wiring board • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. IF-156 BOARD (SIDE A) Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO, AUDIO, POWER) MS-203 Board IF-156 Board...
  • Page 38 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-5 to 4-6 for printed wiring board of IF-156 board. IF-156 BOARD INTERFACE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE INTERFACE IF-156...
  • Page 39 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P MS-203 (LOADING MOTOR) PRINTED WIRING BOARD For printed wiring board • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. MS-203 BOARD Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO, AUDIO, POWER) S001 (CHUCK/TRAY DETECT) C001...
  • Page 40 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P MV-57 (SYSTEM, DRIVE, VIDEO, AUDIO, POWER) PRINTED WIRING BOARD For printed wiring board • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. MV-57 BOARD (SIDE A) Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO, AUDIO, POWER)
  • Page 41 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-11 to 4-12 for printed wiring board of MV-57 board. • Refer to page 4-4 for waveform MV-57 BOARD (1/5) SYSTEM -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 3, ol SYSTEM MV-57 (1/5) 4-13 4-14...
  • Page 42 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-11 to 4-12 for printed wiring board of MV-57 board. • Refer to page 4-4 for waveform MV-57 BOARD (2/5) DRIVE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE DRIVE MV-57 (2/5) 4-15 4-16...
  • Page 43 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-11 to 4-12 for printed wiring board of MV-57 board. • Refer to page 4-4 for waveform MV-57 BOARD (3/5) VIDEO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE qs, wl q;, wg 9, wd qa, wa VIDEO...
  • Page 44 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-11 to 4-12 for printed wiring board of MV-57 board. • Refer to page 4-4 for waveform MV-57 BOARD (4/5) AUDIO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE AUDIO MV-57 (4/5) 4-19 4-20...
  • Page 45 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-11 to 4-12 for printed wiring board of MV-57 board. • Refer to page 4-4 for waveform MV-57 BOARD (5/5) POWER -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE TO CN201 (DVP-NS57P:PX/NS508P:EXCEPT MX/NS508P) (SEE PAGE 4-25 TO 4-26) SRV1873UC (SEE PAGE 4-29 TO 4-30E)

  • Page 46: Power Block (Srv1873Uc) Printed Wiring Board

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P POWER BLOCK (SRV1873UC) PRINTED WIRING BOARD For printed wiring board • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. POWER BOARD (SRV1873UC) (SIDE A) Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO, AUDIO, POWER) MS-203 Board...
  • Page 47 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-23 to 4-24 for printed wiring board of Power board. POWER BOARD POWER SUPPLY (SRV1872WW) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE EVER-10V POWER SW P-CONT SW+5V TO CN501 MV-57 BOARD (SEE PAGE 4-21 TO 4-22) SW+3.3V...
  • Page 48 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P POWER BLOCK (SRV1873UC) PRINTED WIRING BOARD For printed wiring board • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. POWER BOARD (SRV1873UC) (SIDE A) Power Board MV-057 Board (SYSTEM, DRIVE, VIDEO,AUDIO, POWER) MS-203 Board...
  • Page 49 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P For Schematic Diagram • Refer to page 4-27 to 4-28 for printed wiring board of Power board. POWER BOARD POWER SUPPLY (SRV1873UC) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE EVER-10V POWER SW P-CONT SW+5V TO CN501 MV-57 BOARD (SEE PAGE 4-21 TO 4-22) SW+3.3V...

  • Page 50: Ic Pin Function Description

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 5 IC PIN FUNCTION DESCRIPTION 5-1. SYSTEM CONTROL IC PIN FUNCTION DESCRIPTION (MV-57 BOARD, IC101-CXD9932R K CHIP) (DVP-NS47P/NS57P/NS508P) Pin No. Pin name Type Function Analog Input RF main beam input A Analog Input RF main beam input B Analog Input RF main beam input C Analog Input...
  • Page 51 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Pin No. Pin name Type Function DVDD33 Power 3.3V power pin for internal digital circuitry InOut DRAM data bit 5 InOut DRAM data 6 InOut DRAM data 7 DVDD18 Power 1.8V power pin for internal digital circuitry InOut Data Mask 0 RD15 InOut DRAM data bit 15...
  • Page 52 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Pin No. Pin name Type Function R/CR/PR Analog Red, CR/PR, CVBS or SY AADVSS Ground Ground pin for 2ch audio DAC circuitry Analog Not Used Analog Not Used Analog Not Used AADVDD Power 3.3V Power pin for 2ch audio ADC circuitry APLLVDD3 Power 3.3V Power pin for audio clock circuitry...

  • Page 53: System Control Ic Pin Function Description (Mv-57 Board, Ic101 Cxd9933R L Chip)

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 5-2. SYSTEM CONTROL IC PIN FUNCTION DESCRIPTION (MV-57 BOARD, IC101 CXD9933R L CHIP) (DVP-NS64P/NS67P/NS608P) Pin No. Pin name Type Function Analog Input RF main beam input A Analog Input RF main beam input B Analog Input RF main beam input C Analog Input RF main beam input D Analog Input...
  • Page 54 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Pin No. Pin name Type Function InOut DRAM data 7 DVDD18 Power 1.8V power pin for internal digital circuitry InOut Data Mask 0 RD15 InOut DRAM data bit 15 RD14 InOut DRAM data bit 14 RD13 InOut DRAM data bit 13 RD12 InOut DRAM data bit 12...
  • Page 55 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P Pin No. Pin name Type Function DISC/EXT Analog DISC/External input select output signal (H: DISC, L: EXTin) ADVCM Analog 2ch audio ADC reference voltage RGBSEL/ MIC ADIN 1 Analog 1. RGB/YCbCr select output signal (H:RGB Disable, L:RGB Enable) - MV-58 Only 2.

  • Page 56: Test Mode

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 6 TEST MODE 6-1. EXECUTING IOP MEASUREMENT (5) Wait until a hexadecimal number appear. Manual Adjust In order to execute IOP measurement, the following standard procedures must be followed. 1. Track Balance Adjust: 2. Track Gain Adjust: (1) In standby mode, press [TOP MENU], [CLEAR], [POWER] to 3.

  • Page 57: Initializing Setup Data

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P (6) Error code list (10) How to Clearing Emergency code 01: Communication error (No reply from syscon) Press [TOPMENU], [CLEAR] keys in this order. 02: Syscon hung up All emergency code are cleared. 03: Power OFF request when syscon hung up Emg.

  • Page 58: Version Information

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P (4) The Emergency history display screen will be restored soon. 6-5. IF CON SELF DIAGNOSTIC FUNCTION Emg. History Check IF-156 BOARD (IF CON) TEST MODE The IF-156 board (IF CON) test mode is the IF CON self-diagnosis Laser Hours 999h 59min mode.
  • Page 59 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-2. Operation of Auto Self Check When the Self Check mode becomes active at the AC Power ON or by key input, the test display of the following steps (1) to (4) is repeated. (1) FLD and all ON (for 5 seconds) (2) MODEL display (for 2 seconds) a) DVP-NS47P/NS57P/NS508P b) DVP-NS64P/NS67P/NS608P...
  • Page 60 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-3-1. FLD All ON 2-3-1-1. Transition Keys in Self Check Mode • Z key and x key on the main unit • T key on the remote commander 2-3-1-2. Operation and display In this mode, all segments of FLD turn ON. •...
  • Page 61 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-3-3. Remote Commander Key Name Display and Key Code Display 2-3-3-1. Transition Keys in Self Check Mode • Remote commander keys except keys transited in Self Check Mode 2-3-3-2. Operation and Display When a key on the remote commander is pressed in the Self Check Mode, the name of that key is displayed on the FLD. Aslo, the key name display and the key code display can be switched with the [DISPLAY] key on the remote commander.
  • Page 62 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-3-5. FLD Anode Test Display and SHUTTLE Click Operation Test 2-3-5-1. Transition Keys in Self Check Mode • t key on the remote commander • SHUTTLE on the remote commander during Anode Test display (This unit does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/SHUTTLE) 2-3-5-2.
  • Page 63 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2-3-7. LED Test Display 2-3-7-1. Transition Keys in Self Check Mode • key on the remote commander • SHUTTLE on the remote commander during Grid Test display (This model does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/SHUTTLE) 2-3-7-2.
  • Page 64 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P (5G, 3G) (7G~2G) (7G~1G) ANODE CONNECTION 6-9E...

  • Page 65: Electrical Adjustment

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P SECTION 7 ELECTRICAL ADJUSTMENT This section describes procedures and instructions necessary for 7-1. POWER SUPPLY OUTPUT VOLTAGE adjusting electrical circuits in this unit. CHECK Instruments required: Mode Except standby (1) Color monitor TV Instrument Digital multimeter (2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz, with delay mode EVER+5V Check (3) Frequency counter (over 8 digits)

  • Page 66: Adjustment Of Video System

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 7-2. ADJUSTMENT OF VIDEO SYSTEM Checking Component Video Output B-Y <Purpose> Checking Video Level This checks component video output B-Y. If it is incorrect, correct <Purpose> colors will not be displayed when connected to, for instance, Checking Video Level the NTSC/PAL standard, and if not correct, projector.

  • Page 67: Repair Parts List

    : Iran Model supplied. KR : Korea Model VN : Vietnam Model • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) Parts Color Cabinet's Color 8-1-1. MAIN SECTION ns : not supplied DVP-NS47P/NS57P/NS64P/67P DVP-NS508P/NS608P...
  • Page 68 COVER, BATTERY (DVP-NS508P/NS57P/NS64P (NS508P:EXCEPT AR,BR) NS67P/NS608P:IN,EA,IR) (SILVER) X-2188-523-1 PANEL ASSY, FRONT (NS508P:EXCEPT AR,BR) (SILVER) A-1494-216-A PANEL ASSY, FRONT (DVP-NS508P:AR,BR) (BLACK) X-2188-525-1 PANEL ASSY, FRONT (DVP-NS508P:AR,VN) (SILVER) A-1439-798-A SERVICE ASSY, MV (NS47P/NS57P:US) X-2188-448-1 PANEL ASSY, FRONT (DVP-NS64P) (SILVER) A-1486-731-A SERVICE ASSY, MV (DVP-NS508P:MX)

  • Page 69: Mechanism Deck Assembly

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 8-1-2. MECHANISM DECK ASSEMBLY ns : not supplied Ref. No. Part No. Description Remark A-6071-669-A LOADING ASSY(M) 3-088-372-01 INSULATOR 3-087-599-01 INSULATOR SCREW Note : 4-674-137-11 SCREW (PTP2X5) The components identified by mark 3-088-371-01 BELT dotted line with mark are critical for safety.

  • Page 70: Electrical Parts List

    DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P IF-156 The components identified by mark 8-2. ELECTRICAL PARTS LIST or dotted line with mark are critical for safety. Replace only with part number NOTE: specified. • Due to standardization, replacements in the uA. . : µA. . uPA. . : µPA.
  • Page 71 1/10W R406 1-216-809-91 METAL CHIP 1/10W A-1439-798-A SERVICE ASSY, MV (NS47P/-NS57P:US) R407 1-216-809-91 METAL CHIP 1/10W A-1486-731-A SERVICE ASSY, MV (DVP-NS508P:MX) R408 1-216-809-91 METAL CHIP 1/10W A-1483-883-A SERVICE ASSY, MV (DVP-NS508P:IN) R409 1-216-809-91 METAL CHIP 1/10W A-1486-715-A SERVICE ASSY, MV (DVP-NS508P:IR)
  • Page 72 10.00% C175 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% EXCEPT (DVP-NS47P/NS57P/ND508P:E,MX) C179 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C427 1-126-947-11 CAP, ELECT 47UF EXCEPT (DVP-NS508P:MX,E/NS47P/NS57P) C180 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C428 1-165-908-91 CERAMIC CHIP C181 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C182 1-127-715-91 CERAMIC CHIP 0.22UF...
  • Page 73 IC402 8-759-278-58 IC NJM4558V-TE2 R1145 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P) IC405 6-600-430-01 IC TOTX177(F,T) R1146 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P) (DVP-NS508P:EXCEPT (MX,E,AR,BR)/NS608P:SP,EA) IC406 6-703-597-01 IC BD4830G-TR R115 1-211-977-91 METAL CHIP 0.5% 1/10W R1150 1-216-827-91 METAL CHIP 3.3K 1/10W...
  • Page 74 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P MV-57 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R204 1-216-822-91 METAL CHIP 1.2K 1/10W R430 1-216-841-91 METAL CHIP 1/10W R205 1-216-833-91 METAL CHIP 1/10W R434 1-208-699-11 RES,METAL FILM CHIP 4.7K (1005) R206 1-216-833-91 METAL CHIP 1/10W R435 1-208-699-11...
  • Page 75 ADAPTOR, CONVERSION 2P (DVP-NS608P:E/NS508P:E/NS57P:PX3) 1-828-145-11 CORD, CONNECTION (AV) 3-283-141-21 MANUAL, INSTRUCTION (DVP-NS47P) (ENGLISH) 3-283-141-11 MANUAL, INSTRUCTION (DVP-NS57P) (ENGLISH) 3-283-141-31 MANUAL, INSTRUCTION (DVP-NS508P:E,MX) (SPANNISH) 3-283-142-11 MANUAL, INSTRUCTION (DVP-NS508P:EA,IN,IR,SP,TH,MY,TW,ME,AUS) (ENGLISH) 3-283-142-21 MANUAL, INSTRUCTION (DVP-NS508P:TH) (THAI) 3-283-142-31 MANUAL, INSTRUCTION (DVP-NS508P:MY) (CHINESE SIMPLIFIED) 3-283-142-41...
  • Page 76 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2008A1100-1 Sony Corporation 2008.01 Home Electronics Network Company. 9-883-974-11 Published by Product Design 1 Department – 98 – 8-14...
  • Page 77 : Iran Model : USA Model supplied. KR : Korea Model VN : Vietnam Model • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) Parts Color Cabinet's Color 8-1-1. MAIN SECTION ns : not supplied DVP-NS47P/NS57P/NS64P/67P DVP-NS508P/NS608P...
  • Page 78 COVER, BATTERY (DVP-NS508P/NS57P/NS64P (NS508P:EXCEPT AR,BR) NS67P/NS608P:IN,EA,IR) (SILVER) X-2188-523-1 PANEL ASSY, FRONT (NS508P:EXCEPT AR,BR) (SILVER) A-1494-216-A PANEL ASSY, FRONT (DVP-NS508P:AR,BR) (BLACK) X-2188-525-1 PANEL ASSY, FRONT (DVP-NS508P:AR,VN) (SILVER) A-1439-798-A SERVICE ASSY, MV (NS47P/NS57P:US) X-2188-448-1 PANEL ASSY, FRONT (DVP-NS64P) (SILVER) A-1486-731-A SERVICE ASSY, MV (DVP-NS508P:MX)
  • Page 79 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 8-1-2. MECHANISM DECK ASSEMBLY ns : not supplied Ref. No. Part No. Description Remark A-6071-669-A LOADING ASSY(M) 3-088-372-01 INSULATOR 3-087-599-02 INSULATOR SCREW Note : 4-674-137-11 SCREW (PTP2X5) The components identified by mark 3-088-371-01 BELT dotted line with mark are critical for safety.
  • Page 80 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P IF-156 The components identified by mark 8-2. ELECTRICAL PARTS LIST or dotted line with mark are critical for safety. Replace only with part number NOTE: specified. • Due to standardization, replacements in the uA. . : µA. . uPA. . : µPA.
  • Page 81 1/10W R406 1-216-809-91 METAL CHIP 1/10W A-1439-798-A SERVICE ASSY, MV (NS47P/-NS57P:US) R407 1-216-809-91 METAL CHIP 1/10W A-1486-731-A SERVICE ASSY, MV (DVP-NS508P:MX) R408 1-216-809-91 METAL CHIP 1/10W A-1483-883-A SERVICE ASSY, MV (DVP-NS508P:IN) R409 1-216-809-91 METAL CHIP 1/10W A-1486-715-A SERVICE ASSY, MV (DVP-NS508P:IR)
  • Page 82 10.00% C175 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% EXCEPT (DVP-NS47P/NS57P/ND508P:E,MX) C179 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C427 1-126-947-11 CAP, ELECT 47UF EXCEPT (DVP-NS508P:MX,E/NS47P/NS57P) C180 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C428 1-165-908-91 CERAMIC CHIP C181 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% C182 1-127-715-91 CERAMIC CHIP 0.22UF...
  • Page 83 IC402 8-759-278-58 IC NJM4558V-TE2 R1145 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P) IC405 6-600-430-01 IC TOTX177(F,T) R1146 1-216-864-91 SHORT CHIP 0 EXCEPT (NS47P/NS57P) (DVP-NS508P:EXCEPT (MX,E,AR,BR)/NS608P:SP,EA) IC406 6-703-597-01 IC BD4830G-TR R115 1-211-977-91 METAL CHIP 0.5% 1/10W R1150 1-216-827-91 METAL CHIP 3.3K 1/10W...
  • Page 84 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P MV-57 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R204 1-216-822-91 METAL CHIP 1.2K 1/10W R430 1-216-841-91 METAL CHIP 1/10W R205 1-216-833-91 METAL CHIP 1/10W R434 1-208-699-11 RES,METAL FILM CHIP 4.7K (1005) R206 1-216-833-91 METAL CHIP 1/10W R435 1-208-699-11...
  • Page 85 ADAPTOR, CONVERSION 2P (DVP-NS608P:E/NS508P:E/NS57P:PX3) 1-828-145-11 CORD, CONNECTION (AV) 3-283-141-21 MANUAL, INSTRUCTION (DVP-NS47P) (ENGLISH) 3-283-141-11 MANUAL, INSTRUCTION (DVP-NS57P) (ENGLISH) 3-283-141-31 MANUAL, INSTRUCTION (DVP-NS508P:E,MX) (SPANNISH) 3-283-142-11 MANUAL, INSTRUCTION (DVP-NS508P:EA,IN,IR,SP,TH,MY,TW,ME,AUS) (ENGLISH) 3-283-142-21 MANUAL, INSTRUCTION (DVP-NS508P:TH) (THAI) 3-283-142-31 MANUAL, INSTRUCTION (DVP-NS508P:MY) (CHINESE SIMPLIFIED) 3-283-142-41...
  • Page 86 DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P 2008A1100-1 Sony Corporation 2008.01 Home Electronics Network Company. 9-883-974-11 Published by Product Design 1 Department – 98 – 8-14...
