TECHNICAL SPECIFICATIONS
MODEL
PS-5
MAX. CAPACITY
5 kg, 10 lb, 160 oz
MIN. DIVISION
0.005 kg, 0.01 lb, 0.2 oz
MAX. TARE
5 kg, 10 lb, 160 oz
OPERATION TEMPERATURE RANGE
14 TO 104 ºF ( -10 TO 40ºC)
STORAGE TEMPERATURE RANGE
-4 TO 122 ºF ( -20 TO 50ºC)
AC/DC POWER SUPPLY :
OUTPUT 9 Vd.c. 500 mA.
DIMENTIONS
NOTE : THIS PRODUCT'S SERIAL NUMBER CAN BE
HOLDER ON THE CABINET OF THE SCALE. WE SUGGEST THAT YOU WRITE DOWN
THAT SERIAL NUMBER AND THE CORRESPONDING MODEL IN THE FOLLOWING
BLANKS AND KEEP THEM AS PERMANENT PROOF OF YOUR ACQUISITION, TO HELP
IN THE IDENTIFICATION IN CASE OF LOSS OR FURTHER CONSULTATIONS.
DISTRIBUTOR:_____________________________________________________________
ADDRESS_:________________________________________________________________
TELEPHONE________________________________________________________________
DATE OF
PURCHASE:________________________________________________________________
MODEL:____________________________________________________________________
SERIAL NUMBER: ___________________________________________________________
U
APPROVED
L
R
FOUND UNDER THE PLATE
FABRICANTES DE BASCULAS TORREY
S.A. DE C.V.
ELECTRONIC SCALE
PS SERIES
PS SERIES
USER MANUAL
REVISION: 1.0
IMPORTANT:
BEFORE OPERATING THIS SCALE, PLEASE READ THIS MANUAL THOROUGHLY.
Advertisement
Related Manuals for Torrey PS Series
Summary of Contents for Torrey PS Series
-
Page 1: User Manual
FABRICANTES DE BASCULAS TORREY TECHNICAL SPECIFICATIONS MODEL PS-5 MAX. CAPACITY 5 kg, 10 lb, 160 oz S.A. DE C.V. MIN. DIVISION 0.005 kg, 0.01 lb, 0.2 oz MAX. TARE 5 kg, 10 lb, 160 oz OPERATION TEMPERATURE RANGE 14 TO 104 ºF ( -10 TO 40ºC) STORAGE TEMPERATURE RANGE -4 TO 122 ºF ( -20 TO 50ºC) - Page 2 MAINTENANCE AND CLEANING. DEAR COSTUMER: WE APPRECIATE YOUR PREFERENCE. YOU HAVE JUST ACQUIRED A TORREY DO NOT PUT OVERWEIGH OVER THE SCALE ELECTRONIC SCALE, INTERNATIONAL DISTINGUISHED FOR ITS PRECISION AND QUALITY. NEVER PRESS THE KEYBOARD WITH OBJECTS SUCH AS PENCILS, PENS, KNIVES, WITHOUT DOUBT, WE ASSURE THAT YOU WILL BE PLENTY SATISFIED WITH YOUR ETC.
- Page 3 3.- PLATE HOLDER: MANUFACTURED IN ALUMINUM THAT PROVIDES SUPPORT BUT IF YOU PRESS THE KEY THE SCALE WILL CHANGE TO “Kg” MODE AND YOU WILL SEE THE FOLLOWING IN THE VIEW FINDER 4.- BATTERY COMPARTMENT: PLACE WHERE IS LOCATED THE 9 VOLT BATTERY (NO INCLUDED) 5.- JACK: CONNECTS THE AC/DC POWER SUPPLY TO THE SCALE WHICH IS LOCATED IN THE BOTTOM OF THE SCALE (IN THE BASE).
- Page 4 TARE TO CANCEL THE TARE FUNCTION JUST PRESS THE KEY AND THE SCALE WILL OPERATION RETURN TO THE NORMAL FUNCTION. THE NET SYMBOL WILL DISAPPEAR NOTE: MAKE SURE THAT THE SCALE IS FREE OF WEIGHT OVER THE PLATE HOW TO WEIGHT A PRODUCT TURN YOUR SCALE ON PRESSING THE KEY.
