- Page 1 OWNER’S MANUAL PORTIONING SCALE L-EQ HS Series BEFORE OPERATING THIS SCALE, PLEASE READ THIS MANUAL THOROUGHLY. CODE: 13100907 REV 0...
-
Page 2: Table Of Contents
Format of the data sent to the PC Using Scale software Power timer function. Low battery indicator Use of the battery Other important messages that appear on the scale Maintenance and cleaning Troubleshooting guide Technical specifications Additional data L-EQ HS Series... -
Page 3: Important Warnings
Portioning Scale IMPORTANT WARNINGS In case you have any problem with the scale, read the warranty conditions. Do not open the scale your warranty will be canceled. Do not press the keyboard with any sharp and/or pointed objects. Use a VAC outlet exclusive for the scale, avoiding overloads or voltage variations. - Page 4 WARNING Do not open the scale Caution: to reduce the risk of short circuit in your scale, do not remove the cover or substitute any of the parts for others that are not original only authorized distributor. L-EQ HS Series...
-
Page 5: Introduction
Portioning Scale INTRODUCTION Dear customer: We appreciate that you have chosen this product. We assure you that you will get the maximum satisfaction of the new acquisition for your business. We suggest you to read carefully this manual and make sure to keep it at hand for later consultations. -
Page 6: Name And Location Of Parts
LEVEL INDICATOR: Used as a scale’s leveling reference. POWER SUPPLY: 110VAC/6VDC 220VAC/6VDC (included). 10. RS232 CONNECTOR: connect the scale with a PC printer using RS232 cable. 11. TARE FOOTSWITCH CONNECTION: To connect the external tare footswitch. L-EQ HS Series... -
Page 7: Keyboard
Portioning Scale KEYBOARD Turn on the scale. Turn off the scale. Show the weight on the PC screen. Communication through RS232. Activate the TARA function. Activate the ZERO function. Show the weight in kg. Show the weight in lb. Show the weight in oz. Increase the weight to be set for the weight alarm. -
Page 8: Lcd Display Screen
WEIGHT UNIT INDICATOR: Displays the selected weight unit. ALPHANUMERIC INDICATOR: Displays the weight and messages of the scale. LOW BATTERY INDICATOR: appears when the battery power is low and indicates that it is necessary to recharge it. L-EQ HS Series... -
Page 9: How To Operate
Portioning Scale HOW TO OPERATE How to weight a product Turn on the scale, place the product in the plate and the weight will be shown in the display; the symbols “kg”, “lb” or “oz” will appear depending on the unit previously selected. How to use “TARE”... -
Page 10: How To Use "Reference Zero
“HI” key to increase or the “LO” key to decrease the highest limit value. Press again the “SET LIMIT” key, “LO LMT?” will be shown and repeat the same procedure, press once again the “SET LIMIT” key to save the alarms limits and start weighting. L-EQ HS Series... -
Page 11: Pc Communication
Portioning Scale PC COMMUNICATION How to display weight measure on PC screen To be able to transmit the scale’s data to your computer, please follow these steps: •Connect your scale computer using a RS232 cable. •Send "P" letter (or equivalent on ASCII code) from the computer. -
Page 12: Using Scale Software
Serial”, choose a Baud Rate (9600 bps recommended) and the Port which your computer recognized the scale. Select Conectar and next Empezar Secuencia, immediately you would see the weight on your PC screen real time. stop communication select Desconectar. L-EQ HS Series... -
Page 13: Power Timer Function
Portioning Scale POWER TIMER FUNCTION This function is activated when the scale is turned on without the AC/DC power supply. When the sale is not used during approximately 15 minutes it will automatically be turned off. LOW BATTERY INDICATOR If the battery does not have enough charge the low battery’s indicator will appear in the display, is possible to keep on working with the scale for 30 minutes. -
Page 14: Other Important Messages That Appear On The Scale
-> 0 <- key, or turn the scale off and then turn it back on again. LOW BAT This message appears when the battery charge is not enough to keep the scale on and therefore turns off. L-EQ HS Series... -
Page 15: Maintenance And Cleaning
Portioning Scale MAINTENANCE AND CLEANING One of the greatest advantages of purchasing this scale model is that it requires minimum maintenance and it is very simple to keep it in favorable conditions. Do not use a flow of water to clean tour scale. use a damp rag and •... -
Page 16: Troubleshooting Guide
The word “HELP” The scale was turned on Remove the weight, turn appears in the with a weight over the off the scale and then display plate. turn it on again. L-EQ HS Series... -
Page 17: Technical Specifications
Portioning Scale TECHNICAL SPECIFICATIONS L-EQ 5/10-HS L-EQ 10/20-HS MAX. 5kg / 10lb / 160oz MAX. 10kg / 20lb / 320oz MIN. 20g MIN. 40g MIN. DIV. MIN. DIV. 0.001kg / 0.002lb / 0.05oz 0.002kg / 0.005lb / 0.1oz MAX. TARE MAX. -
Page 18: Additional Data
Distributor_______________________________________________ Address ________________________________________________ Telephone number _______________________________________ Purchase date __________________________________________ Purchase date __________________________________________ Serial number ___________________________________________ We reserve the right to change any specification contained in this text without prior notice. L-EQ HS Series... - Page 19 ELECTRONIC SCALE www.torrey.net...
