Checking System Status

After making connections on the N7700SAS and powering up, check whether the
system status is normal or has trouble by observing indicators on the front panel
and hard disk trays.

System Status Normal

The system status is normal if:
The WAN and LAN LEDs glow
1.
green (assuming both are
connected).
The Power LED on the Front Panel
2.
glows blue.
The HDD Power LED on each HDD
3.
tray glows blue (assuming all
disks are installed).
The default IP address of the WAN
4.
port is 192.168.1.100 displayed
on LCD.

System Trouble

The system has trouble if:
1. System Busy LED glows red.
If the system has trouble, please refer to
Chapter 7: Troubleshooting.
WARNING
There are no user serviceable parts inside the N7700. Please contact your
