Chapter 5: Using The N7700Sas; Overview; Login Page; Using Webdisk - Thecus N7700SAS User Manual

Chapter 5: Using the N7700SAS

Overview

Once the N7700SAS is setup and operating, users on the network may manage all
varieties of digital music, photos, or files by simply using their web browsers. To
manage your personal files or access public files on the N7700SAS, just enter its IP
address into your browser (default IP address is http://192.168.1.100), and you
w ill be taken to the N7700SAS Login page.
NOTE

Login Page

To login to the system, enter your user name and password, and select Web Disk or
Photo server then click Login to log into the system. You will be taken to the
selected interface.

Using WebDisk

The N7700SAS provides a WebDisk function that allows you to access the system
over the Internet from any browser.
1. In the Login page, type in the User ID and password that were previously set
for you in the Accounts menu. See
Chapter 4:User and Group Authentication >
2. The WebDisk page appears showing folders made currently available to you
via the Access Control List (ACL).
3. Click on a folder name to enter the folder.
4. The folder's page appears displaying files and folders. Click on a file to
download the file.
5. Buttons on the folder page allow you to create a new folder, upload files and
delete files in the folder.
Before proceeding, make sure that WebDisk Support or Secure WebDisk Support is
enabled in the Service Support screen in the system's Network menu. See Service
Support in Chapter 4: System Network >HTTP/Web Disk.
Local User
98
Configuration.
