TECHNICAL SPECIFICATIONS

Analog Inputs
Connectors:
Impedance:
Max. Input Level:
Sensitivity:
A to D Conversion:
A to D Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
Analog Outputs
Connectors:
Impedance:
Max. Output Level:
Full Scale Output Range:
D to A Conversion:
D to A Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
Digital Inputs and Outputs
S/PDIF In/Out:
Formats:
Sample Rate:
PCMCIA Interface
Connector:
Standards:
Card Format:
Control Interface
MIDI:
External control:
General
Finish:
LED:
LCD:
Dimensions:
Weight:
Mains Voltage:
Power Consumption:
Backup Battery Life:
EMC
Complies with:
Safety
Certified to:
Environment
Operating Temperature:
Storage Temperature:
Humidity:
NOTE: Due to continuous development and standardization all specifications are subject to change without notice
1/4" phone jack, unbalanced (Ring: grounded)
1 MOhm
+21 dBu
@ 15 dB headroom: -26 dBu to +6 dBu
24 bit (1 bit, 128 times oversampling)
0,9 ms @ 44.1 kHz
>105 dB
0.003% @ 1 kHz, 6 dB below full scale
+0/-0.5 dB (20 Hz - 20 kHz)
<-60 dB (20 Hz - 20 kHz)
1/4" phone jack, balanced
100 Ohm (active transformer)
+22 dBu
-10 dBu to +22 dBu
24 bit (1 bit, 128 times oversampling)
0.6 ms @ 44.1 kHz
>100 dB
0.005% @ 1 kHz, 6 dB below full scale
+0/-0.5 dB (20 Hz - 20 kHz)
<-60 dB (20 Hz - 20 kHz)
Coaxial, RCA Type
EIAJ CP-340, IEC 958, S/PDIF (24 bit)
44.1 kHz
PCMCIA Type 1 cards
PCMCIA 2.0, JEIDA 4.0
Supports up to 2 MB SRAM
In/Out/Thru: 5 Pin DIN
1/4" phone jack
Anodized aluminum face. Plated and painted steel chassis
3 LED meters, 5 x 14 dot LED-matrix
56 x 128 dot graphic LCD-display
19" x 1.75" x 8.2" (483 x 44 x 208 mm)
5.0 lb. (2.25 kg)
100 to 240 VAC, 50 to 60 Hz (auto-select)
<20 W
>10 years
EN 55103-1, EN 55103-2 and
Class B limits of FCC rules, part 15
EN 60065, UL 1419
32 °F to 122 °F (0 °C to 50 °C)
-22 °F to 167 °F (-30 °C to 70 °C)
Max. 90% non-condensing
